Поз.
Артикул
Описание
125
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
128
UNION NUT LINE CONNECTION
128
UNION NUT LINE MOUNTING,5 9363655 812730
131
GLAND LINE MOUNTING,5 9363655 812730
131
GLAND LINE CONNECTION
134
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
134
CLAMP ,K 147121, Replaced By: N000000000319
134
CLAMP , Replaced By: A3604300143
134
CLAMP , Replaced By: N916016008200
137
SCREW , Replaced By: N304017006016
137
SCREW PUMP TO BRACKET
140
NUT HEATING PIPE TO BRACKET
140
NUT , Replaced By: N913004006001
140
NUT PUMP TO BRACKET
143
VALVE , Replaced By: A0002702989
143
VALVE 3/2-WAY
146
BRACKET 2/2-WAY VALVE
149
SCREW BRACKET TO TRANSMISSION CASE
152
WASHER
155
LOCK WASHER FITTING TO BRACKET
158
SCREW VALVE TO BRACKET
161
NUT HOOK TO BRACKET
164
FITTING TRANSMISSION CONNECTION
167
SEAL RINGTO 000 270 08 89,16 89,25 89
170
FITTING TWO-WAY VALVE,CONNECTIONS: "1","2"
170
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
173
FITTING P.T.O.
176
ELBOW FITTING MAIN HYDRAULIC CONNECTION
999
VALVE REPAIR KIT TO 000 270 29 89
999
VALVE , Replaced By: A0022601757
999
MAGNETTO 000 270 29 89
