Поз.
Артикул
Описание
5
TANK OIL
8
OIL DIPSTICK
8
OIL DIPSTICK , Replaced By: A0004660867
11
FILLER CAP
14
SEAL RING
17
BRACKET
20
FILTER
20
FILTER
26
BRACKET OIL TANK,K 055089
26
BRACKET OIL TANK,5 094745
32
SCREW CENTRAL LOCK TO CAB M 10X16
47
SCREW OIL TANK TO BRACKET
50
NUT PUMP TO BRACKET
50
NUT , Replaced By: N913004006001
53
HOSE FROM OIL TANK TO SUCTION LINE
53
HOSE ,K 055044
56
LINE (SUCTION LINE),FROM HOSE TO OIL PUMP
56
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,5 138294
56
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,5 163366
59
CLAMP , Replaced By: N000000000667
59
CLAMP HOSE TO SUCTION LINE AND TO OIL TANK 20-32X13 MM
62
HOSE (SUCTION LINE),FROM OIL TANK TO PUMP,5 138294
64
LINE (SUCTION LINE),FROM OIL TANK TO PUMP
66
NUT LINE CONNECTION
66
UNION NUT LINE CONNECTION
66
UNION NUT LINE CONNECTION, Replaced By: N000000006239
66
UNION NUT LINE CONNECTION, Replaced By: N000000006243
68
GLAND , Replaced By: A0019901967
68
GLAND , Replaced By: A0019901267
68
SEAL CONE LINE CONNECTION
68
SEAL CONE LINE CONNECTION
70
ELBOW FITTING SUCTION LINE TO OIL PUMP
72
THRUST RING SUCTION LINE TO OIL PUMP
74
SEALING CORD SUCTION LINE TO OIL PUMP
76
NUT SUCTION LINE TO OIL PUMP
78
FITTING DELIVERY LINE TO PUMP
79
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
84
LINE FROM PUMP TO HIGH PRESSURE HOSE
84
LINE FROM PUMP TO HIGH PRESSURE HOSE,K 244310
84
LINE FROM PUMP TO HIGH PRESSURE HOSE,K 126843
86
UNION NUT LINE CONNECTION
86
UNION NUT LINE CONNECTION, Replaced By: N000000006239
89
GLAND , Replaced By: A0019901967
89
SEAL CONE LINE CONNECTION
107
HOSE (DELIVERY LINE),FROM PUMP TO STEERING,5 138293
107
HOSE (DELIVERY LINE),FROM PUMP TO STEERING,K 126844
107
HOSE POWER-STEERING-PUMP-TO-STEERING-BOX DELIVERY LINE
107
HOSE (DELIVERY LINE),FROM PUMP TO STEERING
107
HOSE (DELIVERY LINE),FROM PUMP TO STEERING,K 126844
125
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX,K 055044
125
LINE (DELIVERY LINE) FROM HIGH PRESSURE HOSE TO STEERING BOX,5 163366
131
NUT. UNION NUT LINE CONNECTION
134
CUTTING RING. GLAND LINE CONNECTION
137
SCREW-IN FITTING LINE CONNECTION TO TRANSMISSION
143
SCREW-IN FITTING DELIVERY LINE TO PUMP
146
LINE (RETURN LINE),FROM STEERING TO OIL TANK,5 163366
146
LINE12 MM, ORDER BY THE METER4 691315
149
UNION NUT LINE CONNECTION
149
UNION NUT LINE CONNECTION, Replaced By: N000000006239
152
GLAND , Replaced By: A0019901967
152
SEAL CONE LINE CONNECTION
161
HOSE ,K 055044
164
CLAMP HOSE TO FITTING AND TO OIL TANK 16-27X13 MM
164
CLAMP HOSE TO FITTING AND TO OIL TANK
167
BRACKET DELIVERY AND SUCTION LINES,5 374584
170
SCREW COVER PLATE TO BRACKET
172
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
172
SCREW , Replaced By: N304017010028
174
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
176
BRACKET DELIVERY AND SUCTION LINES
179
SCREW DISTRIBUTOR TO CAB
185
BRACKET DELIVERY AND SUCTION LINES TO ENGINE
188
NUT , Replaced By: N913004006001
188
NUT PUMP TO BRACKET
189
CLAMP LINE MOUNTING
189
CLAMP , Replaced By: N916016015202
189
BRACKET HOSE TO OIL DIPSTICK GUIDE TUBE,K 130676
189
BRACKET WITH PLUG,K 130676
189
CLAMP OIL FILLER PIPE TO BRACKET
215
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
215
CLAMP LINE MOUNTING
215
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, TOP
218
CLAMP CABLE HARNESS MOUNTING
218
CLAMP DELIVERY AND SUCTION LINES TO ENGINE, FRONT
218
CLAMP DELIVERY AND SUCTION LINES TO FRAME
218
CLAMP , Replaced By: N916016010211
218
CLAMP , Replaced By: N000000001045
218
CLAMP DELIVERY AND SUCTION LINES TO FRAME, Replaced By: N916016022203
221
SCREW COVER PLATE TO BRACKET
224
SCREW , Replaced By: N914146006102
224
SCREW CLAMP MOUNTING M 6X16
227
NUT AT FILTER BRACKET
227
NUT EXHAUST PIPE TO SIDE MEMBER
999
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING M 6X50
999
FITTING (DELIVERY LINE),FROM PUMP TO STEERING, Replaced By: A9329970772
999
PROTECTIVE CAP
999
LINE (SUCTION LINE),FROM OIL TANK TO PUMP,K 136986
999
LINE , Replaced By: A0004291001
999
BRACKET OIL TANK,5 553319
999
LINE (DELIVERY LINE) FROM FITTING TO STEERING,K 126844
999
LINE RETURN LINE TO STEERING,K 055018
999
LINE FROM PUMP TO HIGH PRESSURE HOSE,K 136986
999
BRACKET DELIVERY AND RETURN LINES,K 055018
999
FITTING (DELIVERY LINE),FROM PUMP TO STEERING
999
SEAL RING SOLENOID VALVE A 18X24
