Поз.
Артикул
Описание
25
CROSS MEMBER CENTRAL BEARING NO.5,5 295723
70
BEARING BRACKET CENTRAL BEARING, TO BE ADAPTED DURING ASSEMBLY
70
BEARING BRACKET , Replaced By: A6583250509
75
BRACKET CONTROL ARM,FRONT, 415,416 5 295723 417 5 3074165 557246
75
BEARING BRACKET CONTROL ARM
80
BEARING BRACKET CONTROL ARM
80
BEARING BRACKET CONTROL ARM,REAR,5 009667
85
SPACER TUBE
90
SCREW SHOCK ABSORBER TO RAIL
95
WASHER BRACKET TO SPARE WHEEL CARRIER
100
NUT TORSION BAR TO BEARING BRACKET,5 904661
105
SHIM BEARING BRACKET TO CROSS MEMBER,5 295723
110
SCREW , Replaced By: A0089909101
110
SCREW , Replaced By: N000960018109
110
SCREW , Replaced By: A0039909304
110
SCREW , Replaced By: N308676018009
110
SCREW ENGINE MOUNTING AND BRACKET TO BELL HOUSING SUPPORTING ARM M 18X80
110
SCREWM 18X18X33X55
110
SCREW THRUST ARM TO SPRING BRACKET
110
SCREW THRUST ARM TO BEARING BRACKET ON AXLE M 18X105,K 072849
110
SCREW SUPPORTING ARM TO BELL HOUSING M 18X60
110
SCREW SUPPORTING ARM TO BELL HOUSING M 18X60
110
SCREW FRONT SPRING TO SPRING BRACKET M 18X1.5X150
115
NUT TORSION BAR TO BEARING BRACKET,5 904661
115
NUT , Replaced By: N910113018004
115
NUT BEARING BRACKET TO SIDE AND CROSS MEMBERS
115
NUT INTERMEDIATE LEVER TO STEERING SUPPORT
125
GUSSET PLATE BOTTOM LEFT
130
GUSSET PLATE BOTTOM RIGHT
135
CROSS MEMBER (REAR CROSS MEMBER), TO BE ADAPTED DURING ASSEMBLY
140
CROSS MEMBER (REAR CROSS MEMBER)
145
REINFORCEMENT REAR CROSS MEMBER
150
BRACKET TAIL AND LICENSE PLATE LAMPS
155
SCREW , Replaced By: N308676014008
155
SCREW MOUNTING TO CONSOLE M 14X35
155
SCREW MOUNTING TO CONSOLE M 14X35
160
SCREW SUPPORT TO SIDE MEMBER M 14X45
160
SCREW , Replaced By: N308676014012
165
NUT , Replaced By: N910113014000
165
NUT STEERING SUPPORT TO FRAME
165
NUT STEERING SUPPORT TO FRAME
999
CROSS MEMBER , Replaced By: A6233100146
999
BEARING BRACKET , Replaced By: A6583250109, +002A6583250053, +002N000960018142, +002N007349019002, +002N913004018004
999
BEARING BRACKET ,5 557245, Replaced By: A6553120240, +002N000960018013, +001N000960018023, +001N000960018062
