Поз.
Артикул
Описание
74
LINE
74
LINE , Replaced By: A6844607924
77
UNION NUT LINE CONNECTION, Replaced By: N000000006243
80
GLAND , Replaced By: A0019901267
83
BRACKET ,B 981730
86
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
86
SCREW , Replaced By: N304017010040
89
WASHER GROUND CABLE
92
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
92
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
95
HOSE , Replaced By: A3859971582
95
HOSE , Replaced By: A3849977482
95
HOSE RETURN, FROM STEERING TO OIL TANK, ORDER BY THE METER
98
CLAMP25-40X13 MM
101
OIL LINE SUCTION LINE TO OIL PUMP
104
HOLLOW SCREW AIR COMPRESSOR,CONNECTION: "2"
107
SEAL RING ENGINE AIR COMPRESSOR,CONNECTION: "20"
110
LINE FROM OIL PUMP TO HIGH PRESSURE HOSE 15X1.5 MM
113
UNION NUT LINE CONNECTION
116
GLAND LINE CONNECTION
119
HOSE ,12005921
119
HOSE FROM PUMP TO STEERING
119
HOSE FROM PUMP TO STEERING
122
LINE FROM HOSE TO DOUBLE FITTING I,D 010627
122
LINE FROM HOSE TO DOUBLE FITTING I
123
UNION NUT LINE CONNECTION
124
GLAND LINE CONNECTION
125
CONNECTION FITTING FEED LINE TO STEERING
126
BRACKET
128
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
131
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
134
LINE FROM DOUBLE FITTING I TO DOUBLE FITTING II
137
LINE FROM DOUBLE FITTING II TO DOUBLE FITTING III
137
LINE FROM DOUBLE FITTING II TO DOUBLE FITTING III
137
LINE FROM DOUBLE FITTING II TO DOUBLE FITTING III,D 010627
140
LINE FROM DOUBLE FITTING III TO STEERING
143
UNION NUT LINE CONNECTION
146
GLAND LINE CONNECTION
149
CONNECTION FITTING FEED LINE TO STEERING
152
FITTING POWER STEERING PUMP M16X1,5/M22X1,5,D 084765
155
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
158
FITTING STEERING, 345.200 FROM IDENT NO. 004796
161
SEAL RING VALVE TO VALVE,K 025179
164
LINE FROM STEERING TO DOUBLE FITTING I 22X1.5 MM
167
LINE FROM DOUBLE FITTING I TO DOUBLE FITTING II,D 010627
167
LINE FROM DOUBLE FITTING I TO DOUBLE FITTING II
170
LINE FROM DOUBLE FITTING II TO DOUBLE FITTING III 22X1.5 MM, 345.200 FROM IDENT NO. 004796
173
LINE FROM DOUBLE FITTING III TO DOUBLE FITTING IV,D 010627
173
LINE FROM DOUBLE FITTING III TO DOUBLE FITTING IV
176
LINE FROM DOUBLE FITTING IV TO OIL TANK,D 010626
176
LINE FROM DOUBLE FITTING IV TO OIL TANK,D 010627
179
UNION NUT LINE CONNECTION, Replaced By: N000000006243
182
GLAND , Replaced By: A0019901267
185
FITTING HIGH PRESSURE LINE TO STEERING
188
BRACKET
191
SCREW BRACKET TO SIDE MEMBER M8X20
194
NUT ENGINE MOUNTING M8
197
CLAMP HOSE TO RADIATOR BASE FRAME,B 669058
197
CLAMP DELIVERY AND SUCTION LINES TO FRAME 22/15
197
CLAMP DELIVERY AND SUCTION LINES TO FRAME
197
CLAMP LINE MOUNTING
200
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
201
SHEET METAL SCREW , Replaced By: N007971005208
206
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
209
BRACKET MOUNTING USED FOR COMPRESSED AIR LINES
212
HEXAGON HEAD BOLT BRACKET TO BRACKET M8X25
218
NUT ENGINE MOUNTING M8
221
CLAMP HOSE TO RADIATOR BASE FRAME,B 669058
221
CLAMP DELIVERY AND SUCTION LINES TO FRAME 22/15
221
CLAMP LINE MOUNTING
221
CLAMP DELIVERY AND SUCTION LINES TO FRAME
224
SCREW DELIVERY AND SUCTION LINES TO ENGINE, TOP
224
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
227
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
230
NUT LEVER TO THROTTLE VALVE SHAFT TO 366 140 02 32
