Поз.
Артикул
Описание
76
VALVE TWO-SPEED REAR AXLE CONTROL,D 091465
80
SCREW-IN FITTING ,D 091465
84
ELBOW FITTING AT CYLINDER
84
ELBOW FITTINGTO 682 431 70 65,D 091465
88
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
90
SEAL RING PRESSURE REGULATOR,CONNECTION: "23",5 161701
92
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
92
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
92
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
96
NUT ,D 091466
97
HOLLOW SCREW HEATING CONNECTION
98
SEAL RING LINE CONNECTION
100
ELBOW FITTINGTO 28.2.1
104
FITTING ,D 091466
104
ELBOW FITTINGTO 28.2.2 R
108
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
112
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
116
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
120
HOLLOW SCREW FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "10",K 009079
124
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
128
HOSE (QUICK BREATHER VALVE)
132
UNION NUT LINE CONNECTION
136
GLAND LINE CONNECTION
140
SCREW PLUG
140
SCREW PLUG AT TANK
144
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
145
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
145
HOLLOW SCREW FITTING RELAY VALVE,CONNECTION "20",LEFT
146
SWITCH SUPPLY PRESSURE,5 966147
146
SWITCH
148
FITTING DISTRIBUTOR
152
VALVE QUICK-RELEASE VALVE KNORR
152
VALVE (QUICK BREATHER VALVE) VARGA
152
VALVE (QUICK BREATHER VALVE) KNORR
152
VALVE (QUICK BREATHER VALVE) WABCO
152
VALVE (QUICK BREATHER VALVE) VARGA
152
VALVE , Replaced By: A6934297144
164
REPAIR KITTOA 382 429 70 44, A 693 429 71 44
164
REPAIR KITTO A 364 429 70 44
168
PLASTIC TUBE2X4MM, ORDER BY THE METER
172
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
172
HOSE PLASTIC 6X1 MM, ORDER BY THE METER
173
COUPLING COMPRESSED-AIR-LINE PLUG-CONNECTION
174
PLUG COMPRESSED-AIR-LINE PLUG-CONNECTION
176
UNION NUT LINE MOUNTING, Replaced By: N000000006521
180
UNION NUT
180
UNION NUT BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
184
SLEEVE LEAK LINE
184
SLEEVE LINE MOUNTING
188
GLAND LINE MOUNTING
192
GLAND , Replaced By: A0019901667
192
GLAND BLEEDING, FROM IDENT NO. 5 033767,EXCEPT FOR 5 039977
196
BANJO UNION
196
BANJO UNION HOSE WIDTH, / I.D., 4/12 MM
196
BANJO UNION
196
BANJO UNION HOSE WIDTH, / I.D., 4/16 MM
197
CONNECTORTO M22 / 4MM / VOSS 230
198
PLASTIC PIPE FRONT AXLE PNEUMATIC SUSPENSION 12X9 MM, ORDER BY THE METER
198
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
199
ELBOW FITTING COMPRESSED-AIR-LINE PLUG-CONNECTION TO M 16
199
ELBOW FITTINGTO M10 / 4MM /VOSS 230
199
ELBOW FITTING HOSE WIDTH, 4 MM,TO M 22
200
ELBOW FITTINGTO M22 / 4MM / M12X1,5 / VOSS 230
201
CONNECTOR , Replaced By: A0029905378
201
CONNECTOR COMPRESSED-AIR-LINE PLUG-CONNECTION
202
INSULATING HOSE BLUE
202
INSULATING HOSE8X0,01 MM
202
INSULATING HOSE COLOR CODE YELLOW, ORDER BY THE METER
202
INSULATING HOSE COLOR CODE BLUE 2X0,01 MM
204
LOOM TIE LINE MOUNTING
204
LOOM TIE WIRING HARNESS FOR AIR CONDITIONING SYSTEM 205 MM
204
CABLE TIE. LOOM TIE CABLE TO ALTERNATOR
204
LOOM TIE , Replaced By: A3459977390
204
LOOM TIE ELECTRIC CABLE MOUNTING
208
FITTING ,D 091465
212
FITTING ,D 091465
216
FITTING , Replaced By: A0019975372
220
HOLLOW SCREW FITTING LEFT AND RIGHT COMBINATION CYLINDERS, CONNECTION: "11,12",5 356525
224
NUT ELECTRONIC ACCELERATOR PEDAL
228
BRACKET BULKHEAD FITTING,D 091465
232
SCREW ,D 091465
232
SCREW BRACKET TO SIDE MEMBER
236
NUT BRACKET TO SIDE MEMBER,XB209706
236
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
240
BRACKET QUICK-RELEASE VALVE
240
BRACKET QUICK-RELEASE VALVE
240
BRACKET QUICK-RELEASE VALVE
240
BRACKET ,D 091466
244
BOLT. SCREW QUICK-RELEASE VALVE TO BRACKET
244
SCREW LINES TO BRACKET
244
SCREW QUICK-RELEASE VALVE TO BRACKET
244
SCREW BRACKET TO AIR CLEANER CONSOLE
246
WASHER , Replaced By: N000125008443
247
WASHER BRACKET TO CAB REAR PANEL
248
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
252
SCREW , Replaced By: N304017010040
252
SCREW BRACKET TO SIDE MEMBER
