Поз.
Артикул
Описание
10
CRANKCASE CYLINDER CRANKCASE, FOR BREAK-DOWN OF OF GASKET KIT, SEE END OF GROUP 01
10
GASKET KIT , Replaced By: A3460102008
30
CRANKCASE , FROM ENGINE 053820 ALSO INSTALLED ON 052845-052871,052879-052894,052899-052920,053035-053037,053073,053094-053097,053316,053317,053319, 053320,053322-053325,053401-053557,053568-053593,053599-053613,053615-053636,053641-053663,053671- 053742,053750-053767,053772-053817.
31
CYLINDER PIN
31
CYLINDRICAL PIN
32
SCREW
35
CAMSHAFT BEARINGNO.6
35
CAMSHAFT BEARING NO.1
35
CAMSHAFT BEARINGNO.4
35
CAMSHAFT BEARING NO.2
35
CAMSHAFT BEARINGNO.7
35
CAMSHAFT BEARINGNO.5
37
CAMSHAFT BEARINGNO.3
47
PLUG
48
POINTER
49
PIPE SOCKET
51
PLUG ,010629
53
SEAL RING AT TANK
56
PLUG ,010630
58
EXPANSION PLUG
60
EXPANSION PLUG CORE HOLE 40.30 MM
62
SCREW PLUG
64
DOWEL PIN
66
EXPANSION PLUG
68
SEAL RING TEMPERATURE GAUGE SENDER UNIT
70
SCREW PLUG OIL PASSAGE,REAR
72
SCREW PLUG BELL HOUSING
74
SCREW PLUG STABILIZER
83
SCREW
84
SCREW PLUG
85
SEAL RING VALVE TO VALVE,K 025179
85
SEAL RING FUEL LINE TO FEED PUMP
86
PLUG
88
INTERMEDIATE PIECE , 910,912-916,941-946,952 FROM ENGINE 043849 ALSO INSTALLED ON 043812-043847,911,918 FROM ENGINE 044327 UP TO ENGINE 053819 EXCEPT FOR 052838-052840,052845-052871,052879-052894,052899-052920,053035-053037,053073,053094-053097,053316, 053317,053319,053320,053322-053325,053401-053557,053568-053593,053599-053613,053615-053636,053641- 053663,053671-053742,053750-053767,053772-053817.
88
INTERMEDIATE PIECE , FROM ENGINE 053820 ALSO INSTALLED ON 052845-052871,052879-052894,052899-052920,053035-053037,053073,053094-053097,053316,053317,053319, 053320,053322-053325,053401-053557,053568-053593,053599-053613,053615-053636,053641-053663,053671- 053742,053750-053767,053772-053817.
90
SEAL RING OIL LINE TO OIL COOLER
92
THREADED CHUCK
94
SCREW PLUG BELL HOUSING
96
SEAL RINGTO 006 997 00 72
97
SCREW PLUG
98
SCREW FITTING
98
FITTING FROM INTAKE MANIFOLD TO VACUUM LINE, FROM IDENT NO.002799-360785
101
CYLINDER LINER REPAIR SOLUTION, CYLINDER CRANKCASE WITH DRY LINERS 133.6 MM
101
CYLINDER LINER REPAIR SOLUTION, CYLINDER CRANKCASE WITH DRY LINERS 133.7 MM
101
CYLINDER LINER REPAIR SOLUTION, CYLINDER CRANKCASE WITH DRY LINERS 133.5 MM
104
SENDER UNIT OIL PRESSURE GAUGE M 10X1,027218
104
SENDER UNIT OIL PRESSURE GAUGE
104
SENDER UNIT OIL PRESSURE GAUGE
104
SENDER UNIT OIL PRESSURE GAUGE, 910,912-916,941-946,952 UP TO ENGINE 043848 EXCEPTO FOR 043812-043847,911,918 UP TO ENGINE 044326
106
SEAL RING FUEL LINE TO FEED PUMP
108
FITTED SLEEVE
110
STUD
112
CLAMPING SLEEVE
114
STUD
210
BREATHER PIPE
214
COVER
224
BRACKET , 003251 051353
226
BRACKET BACK-UP LIGHT
228
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
228
SCREW PROTECTIVE PLATE TO EXHAUST PIPE
228
SCREW , Replaced By: N304017008016
229
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
231
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
231
SCREW , Replaced By: N304017008016
232
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
233
WASHER EXHAUST MUFFLER TO STRAP
234
NUT
315
GASKET TIMING CASE COVER
317
COVER
319
SEAL RING
319
SEAL RING
320
GASKET GASKET KIT,TIMING CASE COVER
321
