Поз.
Артикул
Описание
5
HOSE , Replaced By: A0009872827
5
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
8
FITTING (PARTS KIT),LINE RUPTURE
11
UNION NUT LINE CONNECTION
11
UNION NUT LINE CONNECTION, Replaced By: N000000006239
14
GLAND , Replaced By: A0019901967
14
SEAL CONE LINE CONNECTION
17
SLEEVE LINE CONNECTION
20
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
23
CONNECTOR , Replaced By: A0019904078
23
CONNECTOR RELEASE BEARING LUBRICATION
26
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION
27
ELBOW FITTING HOSE WIDTH, 9 MM,TO M 22
28
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
29
BANJO UNION HOSE WIDTH, / I.D., 9/16 MM
93
BRACKET AT CONSOLE, SIMPLE PART-PLEASE HAVE SHOP MADE
108
SCREW BEARING BRACKET TO FRAME
108
SCREW , Replaced By: N000961012051
111
WASHER , Replaced By: N006902011100
111
WASHER , Replaced By: N000125010532
111
WASHER , Replaced By: N006902011102
111
WASHER RADIATOR TO RUBBER MOUNTING
111
WASHER BRACKET TO FRAME
111
WASHER UNDERRUN PROTECTION AND BRACKET TO FRAME
114
NUT STRAP TO BRACKET
114
NUT , Replaced By: N910113010000
135
NUT , Replaced By: N910113010000
135
NUT STRAP TO BRACKET
135
HEXAGON NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET
138
NUT BRACKET TO SUPPORT AND TO END PIECE
144
THRUST RING CHECK VALVE TO AIR RESERVOIR
144
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
147
O-RING CHECK VALVE TO AIR RESERVOIR
162
VALVE. DRAIN VALVE DRAIN
162
VALVE DRAIN, Replaced By: A0004322407
162
VALVE DRAIN, Replaced By: A0004322107
165
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
165
THRUST RING CHECK VALVE TO AIR RESERVOIR
168
O-RING CHECK VALVE TO AIR RESERVOIR
171
VALVE (OVERFLOW VALVE) WABCO
171
VALVE (OVERFLOW VALVE) GRAU
174
DIAPHRAGM
174
DIAPHRAGM
177
SCREWWABCO
180
ELBOW FITTING COMBINATION CYLINDER,CONNECTION: "12"
186
NUT CHECK VALVE TO AIR RESERVOIR
189
FITTING OVERFLOW VALVE,CONNECTION: "10"
192
BANJO UNION HOSE WIDTH, / I.D., 6/12 MM
195
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
195
THRUST RING CHECK VALVE TO AIR RESERVOIR
198
O-RING CHECK VALVE TO AIR RESERVOIR
201
NUT CHECK VALVE TO AIR RESERVOIR
