Поз.
Артикул
Описание
5
INDEPENDENT HEATING , RANGE OF PARTS FOR RETROFITTING,SEE ACCESSORIES LITERATURE ONLY APPLICABLE TO VEHICLES CONFORMING TO CODE 581 ORDER ADDITIONALLY B6 614 0046 ACCESSORY
14
ANTENNA
77
MUFFLER
77
MUFFLER
83
PIPELINE , TO BE ADAPTED DURING ASSEMBLY
84
CLAMP EXHAUST PIPE
176
RECEIVER , NO LONGER AVAILABLE
179
TRANSMITTER
180
BATTERY , ONLY FOR THERMO TOP C HEATER WITH PLASTIC CIRCULATION PUMP
206
GUMMED LABEL
209
SWITCH THERMOSTAT
212
HOSE
215
HOSE
218
CONNECTING PIPE17 X 20
218
CONNECTING PIPE20 X 20
218
CONNECTING PIPE18 X 20
221
CLAMP HOSE TO FLANGE AND TO VALVE
221
CLAMP LINE MOUNTING
221
CLAMP FRAME MOUNTED CABLE HARNESS AND BATTERY CABLE TO BRACKET
221
CLAMP CABLE HARNESS MOUNTING 48/20
224
CLAMP , Replaced By: N916026020001
227
RUBBER MOUNTING BETWEEN HEATER UNIT AND EXHAUST MUFFLER,B 377200
230
RUBBER MOUNTING HEATER UNIT TO WHEEL ARCH, A 209749 F 108104
233
RUBBER MOUNTING AT RIGHT SIDE MEMBER
236
NUT
239
CLAMP LINE MOUNTING
242
LOOM TIE , F 155735 EXCEPT CODE 807 ALSO INSTALLED IN VEHICLE TO F 155734 WITH CODE 808
245
SCREW FUSE BOX TO BRACKET
248
SCREW PANELLING TO BUMPER
254
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
254
SCREW LICENSE PLATE TO BRACKET
254
SCREW CABLE HARNESS MOUNTING
257
SPRING WASHER ALTERNATOR CONNECTION D+
263
WASHER COMPRESSED AIR LINE TO BRACKET
263
WASHER COMPRESSED AIR LINE TO BRACKET
263
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
266
TAPPING SCREW BRACKET TO SUPPORT
269
COMBINATION BOLT BRACKET TO FRAME
272
LOCK NUT MOUNTING, COVER, THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0019900856
278
HEXAGON NUT ELECTRIC CABLE TO ALTERNATOR TERMINAL B-
281
NUT SPRING-LOADED PUSH ROD
284
STUD45 MM
284
STUD30 MM
