Поз.
Артикул
Описание
5
AIR SPRING BELLOWS AIR SPRING BELLOWS
5
AIR SPRING BELLOWS AIR SPRING BELLOWS
5
AIR SPRING BELLOWS TRAILING AXLE LIFT
5
AIR SPRING BELLOWS REAR AXLE
5
AIR SPRING BELLOWS FRONT AXLE
8
SUPPORT FRONT AXLE AIR SPRING BELLOWS
8
SUPPORT , Replaced By: A6343203734
8
SUPPORT AIR SPRING BELLOWS
8
SPRING BRACKET , Replaced By: A3573200134
11
14
WASHER , Replaced By: A3859900440
17
20
23
RETAINER
26
SCREW BEARING BRACKET TO FRAME M 14X125
26
SCREW SUPPORT TO SIDE MEMBER M 14X95
29
NUT , Replaced By: N910113014000
35
38
PLATE
41
NUT PISTON TO CONSOLE
42
50
SCREW SUPPORT TO SIDE MEMBER M 12X1.5X30
53
NUT ALTERNATOR TO SUPPORT
61
FITTING AIR RESERVOIR,CONNECTION: "11"
74
THRUST RING CHECK VALVE TO AIR RESERVOIR
74
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
77
O-RING CHECK VALVE TO AIR RESERVOIR
80
NUT CHECK VALVE TO AIR RESERVOIR
104
HOLLOW SCREW HEATING CONNECTION
107
SEAL RING LINE CONNECTION
