Поз.
Артикул
Описание
3
SUPPORT FRONT
6
SUPPORT APPARATUS SUPPORT,REAR
7
SUPPORT APPARATUS SUPPORT TO SIDE MEMBER,REAR
20
SCREW SUPPORT TO SIDE MEMBER M 14X45
20
SCREW , Replaced By: N308676014012
62
SUPPORT AIR RESERVOIR TO RIGHT SIDE MEMBER, INSIDE
68
SCREW SUPPORT TO SIDE MEMBER M 14X120, TO BE ADAPTED DURING ASSEMBLY
70
NUT STEERING SUPPORT TO FRAME
70
NUT , Replaced By: N910113014000
86
RESERVOIR COMPRESSED AIR 10/10 L
86
RESERVOIR6/20 L
86
RESERVOIR6/20 L
87
RESERVOIR30L,246 MM,12.5 BAR
87
RESERVOIR SERVICE BRAKE 30 L, Replaced By: A0034321801, +001A6554320073
88
LINE FROM AIR RESERVOIR I TO AIR RESERVOIR II
89
UNION NUT LINE CONNECTION
89
UNION NUT LINE CONNECTION, Replaced By: N000000006239
90
SEAL CONE LINE CONNECTION
90
GLAND , Replaced By: A0019901967
91
SUPPORT AIR RESERVOIR TO FRAME
97
SUPPORT PNEUMATIC-SUSPENSION AIR-RESERVOIR
97
SUPPORT , Replaced By: A6994320216
97
SUPPORT PNEUMATIC-SUSPENSION AIR-RESERVOIR
99
BRACKET AIR RESERVOIR TO APPARATUS SUPPORT
100
BRACKET REAR AIR RESERVOIR, NOT USED
102
BRACKET APPARATUS SUPPORT
108
SCREW BRACKET TO SIDE MEMBER
108
SCREW , Replaced By: N304017010002
110
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
112
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
112
SCREW , Replaced By: N308676012012
114
SCREW EXHAUST PIPE TO BRACKET
114
SCREW , Replaced By: A4609900601
116
WASHER BRACKET TO COVERING
116
WASHER , Replaced By: N009021010209
118
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
118
NUT , Replaced By: N913004008001
118
NUT STRAP TO BRACKET
118
NUT , Replaced By: N910113010000
120
HEXAGON NUT EXHAUST PIPE TO BRACKET ON SIDE MEMBER
120
NUT , Replaced By: N910113012003
122
SUPPORT AIR RESERVOIR TO FRAME
124
SUPPORT AT BRACKET
126
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
126
SCREW , Replaced By: N304017008027
126
SCREW BRACKET TO FRAME M 12X35
126
SCREW PIPE CLAMP
126
SCREW , Replaced By: N304017008021
129
SCREW END PIECE TO EXHAUST PIPE M 10X25
130
SCREW CONSOLE TO SIDE MEMBER
131
NUT STRAP TO BRACKET
131
NUT , Replaced By: N910113010000
132
NUT SUPPORT TO SIDE MEMBER
133
SCREW BEARING BRACKET TO REAR AXLE M 16X1.5X50
133
SCREW , Replaced By: N308676016007
133
SCREW SUPPORT TO SIDE MEMBER M 14X45
133
SCREW , Replaced By: N308676014012
134
SCREW SUPPORT TO SIDE MEMBER M 14X45
134
SCREW , Replaced By: N308676014012
135
NUT CONSOLE TO SUPPORT
135
NUT , Replaced By: N910113016001
135
NUT STEERING SUPPORT TO FRAME
135
NUT , Replaced By: N910113014000
136
NUT STEERING SUPPORT TO FRAME
136
NUT , Replaced By: N910113014000
138
SCREW PIPE CLAMP
138
SCREW , Replaced By: N304017008021
138
SCREW , Replaced By: N304017008034
138
SCREW BRACKET TO CROSS CONNECTION STRUT
138
SCREW , Replaced By: N304017008034
138
SCREW , Replaced By: N304017008034
140
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
140
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
140
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
140
NUT , Replaced By: N913004008001
142
PAD AIR RESERVOIR TO BRACKET
143
SCREW BRACKET TO SIDE MEMBER
143
SCREW , Replaced By: N304017008040
144
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
144
NUT , Replaced By: N913004008001
148
STRAP AIR RESERVOIR TO BRACKET
148
STRAP PARTICLE FILTER
148
STRAP , Replaced By: A6554900942
148
STRAP , Replaced By: A6214900242
170
T-FITTING AIR RESERVOIR,CONNECTION: "31"
175
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
180
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
185
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
999
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
