Поз.
Артикул
Описание
5
5
5
10
PRESSURE PLATE
10
PRESSURE PLATE
14
RELEASE LEVER
14
RELEASE LEVER , AXLE BORE IN PRESSURE PLATE TO BE REAMED FROM 8.0MM TO 8.1MM, Replaced By: A0002526913, +001A0002523314, +001A0002523716, +001A0002523816, +040A0002520018, +001A1249945241
16
SPINDLE , FROM IDENT NO. 760272 ALSO INSTALLED ON 500001-599999 AXLE BORE IN PRESSURE PLATE TO BE REAMED FROM 8.0MM TO 8.1MM, Replaced By: A0002523716, +001A0002526513, +001A0002523014, +001A0002523816, +040A0002520018, +001A1249945241
16
SPINDLE FOR RELEASE LEVERS, FROM IDENT NO. 760272 ALSO INSTALLED ON 500001-599999
20
BRACKET FOR BEDDING THE LEVERS IN CLUTCH PRESSURE PLATE
20
BRACKET , Replaced By: A0002521714
20
BRACKET , AXLE BORE IN PRESSURE PLATE TO BE REAMED FROM 8.0MM TO 8.1MM, Replaced By: A0002523314, +001A0002526913, +001A0002523716, +001A0002523816, +040A0002520018, +001A1249945241
22
LEAF SPRING FOR BRACKETS
22
LEAF SPRING FOR BRACKETS
24
SPINDLE THIGH SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING,K 062600
24
SPINDLE FOR BRACKETS, FROM IDENT NO. 760272 ALSO INSTALLED ON 500001-599999
26
ROLLERTO 344 586 70 25
30
INSULATING WASHER
34
PRESSURE SPRING , FROM IDENT NO. 760272 ALSO INSTALLED ON 500001-599999
34
PRESSURE SPRING , Replaced By: A0002524120
38
SPRING SUSPENDED IN CLUTCH PRESSURE PLATE HOUSING
38
SPRING
38
SPRING
42
SPRING CLUTCH PRESSURE PLATE
42
SPRING RELEASE FLANGE TO RELEASE YOKE TO 001 250 00 04
42
SPRING SUSPENDED BELOW LEAF SPRING TO 001 250 00 04,001 250 07 04, FOR USE WITH OM 327 ENGINE,UNTIL SERIES PRODUCTION STOP,FOR USE WITH OM 360 ENGINE FROM IDENT NO. 797910
46
CLAMP RELEASE FLANGE TO RELEASE LEVER
46
CLAMP , Replaced By: A0002523227
55
55
70
HOUSING
74
NUT FOR BRACKETS
74
NUT , Replaced By: A0002523372
76
LOCK , Replaced By: A0002521173
76
LOCK FOR BRACKETS
78
LOCK WASHER BRACKET TO STEERING COLUMN END
80
SCREW BATTERY CABLE MOUNTING AND MAIN CABLE HARNESS MOUNTING
80
SCREW RELEASE LEVER,BRACKET
90
CLUTCH DISC ASBESTOS-FREE LINING, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
90
CLUTCH DISC
90
90
92
92
CLUTCH LINING , Replaced By: A0012524310
92
CLUTCH LINING ASBESTOS-FREE
92
CLUTCH LINING
96
RIVET LINING WITH CLUTCH DISC,5 563495
96
RIVET LEAF SPRING TO CLUTCH DISC
100
RIVET , Replaced By: A0002521275
100
RIVET LINING WITH INTERMEDIATE SPRING
100
RIVET LINING WITH INTERMEDIATE SPRING,5 563495
104
RIVET LEAF SPRING TO CLUTCH DISC 5X6 MM
104
RIVET LEAF SPRING TO CLUTCH DISC
104
RIVET , Replaced By: A0002522075
108
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
112
SCREW VALVE TO BRACKET
112
SCREW VALVE TO BRACKET, Replaced By: N304014008002
999
999
999
999
999
HOUSING
999
LEAF SPRING , REBORE HOLE IN SUPPORTING PLATE FROM 5.2MM TO 6.2MM, Replaced By: A0002524419, +002A0002523975
999
LEAF SPRING
999
NEEDLE BEARING CLUTCH RELEASE SHAFT
999
SNAP RING
999
WASHER CLUTCH RELEASE SHAFT
999
999
999
BELL HOUSING , 10/50 602167 20/60 601938 FROM IDENT NO. SEE, Replaced By: A3372510601, +001A3632500114, +001A3432510050, +001A3432510150, +001A3432930052, +001A3439900040, +001N000471024000
999
BELL HOUSING , 10/50 602167 20/60 601938 FROM IDENT NO. SEE, Replaced By: A3372510701, +001A3632500114, +001A3432510050, +001A3432510150, +001A3432930052, +001A3439900040, +001N000471024000
999
999
999
999
RELEASE SHAFT
999
NEEDLE BEARING ON DRIVE END
999
COTTER PIN LEVER TO ROD, Replaced By: N000094002060
999
LOCK RING22X1.2,TO 001 431 71 14
999
FITTED WASHER CLUTCH RELEASE SHAFT
999
SEAL RING CLUTCH RELEASE SHAFT
999
LOCK PLATE RELEASE LEVER TO SHAFT
