Поз.
Артикул
Описание
5
INTERMEDIATE PIECE INTERMEDIATE FLANGE
5
INTERMEDIATE PIECE , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A0002610404
8
BUSHING
11
CAP INTERMEDIATE FLANGE
14
PRESSURE SPRING SHIFTING LOCK
17
BALL
20
DOWEL PIN INTERLOCK PIN
23
BALL TO PLUG AIR COMPRESSORE OIL BORE,FRONT SIDE
26
CYLINDRICAL PIN
29
SCREW SPRING STOP
32
WASHER (SUPPORTING PLATE)
35
WASHER0.2 MM
35
WASHER0.1 MM
35
WASHER0.3 MM
38
SCREW OIL LINE TO CRANKCASE
41
SPRING WASHER LICENSE PLATE TO BRACKET
44
BALL BEARING MAIN SHAFT,REAR
47
TRANSMISSION CASE COVER REAR
50
BUSHING
53
BUSHING
59
SEAL RING OUTPUT FLANGE,OUTSIDE
59
SEAL RING , Replaced By: A0079973247
59
SEAL RING OUTPUT FLANGE,INSIDE
62
FLANGE MAIN SHAFT OUTPUT
65
NUT
68
EXPANSION PLUG BELL HOUSING
71
PIN
74
SPRING TRANSMISSION CASE REAR COVER
77
SCREW PLUG , Replaced By: N000908014009
77
SCREW PLUGTO 000 553 03 05,000 553 18 05,
80
VALVE , Replaced By: A3833510065, +001A6013500290
80
LINE TRANSMISSION CASE
83
SCREW 3/2-WAY VALVE TO BRACKET M 8X105
86
SCREW , Replaced By: N000933008134
86
SCREW FRONT AXLE REGULATING SOLENOID VALVE
89
SCREW SPRING STOP
92
SCREW VALVE TO BRACKET
95
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
95
SPRING WASHER , Replaced By: N000137008212