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
321
SCREW , Replaced By: N304017008016
323
WASHER , Replaced By: N000125008443
323
WASHER EXHAUST MUFFLER TO STRAP
325
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
325
SPRING WASHER , Replaced By: N000137008212
327
NUT
329
GASKET CYLINDER SIDE COVER
329
GASKET , Replaced By: A3150150221
331
CYLINDER SIDE COVER
333
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
333
SCREW , Replaced By: N304017008016
333
SCREW , Replaced By: N304017008021
333
SCREW PIPE CLAMP
334
SPACER SLEEVE. SPACER TUBE FAN SHROUD TO RADIATOR,4 1619994 428844
336
GASKET CYLINDER SIDE COVER
338
COVER , 910,913,914,916 005183 919,940-945,947 005183 912 004152 915 005033 917 005065
338
COVER
344
COVER
353
SEAL RING CYLINDER SIDE COVER
356
SCREW STRAP TO BRACKET
500
CRANKCASE CYLINDER CRANKCASE, FOR BREAK-DOWN OF OF GASKET KIT, SEE END OF GROUP 01
500
GASKET KIT , Replaced By: A3460102008
999
SEAL. GASKET , Replaced By: A3661880880
999
GASKET , Replaced By: N917003026003
999
SEAL RING CONNECTION: 1,4 719029
999
SCREW FITTING , Replaced By: A4039971172
999
SCREW PLUG SECONDARY CONSUMING UNIT AIR RESERVOIR
999
SEAL RING SPEEDOMETER DRIVE
999
SEAL RING AIR COMPRESSOR,CONNECTION: "10"
999
SEALING RING. SEAL RING OIL DRAIN
999
SEAL RING LOCKING VALVE 20X24
999
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SEAL RING CONNECTIONS "22,31"
999
SEAL RINGTO 000 553 03 05,000 553 18 05,
999
SEAL RING VALVE,CONNECTION "10"
999
SEAL RING PNEUMATIC VALVE
999
SEAL RING BRAKE CYLINDER STROKE INDICATOR
999
SEAL RING , Replaced By: N007603010110
999
SEAL RING BRACKET TO CYLINDER HEAD
999
SEAL RING SCREW PLUG
999
SEAL RINGTO 000 429 24 30
999
SCREW DIFFERENTIAL CASE
999
THREADED PIN
999
CORE PLUG , Replaced By: A3269970106
999
SCREW PLUG
999
GASKET CONNECTOR TO CYLINDER CRANKCASE
999
GASKET , Replaced By: A3550770080
999
GASKET
999
REPAIR KIT , Replaced By: A3550100280
999
GASKET
999
SEAL RING
999
GASKET OIL FILTER TO CYLINDER CRANKCASE
999
GASKET OIL COOLER TO OIL FILTER
999
GASKET INTAKE MANIFOLD TO CYLINDER HEAD
999
GASKET INJECTION PUMP DRIVE TO TIMING CASE
999
VALVE SEAT RING , Replaced By: A3550532032
999
VALVE SEAT RING , Replaced By: A3550531832
999
VALVE SEAT RING , Replaced By: A3550532032
999
VALVE SEAT RING , Replaced By: A3550531832
999
VALVE GUIDE , UP TO ENGINE 027399,ALSO INSTALLED ON 027459,027464,027467, Replaced By: A3460531229, +001A3520530296
999
VALVE GUIDE , UP TO ENGINE 027399,ALSO INSTALLED ON 027459,027464,027467, Replaced By: A3460531129, +001A3520530296
999
PART NAME MISSING , UP TO ENGINE 027399,ALSO INSTALLED ON 027459,027464,027467, Replaced By: A3460530929, +001A3520530296
999
CYLINDER HEAD GASKET
999
CYLINDER HEAD GASKET , Replaced By: A3450160320
999
CYLINDER HEAD GASKET , Replaced By: A3550160220
999
GASKET
999
GASKET OIL PAN,LEFT
999
GASKET OIL PAN,RIGHT
999
CYLINDER HEAD CYLINDER HEAD
999
GASKET KIT , Replaced By: A3550101220
999
GASKET KIT , Replaced By: A3550101120
999
SEAL
999
BOOT , Replaced By: A3520530296
999
GASKETTO 352 010 01 68
999
CAP , Replaced By: A0000180702
999
SEAL RING , Replaced By: A0169978248
999
SEAL RING , Replaced By: A3469970445
