Поз.
Артикул
Описание
5
CROSS MEMBER TRANSFER CASE TO FRAME
8
SCREW , Replaced By: N304017010002
8
SCREW BRACKET TO SIDE MEMBER
11
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
14
NUT , Replaced By: N910113010000
17
SUPPORT FRONT CROSS MEMBER
20
SCREW BRACKET TO SIDE MEMBER
20
SCREW END PIECE TO EXHAUST PIPE M 10X25
23
NUT , Replaced By: N910113010000
26
BRACKET REAR CROSS MEMBER
29
SCREW , Replaced By: N308676012012
32
NUT FRONT SPRING FRONT BRACKET TO SIDE MEMBER
35
BEARING TRANSFER CASE TO FRAME
38
RUBBER MOUNTING TRANSFER CASE TO FRAME
41
WASHER TRANSFER CASE TO FRAME
41
WASHER , Replaced By: A3129902840
44
LOCK TRANSFER CASE TO FRAME
47
SCREW TORSION BAR TO SHACKLE M 12X85,5 255315
47
SCREW SPRING CLAMP TO SPRING LEAF NO.5, TO 682 320 73 02, M 12X80
50
NUT FRONT SPRING FRONT BRACKET TO SIDE MEMBER
