Поз.
Артикул
Описание
236
BRACKET COVER TO CASE,030748
239
SCREW VALVE TO BRACKET M 8X55
239
SCREW , Replaced By: N304017008043
242
VALVE 2/2 -WAY VALVE,P.T.O. CONTROL
245
REPAIR KIT 2/2 -WAY VALVE
248
SCREW , Replaced By: N304017006026
251
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
257
OIL PIPE P.T.O. LUBRICATION
260
HEADLESS SETSCREW OIL PIPE TO TRANSMISSION CASE
263
PIPE SPINDLE TO HOUSING
263
PIPE , FIRST EXHAUST STOCK OF OLD PARTS UP TO TRANSMISSION 058200, Replaced By: A3872607485
266
HOLLOW SCREW LINE MOUNTING,437171
266
HOLLOW SCREW HEATING CONNECTION
269
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
272
OIL PIPE. LINE RETURN LINE TO TRANSMISSION
272
PIPE FROM P.T.O. TO 2/2-WAY VALVE,030748
278
NUT. UNION NUT LINE CONNECTION
281
CUTTING RING. GLAND LINE CONNECTION
284
SCREW-IN FITTING LINE CONNECTION TO TRANSMISSION
284
FITTING
290
SEAL RING
293
CONNECTOR AT SOLENOID VALVE,030747
296
HOLLOW SCREW RESERVOIR TO SUPPORT
299
SEAL RING SOLENOID VALVE A 18X24
301
PLUG FEELER ROLLER
301
PLUG , Replaced By: A3573380035
302
HOLLOW SCREW , Replaced By: N915036010108
302
HOLLOW SCREW FUEL LINE TO FEED PUMP
305
SEAL RINGTO 000 553 03 05,000 553 18 05,
307
PIPE LUBRICATING LINE
307
PIPE , Replaced By: A6552606985
307
OIL PIPE , LENGTH AVAILABLE: 3000 MM233383, Replaced By: A3872608285, +001A3899900563, +001N007603014102, +001N915036010204
308
UNION NUT LINE CONNECTION
309
GLAND LINE CONNECTION
310
HOLLOW SCREW , Replaced By: N915036010108
310
HOLLOW SCREW FUEL LINE TO FEED PUMP
311
HOLLOW SCREW FROM 2/2 -WAY VALVE TO TRANSMISSION M18X1.5,389099
311
HOLLOW SCREW PUMP CONNECTION
314
SEAL RINGTO 000 553 03 05,000 553 18 05,
317
CLAMP OIL-DIPSTICK GUIDE TUBE TO BRACKET
320
PLASTIC PIPE RISING PIPE 4X6 MM
320
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
323
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
326
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
329
HOLLOW SCREW LINE CONNECTION
329
HOLLOW SCREW HEATING CONNECTION
332
SEAL RING PRESSURE CONNECTION TO AIR COMPRESSOR
334
CLIP COMPRSSED AIR LINE TO SUBSTRUCTURE
336
BRACKET TRANSMISSION CASE COVER TO TRANSMISSION CASE
365
LOOM TIE LINE MOUNTING 280 MM
999
SEAL RING THRU HOLE
999
INTERMEDIATE SHAFT ,044719 THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3872640505, +001A3892600590
