Поз.
Артикул
Описание
53
BEARING BRACKET TORSION BAR,REAR,4 114583
56
BEARING BRACKET , Replaced By: A3933200678, +001A3933260152, +001N913004016004
59
STUD BOLT
62
SCREW BRACKET TO SUPPORT
65
SPRING WASHER BRACKET TO TIMING CASE
68
SHACKLE TORSION BAR,REAR,4 114583
71
SHACKLE REAR SPRING TO REAR AXLE,4 707918
71
SHACKLE STABILIZER,5 904660
72
RUBBER MOUNTING SHACKLE TO TORSION BAR,5 904660
72
RUBBER MOUNTING TORSION BAR,4 707917
74
REPAIR KIT , Replaced By: A3873200128
74
REPAIR KIT TORSION BAR MOUNTING,4 707917
74
REPAIR KIT , Replaced By: A3873200528
74
REPAIR KIT TORSION BAR MOUNTING,4 707918
77
LOCK RING SHACKLE TO TORSION BAR,5 904660
80
BUSHING TORSION BAR TO BEARING BRACKET
83
BUSHING SHACKLE TO BEARING BRACKET,5 904660
86
SPACER WASHER SHACKLE TO BEARING BRACKET,5 904660
89
WASHER SHACKLE TO CONSOLE,965965
92
LOCK RING SHACKLE TO CONSOLE TO 393 326 00 63,965965
95
LOCK SPRING PIN LOCK
98
SCREW CLAMP TO BRACKET AND TO PIPE
101
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
104
WASHER ROCKER PANEL TO SUPPORT
107
NUT TORSION BAR TO BEARING BRACKET
110
TORSION BAR REAR AXLE
112
RUBBER MOUNTING TORSION BAR,4 114583
113
REPAIR KIT ,4 114583, Replaced By: A3463200128
113
REPAIR KIT TORSION BAR MOUNTING,4 114583
116
BRACKET ,4 114583
119
SCREW LEAF SPRING TO STRUT
122
LOCK WASHER FITTING TO BRACKET
125
NUT STRAP TO SUPPORT
128
BEARING REAR AXLE TO TO REAR SPRINGS
131
WASHER STEEL VERSION
134
U-BOLT , Replaced By: A9433510225, +002N910113024000
134
U-BOLT , Replaced By: A6203510125
134
U-BOLT REAR AXLE TO TO REAR SPRINGS 475 MM,4 941583
134
U-BOLT REAR AXLE TO TO REAR SPRINGS 500 MM,4 941582
137
BUSHING TORSION BAR TO BEARING BRACKET
140
DISC SPRING TORSION BAR TO BEARING BRACKET
143
LOCK SPRING PIN LOCK
146
SCREW CLAMP TO BRACKET AND TO PIPE
149
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
152
NUT TORSION BAR TO BEARING BRACKET
999
PIN , Replaced By: A6203200228
999
PIN , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE4 707618, Replaced By: A3875860232
999
SHACKLE ,4 707917, Replaced By: A3873260647, +001A3873260281
999
CONSOLE , Replaced By: A3933200678
999
CONSOLE , Replaced By: A3933261163, +001N000961016081
999
SPACER WASHER , Replaced By: A3873230252
999
SHACKLE ,4 707917, Replaced By: A3933260547, +001A3873260281
999
SPACER WASHER SHACKLE TO BEARING BRACKET,5 904660
999
COTTER PINROCKINGER TYP 260 G140
999
COTTER PIN DRAG LINK TO STEERING ARM AND PITMAN ARM
999
NUT COMBINATION CYLINDER TO BEARING BRACKET
999
NUT COMBINATION CYLINDER TO BEARING BRACKET, Replaced By: N910113016002
