Поз.
Артикул
Описание
5
FASTENER (CENTRAL LOCK) CAB LOCKING MECHANISM
8
ROD CAB LOCKING MECHANISM, TO BE ADAPTED DURING ASSEMBLY
8
ROD CENTRAL LOCK
8
ROD CENTRAL LOCK
11
PIN PULL TO FASTENER
14
WASHER BRACKET TO CROSS MEMBER
17
LOCK , Replaced By: N912002008003
17
LOCK PULL TO FASTENER
20
CONSOLE CENTRAL LOCK
23
SCREW CENTRAL LOCK TO CAB M 10X16
23
SCREW END PIECE TO EXHAUST PIPE M 10X25
26
WASHER , Replaced By: N000125010532
26
WASHER RADIATOR TO RUBBER MOUNTING
29
NUT , Replaced By: N910113010000
29
NUT STRAP TO BRACKET
999
NUT , Replaced By: N913004008001
999
SPRING WASHER LEVER MOUNTING
999
SCREW BUSHING AND LEVER TO CAB
999
CLAMPING SLEEVE , Replaced By: N001481005039
999
CLAMPING SLEEVE ROD TO BRACKET
999
CLAMPING SLEEVE LEVER MOUNTING
999
PIN LEVER TO ROD
999
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
999
WASHER , Replaced By: N000125015019
999
COTTER PIN LEVER TO ROD
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
LEVER CAB LOCKING MECHANISM,5 287191
999
LEVER CAB LOCKING MECHANISM
999
LEVER CAB LOCKING MECHANISM
999
LEVER CAB LOCKING MECHANISM
999
HANDLE CAB LOCKING MECHANISM
999
BRACKET ROD THRU CAB
999
SEAL ROD THRU CAB
999
GUIDE SIGN DANGER AREA IN FRONT OF TILTED CAB
999
GUMMED LABEL CAB LOCKING MECHANISM
999
BUSHING LEVER TO CAB
999
RIVET BUSHING AND LEVER TO CAB
