Поз.
Артикул
Описание
5
ACCELERATOR PEDAL
8
JOINT
11
SCREW ACCELERATOR PEDAL TO FLOOR PLATE
17
STOP FULL THROTTLE
20
LEVER (PEDAL LEVER)
26
LOCK PLATE
29
BUSHING ,B 892893
32
WASHER GROUND CABLE
35
LOCK RING. RETAINING RING ACCELERATOR PEDAL TO LEVER
38
LEVER (CONTROL LEVER)
44
BALL STUD. BALL PIVOT TOP B10X4,5 MM
47
LEVER (CONTROL LEVER)
50
BRACKET REVERSING LEVER
53
LEVER
56
BALL STUD. BALL PIVOT TOP B10X4,5 MM
59
BUSHING INTERMEDIATE LEVER TO BEARING BRACKET,5 943507
62
COVERING
65
LOCK PLATE
68
ROD265 MM
71
ROD305 MM
77
BALL SOCKET PULL ROD TO LEVER
80
NUT
83
SECURING CLIP. CIRCLIP ACCELERATOR CONTROL
86
SCREW , Replaced By: A0079900801
86
SCREW REDUCTION VALVE TO BRACKET
89
LOCK WASHER RAIL TO BATTERY SUPPORT
92
SCREW BRACKET TO FRAME
95
WASHER PLUG SOCKET TO BRACKET
98
NUT PUMP TO BRACKET