252
SCREW BRACKET TO AIR CLEANER CONSOLE
254
WASHER , Replaced By: N000125008443
256
SCREW LINES TO BRACKET
256
SCREW BRACKET TO CONSOLE M 8X25
260
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
260
NUT GUSSET PLATES AND REAR CROSS MEMBER TO SIDE MEMBERS
264
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
264
NUT BRACKET TO SIDE MEMBER
272
HOLLOW SCREW HEATING CONNECTION
274
HOLLOW SCREW FITTING PNEUMATIC CYLINDER,CONNECTION: "10",5 308944
276
SEAL RING LINE CONNECTION
290
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
290
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
292
BRAKE HOSE
292
BRAKE HOSE
294
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
296
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
300
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
304
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
308
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
312
SCREW. UNION SCREW LINE CONNECTION
316
BRACKET QUICK-RELEASE VALVE
320
SCREW BRACKET TO AIR CLEANER CONSOLE
324
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
328
WASHER TRAILER PLUG SOCKET TO BRACKET
332
UNION SCREW SPRING LOAD ACCUMULATOR CYLINDER M10X1 / VOSS 230,D 259885
332
FITTING LINE CONNECTION
336
SEAL RING SPRING LOAD ACCUMULATOR CYLINDER TO M10 / VOSS 230,D 259885
336
SEAL RING , Replaced By: A0009940747
340
LOCK , Replaced By: A0009945448
340
LOCK SPRING LOAD ACCUMULATOR CYLINDER TO M10 / VOSS 230,D 259885
344
UNION SCREW SPRING LOAD ACCUMULATOR CYLINDER M10X1 / VOSS 230,D 259885
344
SCREW. UNION SCREW , Replaced By: A0009973734
348
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940103
348
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
352
SEALING CORD COMPRESSED-AIR-LINE PLUG-CONNECTION
356
BRACKET ,D 091466
360
SHEET METAL SCREW
360
TAPPING SCREW. SHEET METAL SCREW ,D 091466
364
WASHER BRACKET TO LEFT SIDE MEMBER
368
LOOM TIE LINE MOUNTING
372
FITTING , Replaced By: A0019975372
400
U-BOLT REAR SPRING TO REAR AXLE M 18X1,5X380 MM
999
HEXAGON HEAD BOLT. SCREW BRACKET TO SIDE MEMBER M10X25
999
NUT L.H. THREAD
999
NUT BRACKET TO FRAME
999
WOODRUFF KEY
999
SCREW MOUNTING CLAMP TO BRACKET AND TO FRAME
999
BOOT
999
SHIFT LEVER LOWER PART LOWER PART
999
WASHER FENDER TO BRACKET,V 207570
999
SHIFT LEVER
999
BOOT GEARSHIFT LEVER UPPER PART
999
VALVE (SHIFT LEVER VALVE)
999
SHIFT LEVER UNDIVIDED, NOT USED
999
SHIFT LEVER UNDIVIDED, NOT USED
999
SHIFT LEVER ,B 968219
999
SHIFT LEVER ,B 968220
999
HANDLE GEARSHIFT LEVER UPPER PART, NO.8650I.......I I I II .......INO.9985I I I II I
999
ARTICULATION PIECE
999
ARTICULATION PIECE R.H. THREAD
999
SHIFT LEVER UPPER PART, .......INO.9985I I I II
999
SHIFT LEVER TOP
999
SHIFT LEVER TOP
999
SHIFT CASE , Replaced By: A0002684601, +001A3842607533, +001A3842687140
999
HANDLE UNDIVIDED
999
HANDLE UNDIVIDED
999
HANDLE UNDIVIDED
999
SHIFTING ROD ,030874, Replaced By: A3842608233, +001A3842607933
999
BEARING COVER
999
PLATE
999
SHIFTING ROD
999
SHIFTING ROD
999
SHIFTING ROD
999
GUIDE
999
SHIFTING ROD
999
KNOB (SHIFT LEVER HANDLE), NO.8650I.......I I I II .......INO.9985I I I II I
999
CLAMPING PIECE ,C 073902
999
BOOT , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
999
BUSHING SHIFT CASE
999
BOOT SHIFT CASE
999
COVER
999
BOOT , 030,032,033,040,041 UP TO CHASSIS 521825
999
SHIFT LEVER LOWER PART
999
GUIDE SHIFTING TUBE
999
JOINT REAR SHIFTING ROD
999
CONNECTOR
999
LOCK FRONT SHIFTING ROD TO REAR SHIFTING ROD
999
TRANSMISSION CASE COVER , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
999
SCREW SHIFTING ROD TO TRANSMISSION
999
CONNECTOR FLANGE TO SHIFTING TUBE
999
SPRING SHIFT CASE,BOTTOM
999
SCREW SHIFTING TUBE TO TRANSMISSION
999
SCREW
999
CLAMPING PIECE SHIFTING TUBE TO TRANSMISSION
999
SLIDE SHIFT CASE
999
HOSE
999
BUSHING SHIFTING ROD TO SHIFT LEVER,770982
999
COVER SHIFTING DOME TO TRANSMISSION CASE,TOP
999
BUSHING
999
SPHERICAL PIECE GEARSHIFT LEVER LOWER PART,D 203092
999
GUMMISCHUSSKAPPE. BOOT SHIFT LEVER
999
VALVE
