Mercedes N304017008034 - Болт крепления

O 405 N 612.417

42 BRAKES - 001 AUTOMATIC CENTRAL LUBRICATION IL.2

Поз.
Артикул
Описание
42
A6125010001
RADIATOR WATER AKG
44
A6125010101
RADIATOR (CHARGING AIR INTERCOOLER) AKG
46
A6125200341
BRACKET LEFT
48
A6125200441
BRACKET RIGHT
64
N304017008034
SCREW BRACKET TO CROSS CONNECTION STRUT
72
N000125008443
WASHER EXHAUST MUFFLER TO STRAP
80
N912004008102
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
88
N304032008006
NUT
96
A3575000632
STAY RADIATOR
104
A3575000232
STAY RADIATOR
112
A3575000132
STAY RADIATOR
120
A0009884211
BUFFER BEARING BRACKET TO BRACKET
128
N000960012345
SCREW
136
N910113012002
NUT SUPPORT TO SIDE MEMBER
152
N000933008145
SCREW CLAMP TO BRACKET AND TO PIPE
160
N910113008003
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
230
A6125013624
COOLING WATER PIPE (COOLING WATER LINE) FROM THERMOSTAT TO RADIATOR
999
A3575000027
SUPPORT FAN SUPPORT, NOT USED TO BE ADAPTED DURING ASSEMBLY
999
A3575012701
RADIATOR WATER
