Поз.
Артикул
Описание
430
BRACKET MODULATION PRESSURE CONTROL
436
SCREW BRACKET TO FRAME SIDE MEMBER
442
SCREW THERMOSTAT HOUSING TO CYLINDER HEAD M 8X20
448
SPRING WASHER CAB FLOOR
454
SPRING WASHER , Replaced By: N000137008212
460
WASHER
466
WASHER , Replaced By: N000125008443
472
BEARING TUBE MODULATION PRESSURE CONTROL
478
BUSHING
484
GREASE NIPPLE PROTECTIVE TUBE
490
WASHER
496
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
502
LEVER MODULATION PRESSURE CONTROL
508
PULL ROD AT CONTROL LEVER, TO BE ADAPTED DURING ASSEMBLY
514
ANGLE JOINT PULL ROD
520
NUT BALL PIVOT TO LEVER
520
NUT BALL PIVOT TO LEVER
526
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
532
ROD MODULATION PRESSURE CONTROL
538
SPACER TUBE PUSH ROD
544
TURNBUCKLE TURNBUCKLE
550
PULL ROD FROM ACCELERATOR PEDAL TO CONTROL SHAFT BEARING, TO BE ADAPTED DURING ASSEMBLY
556
BALL SOCKET PULL ROD TO INTERMEDIATE LEVER
562
NUT BALL PIVOT TO LEVER
562
NUT L.H. THREAD
568
BALL PIVOT ACCELERATOR PEDAL,4 859026
574
NUT BALL PIVOT TO LEVER
580
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
586
CIRCLIP. SECURING CLIP BALL SOCKET TO ROD
999
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
999
T-FITTING 3/2-WAY VALVE
999
CLAMPING RING
