Поз.
Артикул
Описание
119
GUIDE BUSHING TWO-WAY VALVE TO FRAME
124
SCREW 3/2-WAY VALVE TO BRACKET
124
SCREW , Replaced By: N304014008009
129
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
129
NUT , Replaced By: N913004008001
134
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
139
SEAL RING LINE CONNECTION
144
INSULATING HOSE PRESSURE REGULATOR,CONNECTION "3", ORDER BY THE METER5 148812
149
CLAMP COMPRESSED AIR LINE TO BRACKET
154
BATTERY SUPPORT
159
GUIDE BUSHING TWO-WAY VALVE TO FRAME
164
BRACKET FUEL LINE TO BELL HOUSING
169
BRACKET PARTICLE FILTER
174
BRACKET APPARATUS SUPPORT
179
SCREW BRACKET TO FRAME SIDE MEMBER
184
NUT END PIECE TO EXHAUST PIPE
189
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
194
NUT STRAP TO BRACKET
194
NUT , Replaced By: N910113010000
199
CONSOLE BATTERY/APPARATUS SUPPORT,FRONT
204
SCREW BRACKET TO CAB CONSOLE,K 035197
204
SCREW BRACKET TO SIDE MEMBER
209
SCREW BRACKET TO CAB CONSOLE M14X1.5X40
214
LOCK WASHER BRACKET TO SIDE MEMBER,5 703114
219
NUT BRACKET TO SIDE MEMBER
219
NUT , Replaced By: N910113014001
224
STRAP AIR RESERVOIR TO BRACKET
229
SUPPORT ROCKER PANEL
234
SCREW END PIECE TO EXHAUST PIPE M 10X25
239
NUT STRAP TO BRACKET
239
NUT , Replaced By: N910113010000
244
BATTERY SUPPORT
249
SCREW PROPELLER SHAFT BEARING TO CROSS MEMBER
254
WASHER RADIATOR TO RUBBER MOUNTING
259
HEXAGON NUT
259
NUT , Replaced By: N910113010002
264
SPACER TUBE BATTERY SUPPORT TO FRAME 33 MM
269
SPACER TUBE BATTERY SUPPORT TO SPRING BRACKET AND TO STEERING INTERMEDIATE BRACKET 6.5 MM,5 GRAD 20'
274
SPACER TUBE BATTERY SUPPORT TO SPRING BRACKET AND TO STEERING INTERMEDIATE BRACKET 61 MM,5 GRAD 20'
279
SCREW SUPPORT TO SIDE MEMBER M 14X120, TO BE ADAPTED DURING ASSEMBLY
284
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
284
WASHER , Replaced By: N000125015019
289
NUT STEERING SUPPORT TO FRAME
289
NUT , Replaced By: N910113014000
294
HEXAGON HEAD BOLT. SCREW TORSION BAR TO BRACKET
294
SCREW , Replaced By: N308765016004
299
WASHER BRACKET TO FRAME
299
WASHER , Replaced By: N000125017016
304
NUT CONSOLE TO SUPPORT
304
NUT , Replaced By: N910113016001
309
SCREW SUPPORT TO SIDE MEMBER M 14X120, TO BE ADAPTED DURING ASSEMBLY
314
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
314
WASHER , Replaced By: N000125015019
319
NUT STEERING SUPPORT TO FRAME
319
NUT , Replaced By: N910113014000
999
WASHER ADJUSTER
999
VALVE , Replaced By: A0044293144
999
FITTING , Replaced By: A0009977172
999
SEAL RING , Replaced By: A0149972247
999
VALVE , Replaced By: A0044293144
999
VALVE , Replaced By: A0044293244
999
SPACER TUBE , Replaced By: A3094310249
999
STRAP SERVICE BRAKE AIR RESERVOIR, Replaced By: A6204300040
999
BRACKET , Replaced By: A6454310740
999
BRACKET , Replaced By: A4255530840
999
STRAP , Replaced By: A3464300540
999
BRACKET , Replaced By: A6204910141
