Поз.
Артикул
Описание
5
SIGN BOX WINDSHIELD
5
SIGN BOX WINDSHIELD
16
FLUORESCENT TUBE WHITE 30 W
16
FLUORESCENT TUBE WHITE 36 W
17
CRANK
17
CRANK
19
GLASS PANE
19
GLASS PANE
20
RIM
21
SOCKET FLOURESCENT TUBES 24V / 8W
21
SOCKET FLOURESCENT TUBES 24V / 36W
21
SOCKET FLOURESCENT TUBES 24V / 36W
37
SUPPORT SIGN BOX, AS OF PRODUCTION BREAKPOINT DATE 03.05.01
37
SUPPORT SIGN BOX, UNTIL PRODUCTION BREAKPOINT DATE 02.05.01
43
CONSOLE
43
CONSOLE
45
SPACER COWL TOP MOUNTED SIGN BOX
47
HEXAGON HEAD BOLT. SCREW CONSOLE TO COWL AND TO ROOF
47
HEXAGON HEAD BOLT. SCREW CONSOLE TO COWL AND TO ROOF
51
WASHER PLUG SOCKET TO BRACKET
51
WASHER PLUG SOCKET TO BRACKET
55
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
56
NUT SPRING-LOADED PUSH ROD
56
NUT
56
NUT
56
NUT
59
CONTROL UNIT , Replaced By: A0028271045
61
ELECTRIC CABLE
61
ELECTRIC CABLE
61
ELECTRIC CABLE
61
ELECTRIC CABLE
63
BRACKET
65
WASHER
67
NUT
155
INSERT TYPE SIGN
155
INSERT TYPE SIGN
158
PIN
159
RETAINING ROPE385 MM, AS OF PRODUCTION BREAKPOINT DATE 03.05.01
159
RETAINING ROPE169 MM, AS OF PRODUCTION BREAKPOINT DATE 03.05.01
161
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
176
PAD INSERT TYPE SIGN
182
RUBBER MOULDING , ORDER BY THE METER TO BE ADAPTED DURING ASSEMBLY
