Поз.
Артикул
Описание
5
8
COVER , Replaced By: A0004307514
11
14
SCREW. HEXALOBULAR BOLTM6X60
17
WASHER MODULATOR TO ENGINE CONTROL SHAFT
20
HEXAGON NUT. NUT LINE TO SIDE MEMBER
23
23
24
LOCK CLUTCH HOSE
25
SHIM CLUTCH MASTER CYLINDER 5 MM,D 120433
26
HEXALOBULAR BOLT CLAMP ON BRACKET M6X30
26
SCREW BRACKET AND CLAMP M6X20
26
SCREW. HEXAGON HEAD BOLT BUZZER TO WINDOW LEVEL GIRDER M6X25
29
PIN PISTON ROD TO CLUTCH PEDAL
32
LOCK PLATE LEVER TO STRUT
35
35
35
38
FITTING PARTS KIT
38
40
LOCK CLUTCH HOSE
41
SEAL RING FUEL LINE TO FEED PUMP
41
SEAL RINGTO 000 553 03 05,000 553 18 05,
44
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
45
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
47
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
48
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
50
SCREW. UNION SCREW LINE CONNECTION
51
SCREW. UNION SCREW LINE CONNECTION
53
ADAPTER FITTING AT BRAKE LINE COUPLING
54
FITTING LOAD/NO-LOAD VALVE,CONNECTIONS: "10,21"
56
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
59
THRUST RING LOCKING VALVE TO TRAILER CONTROL VALVE,CONNECTION: "42"
59
THRUST RING LOCKING VALVE
59
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
61
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
62
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
64
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
65
LOOM TIE LINE MOUNTING
68
71
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
74
NUT EXHAUST PIPE AND PIPE CLAMP TO BRACKET
77
WASHER BRACKET TO LEFT SIDE MEMBER
80
LOOM TIE LINE MOUNTING
81
PIN RELEASE LEVER
82
CLUTCH BOOSTERWABCO
82
CLUTCH BOOSTERWABCO
82
83
84
85
BOOT ,5 962906
85
BOOT ,5 962906, Replaced By: A0002955683
86
BRACKET
89
92
PISTONTO A 000 295 13 18
95
95
RODTO A 000 295 13 18
98
VALVE , Replaced By: A6314230065
101
NUT
104
104
107
110
SENDER UNIT TRAVEL SENSOR
113
113
113
116
GASKET CLUTCH BOOSTER TO BELL HOUSING,RB012797
119
SCREW , Replaced By: N910143008000
119
SCREW SPEED SENSOR TO REAR AXLE
122
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
140
FITTING COMPRESSED-AIR LINE FOR TRANSMISSION TO CLUTCH BOOSTER
