Поз.
Артикул
Описание
5
RESERVOIR (RESERVOIR)
5
RESERVOIR , Replaced By: A3504317102
8
RESERVOIR WITH LOCKING CAP
11
FILLER CAPTO A 688 431 00 02
11
FILLER CAP
14
SEAL RING
17
STRAINER
20
WASHER
23
NUT FRONT SPRINGS WITH TORSION BAR TO FRONT AXLE
29
HEXALOBULAR BOLT BRACKET TO BRACKET M8X16
29
SCREW BATTERY POS. CABLE TO BRACKET,PB004444
30
NUT AT FILTER BRACKET
30
NUT SPRING-LOADED PUSH ROD
32
BRAKE HOSE , Replaced By: A6889978282
33
GROMMET ,D 314239
34
CLAMP ELECTRIC CABLE TO STEERING COLUMN BRACKET
35
SCREW SIDE MARKER LAMP
35
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
37
HEX. NUT M 5 DIN 934-5 S. NUT PLUG SOCKET TO FRAME
37
NUT RELAY TO BRACKET M5
38
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
38
LOOM TIE. CLAMP HOSE TO HEATING PIPE
38
CLAMP HOSE TO FITTING AND TO OIL TANK
39
LOOM TIE , Replaced By: A3459977390
41
FITTING CLUTCH SLAVE CYLINDER
98
LINE , Replaced By: A6842907713
98
LINE FROM MASTER CYLINDER TO CONNECTOR I,D 001958
98
LINE FROM MASTER CYLINDER TO CONNECTOR I,D 001959 D 007186
98
LINE FROM MASTER CYLINDER TO CONNECTOR I
100
ADAPTER FITTING
100
FITTING DOUBLE FITTING,012797
100
FITTING
101
LINE FROM CONNECTOR I TO CONNECTOR II,010628
101
LINE FROM CONNECTOR II TO CONNECTOR III
104
LINE FROM CONNECTOR TO CLUTCH SLAVE CYLINDER,D 001659B 933016
104
LINE CLUTCH BOOSTER,CONNECTION: 1-4, D 007187
104
LINE FROM CONNECTOR TO CLUTCH SLAVE CYLINDER,D 001658
104
LINE FROM CONNECTOR TO CLUTCH SLAVE CYLINDER, D 007186
104
LINE FROM CONNECTOR TO CLUTCH SLAVE CYLINDER,B 933017 D 007186
107
GLAND , Replaced By: A0019901667
107
GLAND LINE CONNECTION
110
UNION NUT LINE CONNECTION
110
UNION NUT
113
ROHRVERSCHRAUBUNG EM. UNION SCREW LINE MOUNTING
113
UNION SCREW
116
CONNECTION FITTING ,880809
116
FITTING , Replaced By: A0039978972
119
FITTING CLUTCH HOSE 1-4, D 007187
122
SEAL RINGTO 000 553 03 05,000 553 18 05,
122
SEAL RING FUEL LINE TO FEED PUMP
131
HOSE CLUTCH HOSE
131
HOSE , Replaced By: A6932950335
131
HOSE FROM HYDRAULIC HOSE TO CLUTCH SLAVE CYLINDER
134
PLASTIC PIPE AERATION, ORDER BY THE METER
146
BANJO UNION
146
BANJO UNION HOSE WIDTH, / I.D., 6/16 MM
147
INSULATING HOSE
149
BRACKET , Replaced By: A3464296040
152
SCREW BRACKET TO BUMPER,LEFT M 10X25
155
NUT , Replaced By: N910113010000
156
LOOM TIE , Replaced By: A0019978390
156
CABLE TIE BRANCH-OFF LINE FASTENING FOR RPM SENSOR
156
LOOM TIE , Replaced By: A3459977390
156
LOOM TIE LINE MOUNTING 280 MM
158
CLAMP ,K 147121, Replaced By: N000000000319
158
CLAMP LINE MOUNTING
158
CLAMP DELIVERY AND SUCTION LINES TO FRAME
159
CABLE TIE BRANCH-OFF LINE FASTENING FOR RPM SENSOR
161
SCREW FUEL LINE TO BRACKET
161
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
161
SCREW CAP TO BRACKET
164
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
167
NUT BRACKET TO FIRE WALL
167
NUT PUMP TO BRACKET
176
CLUTCH BOOSTERKNORR, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
212
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
212
SCREW PIPE CLAMP
