Поз.
Артикул
Описание
15
SUPPORT FRONT LEFT AND REAR RIGHT
15
SUPPORT FRONT RIGHT AND REAR LEFT
27
SCREW BRACKET TO SIDE MEMBER
33
NUT STRAP TO BRACKET
33
NUT , Replaced By: N910113010000
39
CLAMPING PIECE SUPPORT TO SUPPORT
45
CLAMP SUPPORT TO SUPPORT
51
SCREW , Replaced By: N304017008021
51
SCREW PIPE CLAMP
57
NUT , Replaced By: N913004008001
57
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
63
FENDER REAR
70
BRACKET
76
REINFORCEMENT FENDER TO BRACKET
76
REINFORCEMENT , Replaced By: A4405220829
82
SCREW , Replaced By: N304017008021
82
SCREW PIPE CLAMP
88
NUT SWITCH TO FLOOR PLATE
94
CLAMPING PIECE FENDER TO SUPPORT
100
SCREW , Replaced By: N304017008027
100
SCREW CLAMP TO CONNECTING PIPE AND TO EXHAUST HOSE M 8X30
106
NUT , Replaced By: N913004008001
106
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
112
CAP AT BRACKET,K 257460
999
SCREW , Replaced By: N000000001149
999
WASHER AT BRACKET
999
GUIDE GEARSHIFT MECHANISM, ON TRUCKS UP TO CHASSIS 156152,ON BUSES UP TO CHASSIS 020033
999
SUPPORT
999
FENDER
999
RAIL , Replaced By: A3818810206
999
SPLASH GUARD
999
ANTINOISE CAPSULE
999
BRACKET COVERING TO FRONT FENDER
999
SUPPORT , Replaced By: A6745200233
999
BRACKET LEFT
999
BRACKET RIGHT
999
BRACKET LEFT
999
BRACKET RIGHT
999
SPRING CHOCK
999
REINFORCEMENT FENDER TO BRACKET
999
SHIM FRONT RIGHT AND REAR LEFT
999
FENDER
999
SHIM SUPPORT TO SIDE MEMBER
999
FENDER
999
FENDER
999
BRACKET CHOCK
999
HEXALOBULAR BOLT WIRE CABLE TO BRACKET
999
WASHER COMPRESSED AIR LINE TO BRACKET, Replaced By: N000125006449
999
WASHER , Replaced By: N000125008443
999
WASHER EXHAUST MUFFLER TO STRAP
999
SCREW BRACKET TO TAIL LAMP BRACKET
999
SCREW , Replaced By: N304017006020
999
SCREW , Replaced By: N304017008016
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
SCREW , Replaced By: N304017010002
999
PART NAME MISSING
999
RIVET COVERING BRACKET
999
SCREW , Replaced By: A0029903712
999
WASHER , Replaced By: N009021006208
999
WASHER COMPRESSED AIR LINE TO BRACKET
999
SCREW LICENSE PLATE TO BRACKET
999
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
999
SCREW BRACKET TO SIDE MEMBER
999
RIVET REFLECTOR TO BRACKET
999
NUT TWO-WAY VALVE TO BRACKET
999
NUT , Replaced By: N913004008001
999
SCREW HEAT SHIELD MOUNTING M 6X25
999
PLUG ,5 470513 FOR USE WITH SHORT VERSION OF MERCEDES-BENZ CAB
