Поз.
Артикул
Описание
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE BOSCH
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE KNORR
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE KNORR
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE BOSCH, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
5
BRAKE PRESSURE REGULATOR LOAD-DEPENDING BRAKE WABCO, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
8
REPAIR KIT VALVE BOSCH
8
REPAIR KIT BRAKE POWER REGULATOR BOSCH
8
REPAIR KIT , Replaced By: A0004300207
8
REPAIR KIT COVERING BOSCH
8
REPAIR KIT BRAKE POWER REGULATOR WABCO
11
GUIDE SIGN LOAD-DEPENDING BRAKE,5 307283
11
GUIDE SIGN LOAD-DEPENDING BRAKE,5 936366
14
WASHER EXHAUST MUFFLER TO STRAP
14
WASHER , Replaced By: N000125008443
17
NUT , Replaced By: N913004008001
20
BRACKET BRAKE BOOSTER ASSEMBLIES
20
BRACKET BRAKE POWER REGULATOR
23
SCREW HOLLOW RUBBER SPRING TO CAB,5 956657
23
SCREW LEFT AND RIGHT BEARING BRACKETS TO CAB
23
SCREW , Replaced By: N308676012011
23
SCREW BRACKET TO FRAME
29
NUT STRAP TO BRACKET
29
NUT , Replaced By: N910113010000
29
NUT SUPPORT TO SIDE MEMBER
29
NUT END PIECE TO EXHAUST PIPE
32
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
38
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
41
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
50
LEVER BRAKE POWER REGULATOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
50
LEVER , Replaced By: A6744310039
53
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
56
CONNECTOR PULL ROD TO LEVER
59
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
59
CLAMP , Replaced By: N000000000665
62
CLAMP CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
65
BALL SOCKET BRAKE POWER REGULATOR CONTROL,5 574483
65
BALL SOCKET , Replaced By: A3579910622
65
BALL SOCKET PULL ROD
71
WASHER , Replaced By: N000125008443
71
WASHER EXHAUST MUFFLER TO STRAP
74
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
77
NUT
80
METAL SPRING BELLOWS BRAKE POWER REGULATOR CONTROL,5 557360K 049885
83
SCREW AT ENGINE MOUNTING,TO MOUNT LINES
86
LOCK WASHER FITTING TO BRACKET
89
BRACKET BRACKET TO REAR AXLE HOUSING
92
SCREW BRACKET TO REAR AXLE HOUSING
95
BRACKET OPERATING ROD, TO BE ADAPTED DURING ASSEMBLY
96
BALL PIVOT
101
SPACER RING BRACKET TO REAR AXLE HOUSING
999
REPAIR KIT BRAKE POWER REGULATOR TO 002 431 05 12,KNORR
999
REPAIR KIT BRAKE POWER REGULATOR KNORR
999
SCREW. UNION SCREW LINE CONNECTION
999
SCREW. UNION SCREW LINE CONNECTION
999
ADHESIVE FOIL GUIDE SIGN
