Поз.
Артикул
Описание
4
PIPE
4
LINE FROM AIR COMPRESSOR TO PRESSURE REGULATOR 18X1,5 MM, LENGTH AVAILABLE: 3000 MM
4
PIPE , Replaced By: A0004291501
9
HOSE FROM BUBBLE SEPARATOR TO HEATING PIPE 18X27 MM, ORDER BY THE METER
9
HOSE HEAT EXCHANGER II FEED
14
HOSE (HEATING LINE) FROM ENGINE TO HEATER,FEED, 962133 N 000001 P 000001
14
HOSE FROM PUMP TO HEATING WATER PIPE,504534
14
HOSE HEAT EXCHANGER II RETURN
14
HOSE PIPE LINE TO CONNECTION FITTING AND TO PRESSURE REGULATOR
19
PIPE , Replaced By: A0004291501
20
HOSE HEAT EXCHANGER II RETURN
21
PIPE HEAT EXCHANGER II RETURN
22
HOSE FROM BUBBLE SEPARATOR TO HEATING PIPE 18X27 MM, ORDER BY THE METER
59
GROMMET , UP TO CHASSIS 603580 ON SPECIAL REQUEST, SEPARATE BRAKE FLUID RESERVOIR FOR HYDRAULIC BRAKE
59
GROMMET LINE PASSAGE AT SIDE MEMBER 24 MM,5 473494
69
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
69
CLAMP , Replaced By: N000000000667
74
CLAMP BRAKE HOSE BRACKET
75
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
75
SCREW LICENSE PLATE TO BRACKET
75
SCREW , WITH DIESEL ENGINE
76
NUT SPRING-LOADED PUSH ROD
76
NUT HEATING PIPE TO BRACKET
77
WASHER SWITCH TO FIRE WALL
87
SPACER TUBE REFRIGERANT LINE TO CAB
90
BRACKET TAIL PIPE
999
HOSE RETURN LINE THRU SUBSTRUCTURE
