Поз.
Артикул
Описание
5
STEERING SUPPORT , HYDRAULIC STEERING-766.4
5
STEERING SUPPORT , MECHANIC STEERING-762.0
5
STEERING SUPPORT , HYDRAULIC STEERING-766.4D 523393
5
STEERING SUPPORT , MECHANIC STEERING-762.0
8
HEXAGON HEAD BOLT BEARING BRACKET TO SIDE MEMBER M 12X50
8
SCREW TIGHTENER PULLEY TO BRACKET ON ENGINE
8
HEXAGON HEAD BOLT BEARING BRACKET TO SIDE MEMBER M 12X50
8
HEXAGON HEAD BOLT BEARING BRACKET TO SIDE MEMBER M 12X50
8
SCREW LEFT AND RIGHT CONSOLES TO FRAME M 12X1.5X50
11
LOCK WASHER FITTING TO BRACKET
14
NUT BRACKET TO SIDE MEMBER M12X1.5
17
HEXAGON HEAD BOLT SUPPORTING ARM TO ENGINE REAR MOUNTING M18X1.5X50
17
SCREW STEERING GEAR TO STEERING BRACKET, MECHANIC STEERING-762.0
17
SCREW STEERING GEAR TO STEERING BRACKET M 12X130, MECHANIC STEERING-762.0
20
LOCK WASHER BELL HOUSING TO TRANSMISSION
23
NUT STEERING GEAR TO STEERING BRACKET, MECHANIC STEERING-762.0
23
NUT ALTERNATOR TO SUPPORT
26
PITMAN ARM
26
PITMAN ARM , MECHANIC STEERING-762.0
26
PITMAN ARM
26
PITMAN ARM , MECHANIC STEERING-762.0
29
BOOT
32
DRAG LINK , HYDRAULIC STEERING-766.4
32
DRAG LINK , HYDRAULIC STEERING-766.4
32
DRAG LINKNAKATA, MECHANIC STEERING-762.0
32
DRAG LINKTRW, MECHANIC STEERING-762.0
32
DRAG LINKTRW
32
DRAG LINKNAKATA
32
DRAG LINKNAKATA, MECHANIC STEERING-762.0
32
DRAG LINKTRW, MECHANIC STEERING-762.0
35
DRAG LINK ENDTO 688 460 05 05,75 05,74 05,76 05
35
DRAG LINK ENDTO 688 460 03 05,77 05,79 05
38
BOOTTO 000 460 63 48
41
BOOTTO 000 460 62 48
44
RINGTO 000 463 20 96
47
CLAMPING PIECE JOINT TO DRAG LINK TO 688 460 05 05,75 05,81 05, 7605
47
CLAMP JOINT TO DRAG LINK TO 688 460 05 05,75 05,81 05, 7605
47
CLAMP JOINT TO DRAG LINK TO 688 460 03 05,77 05, 78 05
50
SCREW CLAMP TO DRAG LINK TO 000 463 05 17
50
SCREW CLAMP TO DRAG LINK TO 344 338 73 45
50
SCREW CLAMP TO DRAG LINK TO 344 338 73 45
53
NUT , Replaced By: N910113010003
53
NUT , Replaced By: N910113010003
56
BOOT FIXED PART OF JOINT TO 688 460 03 05,77 05,79 05,78 05
59
BOOT FIXED PART OF JOINT TO 688 460 05 05,75 05,74 05,76 05
62
RINGTO 000 463 20 96
65
NUT DRAG LINK TO STEERING ARM AND PITMAN ARM
68
COTTER PINROCKINGER TYP 260 G140
