Поз.
Артикул
Описание
5
FENDER REAR WHEEL 660X600,5 952572
5
FENDER REAR WHEEL 660X660,5 952572
20
BRACKET FENDER
30
CLAMPING PIECE
35
RIVET
45
SCREW
50
NUT
60
REINFORCEMENT FENDER
65
SCREW BRACKET TO REAR FENDER
70
WASHER COMPRESSED AIR LINE TO BRACKET
70
WASHER , Replaced By: N009021006208
75
NUT , Replaced By: N913004006001
75
NUT PUMP TO BRACKET
85
BEARING BRACKET FENDER
95
BEARING BRACKET TAIL LAMP AND FENDER,RIGHT,K 164363
95
BEARING BRACKET TAIL LAMP AND FENDER,LEFT,K 164364
95
BEARING BRACKET TAIL LAMP AND FENDER,RIGHT,K 164364
95
BEARING BRACKET TAIL LAMP AND FENDER,LEFT,K 164363
95
BEARING BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 134427, Replaced By: A6525220192
95
BEARING BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 134427, Replaced By: A6525220092
100
SCREW , Replaced By: N308765018001
100
SCREW BEARING BRACKET TO SIDE MEMBER M 18X1,5X90,K 164364
100
FITTED SCREWM 18X19X57X85
105
SCREWM 18X18X33X55
105
SCREW BEARING BRACKET TO SIDE MEMBER M 18X1,5X45
110
WASHER BEARING BRACKET TO SIDE MEMBER,K 164363
115
LOCK WASHER BELL HOUSING TO TRANSMISSION
120
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
120
NUT TORSION BAR TO BEARING BRACKET,5 904661
120
NUT , Replaced By: N910113018004
125
SCREW , Replaced By: N304017010053
125
SCREW , Replaced By: N304017010002
125
SCREW , Replaced By: N304017010030
125
SCREW EXHAUST PIPE TO BRACKET
125
SCREW HOLLOW RUBBER SPRING TO CAB,5 956657
125
SCREW BRACKET TO SIDE MEMBER
125
SCREW PIPE ELBOW TO BRACKET M 10X50
130
NUT STRAP TO BRACKET
130
NUT , Replaced By: N910113010000
135
BRACKET , Replaced By: A6525222040
135
BRACKET FRONT AXLE II,RIGHT
140
BRACKET LEFT AND RIGHT,5 453765
140
BRACKET , Replaced By: A3935220140
145
EXPANSION PLUG BRACKET
150
SCREW RADIATOR M 10X45
155
SCREW VALVE TO BRACKET
155
SCREW VALVE TO BRACKET, Replaced By: N304014008002
160
NUT , Replaced By: N910113010000
160
NUT STRAP TO BRACKET
165
NUT , Replaced By: N913004008001
165
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
NUT STRAP TO BRACKET
999
SCREW UNDERRUN PROTECTION AND BRACKET TO FRAME
999
SCREW , Replaced By: N304017010055
999
WASHER , Replaced By: A3143220176
999
SCREW , Replaced By: N304017010050
999
SCREW , Replaced By: N304017010050
999
BRACKET ,K 104588
999
FENDER REAR AXLE,5 952573
999
CLAMPING PIECE BRACKET TO BEARING BRACKET,K 274033
999
CLAMPING PIECE , Replaced By: A6555220120
999
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6525222040
999
BRACKET , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A6525222040
999
BRACKET , Replaced By: A3935220140
999
BRACKET RIGHT
999
FENDER , TO BE ADAPTED DURING ASSEMBLY
999
FENDER REAR WHEEL,5 952573
999
WASHER FENDER BRACKET TO FENDER, Replaced By: A0049902582
999
WASHER BRACKET TO FENDER,K 104588
999
WASHER BEARING BRACKET ON BEARING BRACKET FOR LONGITUDINAL CONTROL ARM,K 103912
999
WASHER , Replaced By: A3143220276
999
SCREW , Replaced By: A1119900029
999
SCREW BRACKET TO FENDER,K 104588
