Поз.
Артикул
Описание
7
BRACKET LEFT TAIL LAMP,K 062690
7
BRACKET RIGHT TAIL LAMP,K 062690
13
BRACKET LEFT TAIL LAMP
13
BRACKET RIGHT TAIL LAMP
19
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
19
SCREW , Replaced By: N304017008016
23
WASHER EXHAUST MUFFLER TO STRAP
23
WASHER , Replaced By: N000125008443
27
NUT , Replaced By: N913004008001
27
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
33
BRACKET TAIL LAMP BRACKET
38
BRACKET TAIL LAMP BRACKET
38
BRACKET
42
BASE TAIL LAMP BRACKET TO FRAME,K 062691
47
SCREW STRUT TO FRAME M 14X1.5X42
47
SCREW BRACKET TO CAB CONSOLE,K 035197
53
WASHER STRUT TO EXHAUST PIPE AND TO SIDE MEMBER
53
WASHER , Replaced By: N000125015019
58
NUT , Replaced By: N910113014001
58
NUT BRACKET TO SIDE MEMBER
63
BRACKET , Replaced By: A6735256039
63
BRACKET LICENSE PLATE
70
BRACKET REFLECTOR
74
SCREW , Replaced By: N304017006020
74
SCREW LICENSE PLATE TO BRACKET
78
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
78
WASHER COMPRESSED AIR LINE TO BRACKET
82
NUT , Replaced By: N913004006001
82
NUT PUMP TO BRACKET
86
REFLECTOR
89
SCREW JUNCTION BOX TO BRACKET
93
WASHER , Replaced By: N000433005304
93
WASHER BOOT TO CAB FLOOR
96
NUT TWO-WAY VALVE TO BRACKET
101
NAME PLATE
106
RIVET NAME PLATE TO TAIL LAMP BRACKET
112
BRACKET GUIDE CROSS
115
SCREW BRACKET TO SIDE MEMBER
115
SCREW , Replaced By: N304017010002
115
SCREW PROTECTIVE PLATE TO EXHAUST MUFFLER
121
NUT , Replaced By: N910113010000
121
NUT STRAP TO BRACKET
127
BRACKET REFLECTOR
133
SIDE MARKER LAMP
133
SIDE MARKER LAMP
133
SIDE MARKER LAMP , Replaced By: A0005442311
137
BULB24 V
143
REFLECTOR AMBER
143
REFLECTOR FENDER
143
REFLECTOR REAR LEFT AND RIGHT
146
RIVET REFLECTOR TO BRACKET
152
SCREW CLAMP MOUNTING M 6X16
152
SCREW , Replaced By: N000000001146
157
SCREW , Replaced By: A0029903712
157
SCREW , Replaced By: N000000001149
157
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
162
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
162
WASHER COMPRESSED AIR LINE TO BRACKET
167
NUT PUMP TO BRACKET
167
NUT PUMP TO BRACKET
167
NUT , Replaced By: N913004006001
999
BRACKET ,K 062691K 251255
999
BRACKET ,K 062691K 251255
