Поз.
Артикул
Описание
101
BRACKET FRAME MOUNTED CABLE HARNESS TO CAB
103
RIVET BRACKET TO CAB
105
BRACKET BREATHER LINE TO SIDE MEMBER
107
SCREW , Replaced By: N304017008034
107
SCREW BRACKET TO CROSS CONNECTION STRUT
109
NUT , Replaced By: N913004008001
111
BRACKET , Replaced By: A0005462243
111
BRACKET CABLE HARNESS MOUNTING
113
BRACKET ALTERNATOR BRANCH-OFF TO ALTERNATOR SA 24 439/03/04
115
SPACER TUBE ALTERNATOR BRANCH-OFF TO ALTERNATOR SA 24 439/03/04
117
SPRING WASHER ALTERNATOR CONNECTION D+
119
NUT TACHOGRAPH TO BRACKET
121
SPRING WASHER , Replaced By: N000137008204
121
SPRING WASHER , Replaced By: N000137008212
121
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
121
SPRING WASHER ELECTRIC CABLE TO ALTERNATOR
121
SPRING WASHER HEATER PLUG CABLE HARNESS
121
SPRING WASHER ALTERNATOR CONNECTION D+
121
SPRING WASHER ALTERNATOR CONNECTION W
121
SPRING WASHER LICENSE PLATE TO BRACKET
123
NUT
123
NUT BOOT TO AIR DUCT AND TO AIR CLEANER
123
NUT TACHOGRAPH TO BRACKET
123
NUT BALL PIVOT TO LEVER
125
SCREW CONTROL UNIT TO CAB
127
NUT TWO-WAY VALVE TO BRACKET
129
WASHER , Replaced By: N000125008443
129
WASHER EXHAUST MUFFLER TO STRAP
131
BRACKET LINE MOUNTING
131
BRACKET LINE MOUNTING
133
BRACKET CABLE HARNESS
135
SCREW END PIECE TO EXHAUST PIPE M 10X25
137
NUT , Replaced By: N910113010000
137
NUT STRAP TO BRACKET
143
BRACKET , Replaced By: A6735460443
143
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
143
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
145
BRACKET OIL LINE MOUNTING
147
BRACKET BATTERY CABLE TO CROSS MEMBER
149
SCREW BRACKET TO SIDE MEMBER
149
SCREW , Replaced By: N308676012012
149
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
151
SCREW , Replaced By: N304017008027
151
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
153
SCREW , Replaced By: N304017008021
153
SCREW PIPE CLAMP
155
NUT , Replaced By: N910113010000
155
NUT STRAP TO BRACKET
155
NUT SUPPORT TO SIDE MEMBER
155
NUT , Replaced By: N913004008001
157
NUT STRAP TO BRACKET
159
CLAMP BATTERY CABLE TO FRAME SIDE MEMBER NEAR TRANSMISSION
159
CLAMP CABLE HARNESS TO BRACKET
161
CLAMP , Replaced By: A0005462675
163
CLAMP BATTERY CABLE MOUNTING,5 143360
165
SCREW , Replaced By: N304017006026
165
SCREW , Replaced By: N304017006026
167
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
167
WASHER COMPRESSED AIR LINE TO BRACKET
167
WASHER COMPRESSED AIR LINE TO BRACKET
170
NUT , Replaced By: N913004006001
170
NUT PUMP TO BRACKET
170
NUT PUMP TO BRACKET
173
SCREW , Replaced By: N304017008021
173
SCREW PIPE CLAMP
176
WASHER , Replaced By: N009021008213
176
WASHER BRACKET TO LEFT SIDE MEMBER
179
NUT , Replaced By: N913004008001
