Поз.
Артикул
Описание
5
ALTERNATOR80 A, BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
10
SCREW DRIVE END BEARING,COMMUTATOR BEARING
10
SCREW , Replaced By: A0019900921
20
BALL BEARING , Replaced By: A0079818925
20
BALL BEARING DRIVE END BEARING BOSCH
25
BALL BEARING SLIP RING SIDE
25
BALL BEARING , Replaced By: A0089814625
35
RECTIFIER , Replaced By: A0011542716
35
RECTIFIER , Replaced By: A0011541516
35
RECTIFIERTO 005 154 34 02
40
SCREW T-FITTING TO BRACKET M4X25
45
CONDENSER
50
SCREW
55
SPRING WASHER AT GENERATOR TERMINAL D+, 010,10/50 UP TO CHASSIS 066175,010,12/52 UP TO CHASSIS 067208 EXCEPT FOR 067205,010,20/60 UP TO CHASSIS 065672,010,22/62 UP TOCHASSIS 068683 012,10/50 UP TO CHASSIS 151591 EXCEPT FOR,SEE FOOTNOTE 074,012,12/52 UP TO CHASSIS 153776 EXCEPT FOR 153758,153760,153771 012,20/60 UP TO CHASSIS 148879 EXCEPT FOR 148827,148837,148844,148850,148852,012,22/62 UP TO CHASSIS 158113
60
GASKET
65
REGULATORTO 007 154 26 02
65
REGULATOR AND CUT-OUT , Replaced By: A0001541805
65
REGULATOR AND CUT-OUTTO 005 154 32 06
70
CARBON BRUSH SETTO 007 154 27 02
75
SCREW REGULATOR AND CUT-OUT TO 008 154 02 02/ 06 02/ 11 02/ 15 02
83
SPRING
90
FAN
95
PULLEYTO A 009 154 44 02, BOSCH
95
PULLEY , Replaced By: A0011551215
95
PULLEY , Replaced By: A6041550015
100
WASHER
110
NUT PULLEY TO ALTERNATOR
400
ALTERNATOR , Replaced By: A0101544702
410
SCREW COVER PLATE TO DRIVE BEARING M4X20
415
BALL BEARING DRIVE END BEARING BOSCH
415
BALL BEARING , Replaced By: A0079818925
420
BALL BEARING , Replaced By: A0079817325
420
BALL BEARING SLIP RING SIDE BOSCH
425
RING SLIP RING SIDE
430
REGULATOR AND CUT-OUTTO 008 154 52 02
435
SCREW-AND-WASHER ASSEMBLY. COMBINATION BOLT
450
COVER FOR ALTERNATOR: 70A/90A, BOSCH
450
COVER , Replaced By: A0001543404
455
SCREW COVER BOSCH
460
SCREW HOUSING M5X47, BOSCH
500
PULLEYTO A 009 154 44 02, BOSCH
500
PULLEY , Replaced By: A6041550015
510
NUT PULLEY TO ALTERNATOR
999
NUT TACHOGRAPH TO BRACKET
