Поз.
Артикул
Описание
5
GASKET KIT CYLINDER CRANKCASE, FOR BREAK-DOWN OF OF GASKET KIT, SEE END OF GROUP 01
5
GASKET KIT , EXHAUST STOCK OF OLD PART NUMBER FIRST THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3605860790, +001A3275860190
5
GASKET KIT , Replaced By: A3600105508
5
GASKET KIT , Replaced By: A3600100280
10
CRANKCASE , UP TO ENGINE 002884 EXCEPT FOR, 002754-002757,002811-002834,002836-002865,002867-002881, Replaced By: A3270101108, +001A3270110008, +001A3520184216, +001A3270180053, +001A3271502072, +001A3271500275, +001A3272010680, +001A3522036439, +001A3272030073, +001A0039976746, +001A0039975692, +002N000931010111
10
CRANKCASE , FROM ENGINE 002885 ALSO INSTALLED ON 002754-002757,002811-002834,002836-002865,002867-002881, Replaced By: A3270101108, +001A3520184216, +001A3270180053, +001A3279971071
10
CRANKCASE , Replaced By: A3270101108, +001A3270110008, +001A3520184216, +001A3270180053, +001A0039976746
10
CRANKCASE WITH CAMSHAFT BEARINGS,LESS BELL HOUSING
12
SCREW PLUG CORE HOLE IN PUSH ROD CHAMBER
15
SEAL RING TEMPERATURE GAUGE SENDER UNIT
17
SCREW PLUG OIL PASSAGE,REAR
19
SEAL RING REAR CORE HOLE
21
SCREW PLUG REAR CORE HOLE
23
EXPANSION PLUG CORE HOLE,OIL COOLER SIDE
25
EXPANSION PLUG P.T.O.
27
THREADED CHUCK
29
EXPANSION PLUG CAMSHAFT BEARINGS NO. 7
31
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
33
SCREW PLUG RELAY VALVE,CONNECTION "20",RIGHT
35
CAP. EXPANSION PLUG , UP TO ENGINE 002884 EXCEPT FOR, 002754-002757,002811-002834,002836-002865,002867-002881
35
EXPANSION PLUG P.T.O. HOUSING
36
CYLINDRICAL PIN CYLINDER HEAD TO CYLINDER CRANKCASE
36
CYLINDRICAL PIN FLYWHEEL HOUSING TO CYLINDER CRANKCASE
37
CYLINDRICAL PIN
37
CYLINDRICAL PIN ,A 057455, 341.023,027,032,034,036,038,041,042,043,044,045 FROM IDENT NO. A 057456 SEE SPARE PARTS LIST 713.0, MF 859A 077314, 341.116 FROM IDENT NO. A 077315 SEE SPARE PARTS LIST 713.0, MF 859
38
CYLINDER PIN. CYLINDRICAL PIN , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
39
GROOVED PIN CYLINDER HEAD TO CYLINDER CRANKCASE
40
BEARING CAP
41
CYLINDRICAL PIN , Replaced By: N000007008108
41
CYLINDER PIN. CYLINDRICAL PIN
43
CYLINDRICAL PIN
45
BEARING CAP
46
SCREW
47
GUIDE TUBE
47
GUIDE TUBE , Replaced By: A3520184216
49
SPACER TUBE GUIDE TUBE TO CYLINDER CRANKCASE
51
VALVE ,4 263013
53
SPRING ,4 263013
55
CAMSHAFT BEARINGNO. 1
57
CAMSHAFT BEARINGNO. 2, NO. 3, NO. 5, NO. 6
59
CAMSHAFT BEARINGNO. 4
61
CAMSHAFT BEARINGNO. 7
63
SEAL RING TEMPERATURE GAUGE SENDER UNIT
65
FITTING FRONT SIDE
66
FITTING OIL PRESSURE GAUGE CONNECTION
78
ENGINE PLATE , 001929
79
RIVET ENGINE PLATE TO ENGINE
79
RIVET , Replaced By: A0039909597
80
SUSPENSION EYE
86
TIMING CASE
86
TIMING CASE
87
SCREW PLUG STABILIZER
88
CYLINDER PIN. CYLINDRICAL PIN , UP TO CHASSIS 447270 FROM CHASSIS SEE SPARE PARTS LIST 817,INAPPLICABLE TO R.H.D.AND SUPERCHARGED ENGINE VEHICLES
89
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
90
SCREW FITTING
91
GASKET TIMING CASE TO CYLINDER CRANKCASE
91
GASKET , Replaced By: A3600150480
91
GASKET , Replaced By: A3600150480
92
SCREW PROPELLER SHAFT TO COUPLING FLANGE
93
COVER
94
SEAL RING
94
SEAL RING
94
SEAL RING , Replaced By: A0119975647
94
SEAL RING , Replaced By: A0119975747
95
POINTER
95
POINTER
96
GASKET TIMING CASE COVER TO TIMING CASE
96
GASKET , Replaced By: A3600150120
97
SCREW
98
SCREW
120
CLAMP BREATHER PIPE TO OIL PAN
121
BRACKET BREATHER PIPE TO OIL PAN
122
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
122
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
122
SCREW , Replaced By: N304017008016
123
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
123
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
124
NUT
124
NUT BALL PIVOT TO LEVER
200
GASKET KIT , Replaced By: A3600105508
200
GASKET KIT CYLINDER CRANKCASE, FOR BREAK-DOWN OF OF GASKET KIT, SEE END OF GROUP 01
999
FILLER CAP , Replaced By: A0000101485
999
FILLER CAP
999
