Поз.
Артикул
Описание
8
BRACKET AT FRAME
11
BRACKET AT FRAME,088432
23
BRAKE PRESSURE REGULATOR , Replaced By: A6314310112
26
SCREW , Replaced By: N304017006016
29
WASHER , Replaced By: N009021006208
32
BRAKE BOOSTER
35
SEAL RING MASTER CYLINDER TO BRAKE BOOSTER
38
REPAIR KIT BRAKE BOOSTER
41
BRAKE MASTER CYLINDER
44
SEAL RING MASTER CYLINDER TO BRAKE BOOSTER
46
VALVE PARTS KIT
48
GROMMET FROM RESERVOIR TO MASTER CYLINDER
48
GROMMET FROM RESERVOIR TO MASTER CYLINDER
113
COVERING
116
NUT COVERING TO FRAME
119
SCREW , Replaced By: N304017008039
122
WASHER BRACKET TO LEFT SIDE MEMBER
125
SCREW BRACKET ON LOAD SENSOR
128
WASHER , Replaced By: N009021006208
128
WASHER , Replaced By: N009021006208
131
EDGE GUARD SECTION AIR INTAKE COVERING 400 MM, ORDER BY THE METER
999
RELAY (ENGINE RELAY) TO 001 431 80 12
999
RELAY SOLENOID VALVE TO 001 431 80 12
999
LOOM TIE LINE MOUNTING 280 MM
999
CLAMP BRAKE LINE MOUNTING
999
FRAME
999
FRAME
999
FRAME
999
RUBBER PAD BRAKE LINE MOUNTING
999
BRAKE PRESSURE REGULATOR HYDRAULIC UNIT
999
CLAMP , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. 097945, Replaced By: A4639940148
999
LOOM TIE
999
LOOM TIE SENSOR CABLE TO BRAKE HOSE
999
LOOM TIE SENSOR CABLE TO BRAKE HOSE
999
LOOM TIE SENSOR CABLE TO BRAKE HOSE
