Поз.
Артикул
Описание
35
LINE CLUTCH 8 X 1, LENGTH AVAILABLE 3000 MM
38
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
41
FITTING (PARTS KIT),LINE RUPTURE
44
UNION NUT LINE CONNECTION
47
GLAND LINE CONNECTION
53
FITTING HYDRAULIC LINE TO BRACKET,K 130132
54
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
56
NUT FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
59
T-FITTING 3/2-WAY VALVE,CONNECTION: "33", UP TO IDENT NO. 5 385481 FROM IDENT NO. SEE STANDARD VERSION
59
FITTING , Replaced By: A0009909970
70
FITTING FITTING TO BRACKET
72
LINE EXHAUST BRAKE, LENGTH AVAILABLE: 3000 MM
74
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
77
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
80
UNION NUT
83
GLAND , Replaced By: A0019901667
86
SLEEVE LEAK LINE
91
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
93
BRAKE HOSE AT CYLINDER, TO BE ADAPTED DURING ASSEMBLY
93
HOSE , Replaced By: A3074290035, +001A0019909871, +001A0029906071
95
BRACKET LINE MOUNTING
97
179
VALVE REDUCTION VALVE 3 BAR
182
VALVE (3/2-WAY SOLENOID VALVE) WABCO
185
REPAIR KIT REDUCTION VALVE
197
HOLLOW SCREW LINE CONNECTION
200
HOLLOW SCREW HEATING CONNECTION
203
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
206
SEAL RING PNEUMATIC VALVE
209
212
SCREW SWITCH TO BRACKET 8X16
215
SCREW , Replaced By: N304014008007
221
SCREW FUEL TANK TO CONSOLE
224
WASHER , Replaced By: N000125008443
227
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
230
LOCK WASHER FUSE
236
VALVE ENGINE SHUT-OFF
239
VALVE PARTTO 004 997 00 36,5 757289 AUSSERDEM EINGEBAUT IN 5 759173
242
SEAL RINGWABCO
245
SEAL RING VALVE TO VALVE
248
REPAIR KITTO 003 997 14 36,WABCO 472 123 19 80
251
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
254
FITTING LINE CONNECTION, Replaced By: N000000006446
257
FITTING TWO-WAY VALVE,CONNECTIONS: "1","2"
257
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
260
HOLLOW SCREW HEATING CONNECTION
263
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
999
FITTING TWO-WAY VALVE,CONNECTIONS: "1","2"
999
999
999
TS DOUBLE FITTING SOLENOID VALVE
