Поз.
Артикул
Описание
451
SLEEVE PORT-CLOSING FINE ADJUSTMENT
451
FITTING , Replaced By: A6010740632, +001A6010740228
454
SET SCREW , Replaced By: A6010740228, +001A6010740632
454
SET SCREW PORT-CLOSING FINE ADJUSTMENT
457
COMBINATION BOLT , Replaced By: N304017006019, +001N000137006204
457
SCREW , WITH DIESEL ENGINE
466
SUPPORT INJECTION PUMP
472
SCREW PUMP TO BRACKET
472
SCREW , Replaced By: N304017006016
475
SCREW , Replaced By: N304017008021
475
SCREW PIPE CLAMP
478
WASHER BATTERY MOUNTING, FROM IDENT NO. 5 419107-5 757662 ALS INSTALLED ON 5 800000-5 806588
487
SEAL RING INJECTION PUMP TO CRANKCASE
490
SCREW BRACKET TO 3/2-WAY VALVE
496
NUT INJECTION PUMP TO CRANKCASE
502
CONNECTOR
505
SEAL RING SCREW PLUG
514
LINE CYLINDER NO.5
514
LINE CYLINDER NO.4
514
LINE CYLINDER NO.6, 912 10/50,20/60 080073 912 12/52,22/62 055081 931 10/50,20/60 002586 931 12/52,22/62 001037 950 12/52,22/62 003505 960 12/52,22/62 040511 963 12/52,22/62 003531
514
LINE CYLINDER NO.2
514
LINE CYLINDER NO.3
514
LINE CYLINDER NO.1
520
BRACKET , Replaced By: A6010781941, +001A6010780386, +002A6010780486
520
BRACKET FUEL LINES NO.1-3
523
SHIM FUEL LINE TO BRACKET
526
SHIM FUEL LINE TO BRACKET
529
BRACKET FUEL LINES NO.1-3
532
BRACKET , Replaced By: A6030780141
535
LINE FASTENER FUEL LINES NO.1-5
538
BRACKET CONTROL LINE TO REGULATING ROD
538
BRACKET , Replaced By: A6010782641
544
COMBINATION BOLT , Replaced By: N304017006016
544
COMBINATION BOLT
547
BRACKET FUEL LINES NO.4
550
BRACKET FUEL LINES NO.4+5
553
COMBINATION BOLT
553
COMBINATION BOLT , Replaced By: N304017006016
556
SCREW , Replaced By: N304017006020
556
SCREW LICENSE PLATE TO BRACKET
559
SPRING WASHER LICENSE PLATE TO BRACKET
565
NOZZLE HOLDER , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0030172921
565
NOZZLE HOLDER COMBINATION BOSCH,970518 372
568
NOZZLE HOLDER (HOLDER BODY) TO 002 017 40 21,002 017 34 21, TO NOZZLE HOLDER OF MAKE: BOSCH
571
SPACER WASHER1.88 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
571
SPACER WASHER0.88 MM
571
SPACER WASHER1.78 MM, Replaced By: A0040172252
571
SPACER WASHER0.84 MM
571
SHIM, 1.55 MM THICK. SPACER WASHER1.55 MM
571
SPACER WASHER0.80 MM
571
SHIM, 1.15 MM THICK. SPACER WASHER1.15 MM
571
SPACER WASHER1.70 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
571
SPACER WASHER1.20 MM
571
SPACER WASHER1.98 MM
571
SHIM, 1.0 MM THICK. SPACER WASHER1.0 MM
571
SHIM, 1.75 MM THICK. SPACER WASHER1.75 MM
571
SHIM, 1.20 MM THICK. SPACER WASHER1.2 MM
571
SHIM, 1.30 MM THICK. SPACER WASHER1.3 MM
571
SHIM, 1.35 MM THICK. SPACER WASHER1.34 MM, Replaced By: A0030177852
571
SHIM, 1.40 MM THICK. SPACER WASHER , Replaced By: A0030178452
571
SHIM, 1.50 MM THICK. SPACER WASHER1.50 MM, Replaced By: A0030179452
571
SHIM, 1.70 MM THICK. SPACER WASHER , Replaced By: A0040171452
571
SHIM, 1.80 MM THICK. SPACER WASHER1.80 MM, Replaced By: A0040172452
571
SPACER WASHER , Replaced By: A0030179252
571
SPACER WASHER , Replaced By: A0040171252
571
SPACER WASHER1.88 MM, Replaced By: A0040173252
571
SPACER WASHER1.98 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
571
SPACER WASHER1.50 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
571
SPACER WASHER1.08 MM
571
SPACER WASHER1.18 MM
571
SHIM, 1.10 MM THICK. SPACER WASHER1.1 MM
571
SHIM, 1.95 MM THICK. SPACER WASHER1.95 MM
571
SPACER WASHER1.40 MM
571
SHIM, 1.25 MM THICK. SPACER WASHER1.24 MM
571
SPACER WASHER1.80 MM
571
SPACER WASHER0.90 MM
571
SHIM, 1.60 MM THICK. SPACER WASHER1.6 MM
571
SHIM, 1.90 MM THICK. SPACER WASHER1.9 MM
571
SHIM1.34 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
571
SPACER WASHER1.48 MM
571
SHIM, 1.65 MM THICK. SPACER WASHER1.65 MM
571
SPACER WASHER0.98 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
571
SPACER WASHER1.30 MM
571
SPACER WASHER1.58 MM
571
SHIM, 1.45 MM THICK. SPACER WASHER1.45 MM
571
SHIM, 1.85 MM THICK. SPACER WASHER , Replaced By: A0040172852
571
SPACER WASHER1.28 MM
571
SPACER WASHER1.38 MM
571
SHIM, 1.05 MM THICK. SPACER WASHER1.04 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
571
SPACER WASHER1.68 MM
571
SPACER WASHER0.94 MM
574
PRESSURE SPRINGTO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
577
PIN (PRESSURE SPINDLE) TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
580
SPACER WASHERTO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
583
UNION NUT (NOZZLE RETAINING NUT) TO 002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
586
NOZZLE (NOZZLE NEEDLE), TO NOZZLE HOLDER OF MAKE: BOSCH
589
SEAL RING
999
COVER
999
SPRING WASHER , Replaced By: N000137008212
999
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