GASKET OIL FILTER BOWL WITH FULL-FLOW FILTER TO OIL FILTER HEAD
999
GASKETTO 366 180 09 10
999
GASKET FILTER HOUSING TO FILTER HEAD
999
BRACKET
999
SEAL RING FUEL FILTER COVER
999
SEAL RING ,D 031246
999
SEAL RING INJECTION TIMING DEVICE
999
SEAL RING CRANKSHAFT SEALING,REAR
999
SEAL RING OIL FILLER PIPE
999
SEAL RING
999
FLANGE GASKET COVER TO TIMING CASE
999
SEAL RING , Replaced By: A0000180180
999
SCREW PLUG , Replaced By: A0009972632
999
SEAL RING ANGLE DRIVE
999
INSTRUCTION PLATE AT CYLINDER HEAD COVER,028243
999
SEAL HOLDER
999
GASKET KIT , Replaced By: A3600103320
999
COVER , UP TO ENGINE 002293 EXCEPT FOR, SEE FOOTNOTE 020
999
COVER , Replaced By: A3270150501, +001A3270150131, +001A0119975647
999
ENGINE , SEE ENGINE SPARE PARTS LIST OM360,360.916, Replaced By: A3600104803
999
GUIDE TUBE
999
GASKET , Replaced By: A3600150120
999
GASKET , Replaced By: A3600150122
999
GASKET , Replaced By: A3600150380
999
CYLINDER HEAD COVER , 006675, Replaced By: A3600160005, +001A3520100168
999
CYLINDER HEAD COVER , Replaced By: A3270160905
999
CYLINDER HEAD GASKET , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3600160320
999
GASKET , Replaced By: A3600180280
999
GASKET , Replaced By: A3600350080
999
VALVE GUIDE , Replaced By: A3270531430
999
GASKET , Replaced By: A3550750080
999
SEAL FUEL LEAK LINE
999
GASKET , Replaced By: A3661840080
999
GASKET , Replaced By: A3601860080
999
GASKET , Replaced By: A3602030080
999
GASKET KIT , Replaced By: A3270100080
999
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A3880170160
999
SEAL RING NOZZLE HOLDER TO CYLINDER HEAD 1.5 MM
999
CAP , Replaced By: A0000180702
999
GASKETTO 352 010 01 68
999
GASKET , Replaced By: A3522032480
999
GASKET , Replaced By: A3522032080
999
GASKET , Replaced By: A3522032280
999
GASKET COVER TO THERMOSTAT HOUSING,078816
999
GASKET COVER TO THERMOSTAT HOUSING, NOT USED
999
GASKET , Replaced By: A3522032680
999
GASKET DE-AERATION LINE TO HEATING LINE
999
SEAL RING DELIVERY LINES
999
GASKET
999
GASKET INJECTION PUMP DRIVE TO TIMING CASE
999
GASKET OUTLET TO ENGINE
999
GASKET KIT CYLINDER HEAD, FOR BREAK-DOWN OF GASKET KIT,SEE END OF GROUP 01
999
GASKET , Replaced By: A3600140322
999
GASKET OIL PAN TO CYLINDER CRANKCASE
999
GASKET , Replaced By: A3600150222
999
GASKET PUSH ROD CHAMBER COVER TO CYLINDER CRANKCASE
999
GASKET , Replaced By: A3600150480
999
GASKET COVER TO CYLINDER CRANKCASE
999
GASKET , Replaced By: A3600150480
999
GASKET , Replaced By: A3600160221
999
GASKET CYLINDER HEAD COVER TO CYLINDER HEAD
999
CYLINDER HEAD GASKET , Replaced By: A3600160520
999
CYLINDER HEAD GASKET
999
GASKET CYLINDER SIDE COVER TO CYLINDER CRANKCASE
999
GASKET
999
GASKET , Replaced By: A3550770080
999
GASKET INTAKE MANIFOLD
999
GASKET EXHAUST MANIFOLD TO CYLINDER HEAD
999
GASKET SUCTION PIPE TO OIL PUMP HOUSING
999
GASKET , Replaced By: A3602010380
999
GASKET WATER PUMP TO CYLINDER CRANKCASE
999
GASKET UPPER COOLING WATER LINE TO CYLINDER HEAD
999
SEAL RING OIL COOLER CONNECTION
999
GASKET COVER TO TIMING CASE, Replaced By: A0259976947
999
GASKET , Replaced By: A3661840180
999
GASKET OIL FILTER TO CYLINDER CRANKCASE
999
GASKET INTAKE MANIFOLD
999
GASKET , Replaced By: A3661310080
999
SEAL RINGBOSCH
999
SEAL RING SCREW PLUG
999
SEAL RING BRACKET TO CYLINDER HEAD
999
SEAL RING , Replaced By: N007603010110
999
SEAL RING
999
SEAL RING PNEUMATIC VALVE
999
SEAL RING LINE CONNECTION
999
SEAL RING , Replaced By: N007603012111
999
SEAL RING FROM FUEL TANK TO FUEL TANK
999
SEAL RING FUEL LINE TO FEED PUMP
999
SEAL RING VALVE TO VALVE,K 025179
999
SEAL RING , 001778
999
SEAL RING LINE CONNECTION
999
SEAL RING AIR RESERVOIR,CONNECTIONS: "24,34"
999
SEALING RING. SEAL RING OIL DRAIN
999
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
999
SEAL RING OIL LINE TO OIL COOLER
999
SEAL RING
999
GASKET HEATING PIPE TO ENGINE
999
GASKET , Replaced By: N917003040006
999
GASKET. SEAL , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A3559970149
