Поз.
Артикул
Описание
5
TRANSMISSION CASE
8
CYLINDRICAL PIN
11
PIN ,041858
13
GEAR
15
BUSHING
19
REVERSE IDLER SHAFT
21
SCREW
25
SPRING WASHER STEERING COLUMN BRACKET TO CAB
27
NUT
27
NUT , Replaced By: N304032010002
29
LEVER
35
DOWEL PIN
37
COLLAR. SLEEVE
41
COUNTERSHAFT , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 365564-414556 ALSO INSTALLED ON, SEE FOOTNOTE 6 AND 9
44
KEY
47
GEAR 27 TEETH, 3RD SPEED
50
GEAR 33 TEETH, 4TH SPEED, 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 365564-394000 ALSO INSTALLED ON, SEE FOOTNOTE 6 AND 14
52
LOCK RING
55
WASHER
57
CYLINDR. ROLLER BEARING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
57
BALL BEARING , Replaced By: A0049814201
61
SPACER WASHER AS REQUIRED 0.10 MM, UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
65
DRIVE SHAFT , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 365564 ALSO INSTALLED ON, SEE FOOTNOTE 6 AND 14
67
OIL RING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
71
GROOVED BALL BEARING
75
SNAP RING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
76
SPACER RING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
81
SNAP RING AS REQUIRED 1.9 MM
85
SPACER WASHER AS REQUIRED 0.1 MM
91
MAIN SHAFT
95
NEEDLE BEARING 3RD SPEED
97
GEAR 3RD SPEED
99
THRUST WASHER , UP TO TRANSMISSION: 023 766040 UP TO CHASSIS: 009860
103
SYNCHRONIZER RING 3RD AND 4TH SPEED
105
SYNCHRONIZER BODY 3RD AND 4TH SPEED
109
SYNCHRONIZER BODY , NO LONGER AVAILABLE
111
SPRING
113
BALL HOUSING,FRONT
121
FOLLOWER
125
SLIDING COLLAR 3RD AND 4TH SPEED, NO LONGER AVAILABLE
127
LOCK
129
GROOVED NUT
132
ROLLER ASSEMBLY
132
ROLLER ASSEMBLY , Replaced By: A0029813412
135
ROLLER ASSEMBLY
140
GEAR , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 365564 ALSO INSTALLED ON, SEE FOOTNOTE 6 CONTINUED, SEE FOOTNOTE 22
142
SNAP RING , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 365564 ALSO INSTALLED ON, SEE FOOTNOTE 6 CONTINUED, SEE FOOTNOTE 22
145
THRUST WASHER 7.90 MM
149
SYNCHRONIZER RING 3RD AND 4TH SPEED
151
SYNCHRONIZER BODY 1ST AND 2ND SPEED, 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 365564 ALSO INSTALLED ON, SEE FOOTNOTE 6 CONTINUED, SEE FOOTNOTE 22
155
SYNCHRONIZER BODY , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 365564 ALSO INSTALLED ON, SEE FOOTNOTE 6 CONTINUED, SEE FOOTNOTE 22 NO LONGER AVAILABLE
159
SPRING
162
BALL HOUSING,FRONT
165
FOLLOWER
169
SLIDING COLLAR , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 365564 ALSO INSTALLED ON, SEE FOOTNOTE 6 CONTINUED, SEE FOOTNOTE 22 NO LONGER AVAILABLE
173
KEY
175
THRUST WASHER 4.40 MM
179
NEEDLE BEARING
185
GEAR 33 TEETH, 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 414557, 002,003,005,011,017 FROM TRANSMISSION 011431
189
THRUST WASHER 3.80 MM
191
BALL BEARING
199
SNAP RING
201
SPACER WASHER 0.10 MM
205
DRIVE GEAR
207
TRANSMISSION CASE COVER FRONT, 261362
209
SCREW SUPPORT TO FENDER
209
SCREW , Replaced By: N304017008018
211
SPRING WASHER , Replaced By: N000137008212
211
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
214
BALL PIVOT , 261362
217
SPRING WASHER STEERING COLUMN BRACKET TO CAB
219
TRANSMISSION CASE COVER REAR
221
PLUG
225
SHAFT
229
DRIVE GEAR
233
SCREW SUPPORT TO FENDER
233
SCREW , Replaced By: N304017008018
235
SCREW
239
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
239
SPRING WASHER , Replaced By: N000137008212
241
FLANGE
245
LOCK
247
GROOVED NUT
249
SCREW PLUG , Replaced By: A0009972632
251
SCREW PLUG
251
SCREW PLUG , Replaced By: A2109970132
253
SEAL RING
257
GASKET KIT TRANSMISSION
261
REPAIR KIT TRANSMISSION CASE FRONT COVER
269
WASHER
999
SEAL RING , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
BALL BEARING , UP TO CHASSIS 017058 UP TO TRANSMISSION 766040
999
KNOB DARK GRAPHITE GREY
999
BOOT , 000,001,004,010,016 FROM CHASSIS 190318 ALSO INSTALLED ON,SEE FOOTN.36,002,003,005,011,017 FROM CHASSIS 034217 ALSO INSTALLED ON SEE FOOTN.37 AND FOOTN.49
999
LEVER , ON SPECIAL REQUEST, POWER STEERING
999
GEAR , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 365564 ALSO INSTALLED ON, SEE FOOTNOTE 6 CONTINUED, SEE FOOTNOTE 22
999
LEVER , Replaced By: A1112601381
999
