Поз.
Артикул
Описание
5
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
5
LINE , Replaced By: A0005516256
8
BRAKE PRESSURE REGULATOR
8
BRAKE PRESSURE REGULATOR , EXHAUST STOCK OF OLD PARTS NUMBER FIRST UP TO CHASSIS 4 412738, Replaced By: A0014311312
11
REPAIR KIT BRAKE POWER REGULATOR TO 000 431 37 12
14
LEVER BRAKE POWER REGULATOR CONTROL, TO BE ADAPTED DURING ASSEMBLY
14
LEVER , Replaced By: A6744310039
14
LEVER , Replaced By: A6204310839
14
LEVER , Replaced By: A3854310239
14
LEVER , Replaced By: A3854310239
14
LEVER
17
WASHER EXHAUST MUFFLER TO STRAP
17
WASHER , Replaced By: N000125008443
20
COTTER PIN CONNECTOR TO BRAKE PRESSURE REGULATOR LEVER
23
ELBOW FITTING BRAKE PRESSURE REGULATOR CONNECTION,4 412739
23
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
26
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
26
NUT CHECK VALVE TO AIR RESERVOIR
29
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
29
THRUST RING CHECK VALVE TO AIR RESERVOIR
29
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
32
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
32
O-RING CHECK VALVE TO AIR RESERVOIR
35
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
35
SEAL RING LINE CONNECTION
38
FITTING RELAY VALVE,CONNECTION: "1,2"
38
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
41
BRACKET
44
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
47
NUT
50
SCREW BRACKET TO SIDE MEMBER
50
SCREW , Replaced By: N304017010002
50
SCREW END PIECE TO EXHAUST PIPE M 10X25
53
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
56
NUT
56
NUT , Replaced By: N304032010002
59
ROD , Replaced By: N900331008261
59
PULL ROD BRAKE POWER REGULATOR CONTROL 200 MM, TO BE ADAPTED DURING ASSEMBLY
59
ROD , Replaced By: N900331008261
59
ROD , Replaced By: N900331008261
59
PULL ROD FROM CONTROL SHAFT BEARING TO ENGINE SHAFT, TO BE ADAPTED DURING ASSEMBLY
59
PULL ROD , Replaced By: N900331008420
59
ROD , Replaced By: N900331008262
59
ROD , Replaced By: N900331008262
59
ROD
62
NUT
65
CONNECTOR PULL ROD TO LEVER
68
CLAMP HOSE TO RADIATOR AND TO EXPANSION TANK 12-22X13 MM
68
CLAMP , Replaced By: N000000000665
71
METAL SPRING BELLOWS ,4 9579425 498312
71
METAL SPRING BELLOWS ,4 957941, Replaced By: A0004311718, +001N000961012047
71
METAL SPRING BELLOWS , Replaced By: A0004311418
74
YOKE BOTTOM
74
YOKE , Replaced By: A0004310667
77
BRACKET METAL SPRING BELLOWS
80
SHIM
83
LOCK WASHERROCKINGER TYP 59 G140,59 G150
86
SCREW BRACKET TO REAR AXLE
89
LOCK WASHER FITTING TO BRACKET
92
SCREW METAL SPRING BELLOWS TO BRACKET,4 957941
95
UNION NUT BUTT SCREW CONNECTION
98
GLAND LINE CONNECTION
101
THRUST RING BUTT SCREW CONNECTION
104
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
104
SEAL RING , Replaced By: N007603012121
