Mercedes A6328852714 - HALTER UT

TRAVEGO 15 SHD 2 - ACHSER 632.285

88 ATTACHMENT PARTS - 060 FRONT BUMPER IL. 3

Поз.
Артикул
Описание
256
A6328800283
RADIATOR GRILLE SHELLLOGO
256
A6328800483
COVERLOGO
259
A6328800851
SUPPORTING FRAME
262
A2158880086
MERCEDES STAR PROXIMITY-CONTROLLED CRUISE CONTROL
265
N910143008000
SCREW SPEED SENSOR TO REAR AXLE
268
A6328851214
BRACKET INSIDE BOTTOM RIGHT
271
N000000002925
HEXALOBULAR BOLT FASTENING RADIO SET 4X12
274
A6328852614
BRACKET TOP
274
A6328854514
BRACKET TOP
277
A6328852714
BRACKET BOTTOM
277
A6328854614
BRACKET BOTTOM
286
A0009906256
NUT
304
A1648880411
BASE PLATE
307
N910143006000
SCREW CONDENSER TO CHARGE AIR INTERCOOLER M6 X 12
999
A0009908902
SCREW. HEXAL. SOCKET CSK. BOLTM8X30
999
A0009982546
DAMPING DISK
999
A0019878440
RUBBER BUFFER TO GLASS PANE,BOTTOM
999
A0019896598
SEALING STRIP , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
999
A6298854114
BRACKET
999
A6328801251
SUPPORTING FRAME
999
N000000000460
SHEET METAL SCREW BRACKET TO FLOOR PLATE
999
N910105008038
SCREW BUMPER TO REAR CROSS MEMBER M 8X50
999
N910112008000
HEXAGON NUT. NUT BRACKET TO CAB REAR PANEL