999
PLUG , Replaced By: A3469970135
999
SCREW PLUG , Replaced By: A4039970230
999
PLUG , Replaced By: A3469970106
999
GASKET KIT , Replaced By: A3460100180
999
GASKET KIT , Replaced By: A3460100280
999
GASKET KIT , Replaced By: A3465860790
999
GASKET KIT , Replaced By: A3465860690, +001A3550101220
999
GASKET KIT , Replaced By: A3465860690, +001A3550101220, +001A3462001201
999
GASKET KIT , Replaced By: A3465860590
999
GASKET KIT , Replaced By: A3465860490
999
GASKET KIT , Replaced By: A3465860390
999
SEALING FLANGE , Replaced By: A3451420080
999
GASKET , Replaced By: A3551410280
999
VALVE GUIDE REPAIR SIZE I 15.10 MM, FROM ENGINE 027400,EXCEPTO FOR 027459,027464,027467
999
VALVE SEAT RING , Replaced By: A3550531331
999
VALVE GUIDE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3550530530
999
VALVE GUIDE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3550530430
999
VALVE SEAT RING , Replaced By: A3550531232
999
VALVE SEAT RING , Replaced By: A3550531131
999
VALVE GUIDE , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A3550530330
999
VALVE SEAT RING , Replaced By: A3550531032
999
INTAKE VALVE , Replaced By: A3460530001
999
EXHAUST VALVE , Replaced By: A3460530005
999
VALVE SEAT RING , Replaced By: A3460530532
999
VALVE SEAT RING , Replaced By: A3460530731
999
CYLINDER HEAD GASKET , Replaced By: A3550160220
999
CYLINDER HEAD GASKET , Replaced By: A3550160220
999
GASKET , Replaced By: A3460150222
999
GASKET , Replaced By: A3460150120
999
GASKET OIL PAN
999
OIL PAN , 912 005607 917 005612 912 005608 917 005613 045215, Replaced By: A3550100013, +001A3550100166, +001A3550100072, +028N000931008266
999
CYLINDER HEAD LESS VALVES
999
OIL PAN , 910,914,915 UP TO ENGINE 043950 ALSO INSTALLED ON 043994,043999,SEE FOOTNOTE 59, Replaced By: A3550100313, +001A3550100066, +001A3550100072, +028N000931008057
999
CYLINDER HEAD , UP TO ENGINE 027399,ALSO INSTALLED ON 027459,027464,027467, Replaced By: A3550100220, +002A3520530296
999
OIL FILLER NECK
999
COVER , 910,913,914,916 005184 919,940-945,947 005184 912 004153 915 005034 917 005066 051353, Replaced By: A3460101116, +001A3460101464, +001A3460181640, +001A3550180140, +001N000933008131, +002N000934008010, +001N071511036001, +003N912004008102
999
GUIDE TUBE , 910,914,915 UP TO ENGINE 043950 ALSO INSTALLED ON 043994,043999,SEE FOOTNOTE 59
999
BREATHER PIPE , Replaced By: A3460100670, +001A3460101116, +001A3460181640, +001A3550180140, +001N000125008418, +001N000933008131, +002N000934008010, +001N071511036001, +003N912004008102
999
CYLINDER SIDE COVER , Replaced By: A3460100010
999
GASKET KIT , Replaced By: A3550100380
999
OIL DIPSTICK , 910,914,915 UP TO ENGINE 043950 ALSO INSTALLED ON 043994,043999,SEE FOOTNOTE 59
999
OIL FILLER NECK
999
GUIDE TUBE , 910,914,915 UP TO ENGINE 043950 ALSO INSTALLED ON 043994,043999,SEE FOOTNOTE 59
999
CYLINDER SIDE COVER , Replaced By: A3260100610
999
GASKET EXHAUST MANIFOLD TO CYLINDER HEAD
999
VALVE SEAT RING , Replaced By: A3550532032
999
VALVE SEAT RING , Replaced By: A3550531832
999
CYLINDER HEAD GASKET , Replaced By: A3550160420
999
CYLINDER HEAD GASKET , Replaced By: A3450160520
999
PLUG , Replaced By: A3269970106
