Поз.
Артикул
Описание
5
HOSE FEED & RETURN 8X11MM, ORDER BY THE METER
11
SEALING RING. SEAL RING DELIVERY LINE TO STEERING
11
SEAL RING CONNECTION: 1,4 719029
14
BANJO UNION , Replaced By: N915052008019
15
CONNECTOR
15
ELBOW FITTING FUEL LINES TO FITTING CONEXAO ESPIGAO - "L"
17
PLASTIC PIPE AERATION, ORDER BY THE METER
20
INSULATING HOSE
20
INSULATING HOSE
26
BANJO UNION FEED 8/14 MM,659794
29
HOLLOW SCREW TWO-WAY VALVE,CONNECTIONS: "11,12"
32
SEAL RING FUEL LINE TO FEED PUMP
35
FITTING RETURN
38
NUT. UNION NUT RETURN
41
HOSE , ORDER BY THE METER
41
HOSE , Replaced By: A3769978182
42
HOSE FEED LINE AND RETURN LINE
43
SLEEVE FEED
44
CLAMP , Replaced By: N916017011001
44
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
45
CLAMP LINE MOUNTING
45
CLAMP FUEL LEAK LINE,FUEL FILTER
47
BANJO UNION CONNECTION OF FUEL LINES
50
HOLLOW SCREW
53
SEAL RING INJECTION PUMP
56
BRACKET COMPRESSED AIR LINE TO SIDE MEMBER
59
SCREW PLUG SOCKET TO FRAME
62
NUT BRACKET TO SIDE MEMBER
65
CLAMP FROM EXPANSION TANK TO HEATING PIPE, NOT USED
65
CLAMP FUEL LINES TO BRACKET
68
SCREW MOUNTING CLAMP TO BRACKET AND TO FRAME
71
HEXAGON HEAD BOLT COVERING TO CAB
74
WASHER TRAILER PLUG SOCKET TO BRACKET
80
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
83
NUT , Replaced By: N913004006001
86
LOOM TIE ELECTRIC CABLE MOUNTING
86
LOOM TIE LINE MOUNTING
86
LOOM TIE
87
WASHER BRACKET TO LEFT SIDE MEMBER
