Поз.
Артикул
Описание
5
FENDER REAR AXLE
5
FENDER REAR AXLE,5 952572
5
FENDER REAR AXLE,5 952573
10
BRACKET FENDER TO BRACKET, Replaced By: A6205204341
10
BRACKET FENDER TO BRACKET
15
RIVET
20
SCREW
25
CLAMPING PIECE
30
NUT
35
SCREW SUPPORTING RAIL TO SUPPORT,5 429712
40
NUT , Replaced By: N913004006001
40
NUT PUMP TO BRACKET
45
REINFORCEMENT FENDER FIXTURE 505 MM
45
REINFORCEMENT FENDER FIXTURE 525 MM
45
REINFORCEMENT FENDER FIXTURE 500 MM
45
REINFORCEMENT FENDER FIXTURE 536 MM
90
SCREW BRACKET TO REAR FENDER
90
SCREW BRACKET TO FENDER,5 952572
100
WASHER , Replaced By: N009021006208
100
WASHER COMPRESSED AIR LINE TO BRACKET
105
NUT , Replaced By: N913004006001
105
NUT PUMP TO BRACKET
110
COVERING
115
RIVET BINDING RAIL TO COVERING
120
RIVET BRACKET TO BINDING RAIL
125
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
125
WASHER COMPRESSED AIR LINE TO BRACKET
140
BRACKET COVERING TO SEMIMONOCOQUE WING
145
SCREW COVERING TO SEMIMONOCOQUE WING
150
SPACER TUBE COVERING TO SEMIMONOCOQUE WING, TO BE ADAPTED DURING ASSEMBLY
155
WASHER COMPRESSED AIR LINE TO BRACKET
155
WASHER , Replaced By: N009021006208
160
NUT , Replaced By: N913004006001
160
NUT PUMP TO BRACKET
275
BEARING BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 134427, Replaced By: A6525220192
275
BEARING BRACKET , FIRST EXHAUST STOCK OF OLD PARTS UP TO IDENT NO. K 134427, Replaced By: A6525220092
275
BEARING BRACKET TAIL LAMP AND FENDER,LEFT,K 164364
275
BEARING BRACKET TAIL LAMP AND FENDER,RIGHT,K 164363
275
BEARING BRACKET TAIL LAMP AND FENDER,RIGHT,K 164364
275
BEARING BRACKET TAIL LAMP AND FENDER,LEFT,K 164363
290
FITTED SCREWM 18X19X57X85
290
FITTED SCREW BEARING BRACKET ON BEARING BRACKET FOR LONGITUDINAL CONTROL ARM M 18X1,5X90,K 164364
295
WASHER , Replaced By: A3143220176
295
WASHER , Replaced By: A3143220276
295
WASHER BEARING BRACKET ON BEARING BRACKET FOR LONGITUDINAL CONTROL ARM,K 103912
295
WASHER BEARING BRACKET TO SIDE MEMBER,K 164363
300
NUT TORSION BAR TO BEARING BRACKET,5 904661
300
NUT , Replaced By: N910113018004
300
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
305
SCREWM 18X18X33X55
305
SCREW BEARING BRACKET TO SIDE MEMBER M 18X1,5X45
310
LOCK WASHER BELL HOUSING TO TRANSMISSION
325
BRACKET LEFT AND RIGHT,5 453765
325
BRACKET RIGHT
350
SCREW RADIATOR M 10X45
355
NUT STRAP TO BRACKET
355
NUT , Replaced By: N910113010000
360
SCREW VALVE TO BRACKET, Replaced By: N304014008002
360
SCREW VALVE TO BRACKET
365
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
365
NUT , Replaced By: N913004008001
365
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
999
CLAMPING PIECE BRACKET TO BEARING BRACKET,K 274033
999
CLAMPING PIECE , Replaced By: A6555220120
999
BRACKET FENDER TO BRACKET
999
BRACKET COVERING
999
BINDING RAIL COVERING
