Mercedes N304017008021 - АВТОЗАПЧАСТЬ

O 404 618.113

25 CLUTCH - 001 HOLDER FOR HYDRAULIC LINES

Поз.
Артикул
Описание
90
A3568201042
ELECTRIC MOTOR. WIPER MOTOR
94
A0028202941
CRANK AT MOTOR
94
A0008242906
CRANK
98
A0089977481
GROMMET BETWEEN ELECTRIC MOTOR & BRACKET
102
N000912010038
CYLINDRICAL HEAD SCREW. SCREWTO 005 250 02 04, 03 04, 04 04
106
N304017008021
SCREW PIPE CLAMP
110
A0028203241
LINKAGE LEFT
114
A0028203041
LINKAGE CENTRAL
118
A0028203141
LINKAGE RIGHT
122
A0008208646
BEARING. WIPER BEARING LEFT
126
A0008208746
BEARING CENTRAL
130
A0008208546
BEARING. WIPER BEARING RIGHT
134
A3568200546
BEARING PARTS KIT,WIPER BEARING
142
A3568200640
WIPER ASSEMBLY RIGHT
142
A3568200540
WIPER ASSEMBLY LEFT
146
A0008209945
WIPER BLADE
150
N000934006007
NUT BALL PIVOT TO LEVER
154
A0004290640
BRACKET ELECTRIC CABLE MOUNTING
999
A3056120214
CROSS MEMBER , TO BE ADAPTED DURING ASSEMBLY 305 612 02 14 RECTANGULAR TUBE 40 X 30 X 2 X 2430 MM
999
A3568902514
BRACKET
999
A3568902614
BRACKET
999
A3568991714
BRACKET
999
A3568991814
BRACKET
999
A3568991914
BRACKET
