Поз.
Артикул
Описание
10
WATER COOLER
10
WATER COOLER , Replaced By: A0995006203
20
DETENT SPRING COOLANT HOSE, LEFT, TO RADIATOR SCB3646.4MM
30
DETENT SPRING COOLANT HOSE, LEFT, TO RADIATOR SCB3646.4MM
30
DETENT SPRING FILLING HOSE TO RADIATOR SCB1727MM
40
DRAIN PLUG DRAIN PLUG
40
DRAIN PLUG DRAIN PLUG
100
CONDENSER , Replaced By: A2045000654
100
CAPACITOR
110
BRACKET LEFT AND RIGHT CONDENSER
120
PRESSURE SENSORM 10, Replaced By: A2110000283
120
PRESSURE SENSOR
125
REFRIGERANT DRIER F AC
130
RADIATOR BEARING REPAIR SOLUTION, COOLER, BOTTOM LEFT AND RIGHT
140
ELASTOMER BEARING RADIATOR BOTTOM
140
RUBBER MOUNT BOTTOM LEFT & RIGHT
140
ELASTOMER BEARING RADIATOR BOTTOM, Replaced By: A0995040212
150
BEARING TOP LEFT AND RIGHT, J 06236120041209
160
CLIP RADIATOR TOP
200
FAN SHROUD TOP
210
CATCH COVERING TO COVERING
220
COVER ON FAN SHROUD
240
AIR BAFFLE TOP
240
AIR DUCT TOP
260
BLOWER400W
260
BLOWER600W, Replaced By: A2049066802
260
BLOWER
260
BLOWER600 W
270
VACUUM BOX
280
HOSE LINE FROM VACUUM BOX TO INTAKE MANIFOLD
280
HOSE ASSEMBLY FROM VACUUM BOX TO INTAKE MANIFOLD
300
AIR BAFFLE BOTTOM
300
AIR DUCT
910
CLUTCH. PIN BUSHING HOUSING SIREN
920
HOUSING ENGINE HOOD SWITCH ANTI-THEFT ALARM SYSTEM 2-PIN MLK1.2,S62
920
PIN BUSHING HOUSING ENGINE CABLE HARNESS PLUG-CONNECTION 4-PIN SLK2.8, LSK8,X26/29
930
HOUSING ENGINE HOOD SWITCH ANTI-THEFT ALARM SYSTEM 2-PIN MLK1.2,S62