LEVER
999
SHIFTING TUBE , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR, SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.43
999
BEARING BRACKET , ON SPECIAL REQUEST, POWER STEERING
999
LEVER
999
DRIVE SHAFT , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 394001, 002,003,005,011,017 FROM TRANSMISSION 007686
999
SHIFTING TUBE , 000,001,004,010,016 FROM CHASSIS 190318 ALSO INSTALLED ON, SEE FOOTN.36,002,003,005,011,017 FROM CHASSIS 034217 ALSO INSTAL- LED ON SEE FOOTN.37 AND FOOTN.45
999
SHIFTING ROD
999
TRANSMISSION WITH BELL HOUSING
999
TRANSMISSION WITH BELL HOUSING
999
SHIFTING ROD
999
GEAR 1ST SPEED, NOT USED
999
GEAR , NOT USED
999
GEAR 33 TEETH, 4TH SPEED, 000,001,004,010,016,100,101,110,116 FROM TRANSMISSION 394001, 002,003,005,011,017 FROM TRANSMISSION 007686
999
COUNTERSHAFT , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 414557, 002,003,005,011,017 FROM TRANSMISSION 011431
999
COVER , ON SPECIAL REQUEST, POWER STEERING
999
SHAFT , ON SPECIAL REQUEST, POWER STEERING
999
LEVER , ON SPECIAL REQUEST, POWER STEERING
999
LEVER
999
LEVER
999
TRANSMISSION CASE COVER , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 040899-490815, 002,003,005,011,017 UP TO TRANSMISSION 021530, Replaced By: A1112603114, +001A1112610066
999
SHIFTING TUBE , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.38
999
LEVER
999
TRANSMISSION CASE COVER
999
BEARING BRACKET , 040898
999
PIPE , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 490816, 002,003,005,011,017 FROM TRANSMISSION 021531
999
GASKET , NO LONGER AVAILABLE INDIVIDUALLY, BUT ONLY IN REPAIR KIT
999
GASKET
999
GEAR , NOT USED
999
COUNTERSHAFT , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 365564-414556 ALSO INSTALLED ON, SEE FOOTNOTE 6 AND 9
999
COUNTERSHAFT , 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 414557, 002,003,005,011,017 FROM TRANSMISSION 011431
999
BOOT , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.38
999
SHAFT
999
GUIDE PIVOT , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.38
999
COVER
999
KNOB LIGHT IVORY-COLORED, 000,001,004,010,016 UP TO CHASSIS 130558, 100,101,104,110 UP TO CHASSIS 225648 ON SPECIAL REQUEST
999
WASHER1.0 MM, 10/50,12/52 UP TO CHASSIS 096085, 20/60,22/62 UP TO CHASSIS 095140
999
WASHER0.5 MM, 10/50,12/52 UP TO CHASSIS 096085, 20/60,22/62 UP TO CHASSIS 095140
999
GASKET
999
GEAR 30 TEETH, 1ST SPEED, 000,001,004,010,016,100,101,104,110,116 FROM TRANSMISSION 365564-414556 ALSO INSTALLED ON, SEE FOOTNOTE 6 AND 9
999
SEAL RING , Replaced By: A0119976447
999
SCREW PLUG , Replaced By: A2109970132
999
THRUST WASHER , Replaced By: A1202621362
999
THRUST WASHER 4.50 MM
999
THRUST WASHER , Replaced By: A1202621562
999
THRUST WASHER , NOT USED
999
THRUST WASHER AS REQUIRED
999
THRUST WASHER AS REQUIRED
999
SPACER WASHER INTERMEDIATE BEARING
999
PIN ,041857
999
SPACER WASHER 0.20 MM
999
SPACER WASHER 0.2 MM
999
SPACER WASHER 0.3 MM
999
SPACER WASHER 0.30 MM
999
INTERLOCK PLUG , Replaced By: A3442657044
999
SNAP RING , Replaced By: A1369940935
999
SNAP RING 2.05 MM
999
SHIFT LEVER , 000,001,004,010,016 UP TO CHASSIS 190317 EXCEPT FOR,SEE FOOTN.36,002,003,005,011,017 UP TO CHASSIS 034216 EXCEPT FOR SEEFOOTN.37 AND FOOTN.38
999
KNOB , Replaced By: A1112680842
999
SEAL RING
999
THRUST WASHER 3.90 MM
999
THRUST WASHER 4.00 MM
999
THRUST WASHER 4.10 MM
999
THRUST WASHER AS REQUIRED 4.20 MM
999
THRUST WASHER AS REQUIRED 4.30 MM
999
THRUST WASHER 4.40 MM
999
THRUST WASHER 4.50 MM
999
SHIFTING FORK 1ST AND 2ND SPEED
999
SPACER WASHER 0.25 MM
999
SPACER WASHER 0.50 MM
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
LOCK WASHER TAIL LAMP TO BRACKET
999
SPRING WASHER LICENSE PLATE TO BRACKET
999
HEADLESS SETSCREW , Replaced By: A1109900110, +001N000137010101
999
SCREW
999
SCREW SELECTOR LEVER TO SELECTOR FINGER
999
SCREW LEVER TO SHAFT
999
SCREW , Replaced By: N304017010050
999
SCREW COVER PLATE TO BRACKET
999
NUT BALL PIVOT TO LEVER
999
NUT , Replaced By: N304032008006
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
SCREW , Replaced By: N304017010055
999
NUT
999
NUT BATTERY CABLE
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
