Поз.
Артикул
Описание
3
BEARING COVER TRANSMISSION CASE,INSIDE
6
CYLINDRICAL PIN BEARING COVER 45 MM
9
GASKET BEARING COVER TO TRANSMISSION CASE
9
GASKET , Replaced By: A3872681580
12
NEEDLE BEARING BEARING COVER
12
NEEDLE BEARING BEARING COVER
12
NEEDLE BEARING BEARING COVER
15
BREATHER TRANSFER CASE
18
SCREW CONNECTOR TO CAB M6X8
21
SPRING WASHER LICENSE PLATE TO BRACKET
24
BEARING COVER OUTSIDE
27
GASKET BEARING COVER TO TRANSMISSION CASE
27
GASKET , Replaced By: A3872681580
30
SCREW , Replaced By: N914126008078
30
SCREW BEARING BRACKET TO TRANSMISSION M 8X60,556500
33
DETENT GEAR INTERLOCK,128845
36
CLAMPING PIN SHIFTING SEGMENT
39
SCREW COMPRESSED AIR LINE TO LEFT SIDE MEMBER
39
SCREW , Replaced By: N000933008337
39
SCREW , Replaced By: A0099900101
42
PIN BEARING COVER
45
SPRING REVERSE SPEED STOP
48
SPACER WASHER BEARING COVER
51
LOCK RING GEAR INTERLOCK
54
NEEDLE BEARING STEERING SHAFT BEARING IN COVER
57
SEAL RING BEARING COVER,INSIDE
63
COVER REVERSE SPEED STOP
69
GASKET BEARING COVER TO TRANSMISSION CASE
75
SCREW , Replaced By: N304017008021
75
SCREW PIPE CLAMP
93
SHIFT CASE
99
SCREW CONTROL PLATE TO TRANSMISSION CASE M 8X65
102
SCREW
105
BUSHING SHIFT CASE
105
BUSHING SHIFT CASE
108
EXPANSION PLUG EXHAUST FLAP BEARING
111
BUSHING SHIFT CASE, NORMAL GEARSHIFT SYSTEM
114
SEAL RING SHIFT CASE, NORMAL GEARSHIFT SYSTEM
117
SHAFT (SHIFTING SHAFT)
117
SHAFT
120
CYLINDRICAL PIN SHIFTING SHAFT
123
SELECTOR LEVER (SELECTOR FINGER)
123
SELECTOR LEVER (SELECTOR FINGER),048123
123
SELECTOR LEVER , Replaced By: A3892650230
126
WOODRUFF KEY BEARING BODY,6 900042
129
SPACER WASHER SHIFTING SHAFT
132
SPACER WASHER SHIFTING SHAFT
135
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
