Поз.
Артикул
Описание
1
BEARING BRACKET ENGINE ALONGSIDE FIXING,REAR
1
BEARING BRACKET ENGINE ALONGSIDE FIXING,REAR
2
BEARING BRACKET ENGINE ALONGSIDE FIXING,REAR
2
BEARING BRACKET ENGINE ALONGSIDE FIXING,REAR
2
BEARING BRACKET ENGINE ALONGSIDE FIXING,REAR
2
BEARING BRACKET ENGINE ALONGSIDE FIXING,REAR
3
SCREW. HEXAGON HEAD BOLT VALVE TO BRACKET
3
SCREW , Replaced By: N308676012012
3
SCREW CONSOLE TO SIDE MEMBER
5
ROD , Replaced By: A3522420737, +001A0009961540, +001A0009961740, +001N000934016007, +001N000934016014
8
ROD
8
ROD , Replaced By: A3522420737
8
ROD
10
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
11
UNION NUT BUTT SCREW CONNECTION
12
GLAND LINE CONNECTION
13
THRUST RING BUTT SCREW CONNECTION
14
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
14
SEAL RING , Replaced By: N007603012121
15
VALVE TWO-CIRCUIT, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
15
VALVE THREE-CIRCUIT PROTECTIVE VALVE TO BRACKET, 840081
16
VALVE DISC024, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
16
VALVE DISC024, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
16
VALVE DISC024, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
17
VALVE DISC101
18
SEALBOSCH 024, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
18
SEALBOSCH 024, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
18
SEALBOSCH 024, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
19
CUP , INCLUDED IN RANGE OF DELIVERY OF 000 431 68 06
19
CUP , INCLUDED IN RANGE OF DELIVERY OF 000 431 68 06
19
CUP , INCLUDED IN RANGE OF DELIVERY OF 000 431 68 06
20
O-RING CHECK VALVE TO AIR RESERVOIR
20
O-RING CHECK VALVE TO AIR RESERVOIR
22
THRUST RING CHECK VALVE TO AIR RESERVOIR
22
THRUST RING CHECK VALVE TO AIR RESERVOIR
22
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
23
NUT CHECK VALVE TO AIR RESERVOIR
23
NUT CHECK VALVE TO AIR RESERVOIR
25
SEAL RING LINE CONNECTION
28
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
30
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
32
T-FITTING COMPRESSED AIR VALVE CONNECTION
33
RESERVOIR TWO-CHAMBER CAPACITY 30X30 L.
33
RESERVOIR COMPRESSED AIR
33
RESERVOIR COMPRESSED AIR
33
RESERVOIR COMPRESSED AIR
33
RESERVOIR , Replaced By: A3604303205
33
RESERVOIR COMPRESSED AIR 20 L
33
RESERVOIR COMPRESSED AIR 20 L
33
RESERVOIR COMPRESSED AIR 20 L
33
RESERVOIR COMPRESSED AIR 20 L
33
RESERVOIR COMPRESSED AIR 20 L
34
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
35
FITTING SHUTTLE VALVE,CONNECTION: "20"
35
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
35
DOUBLE FITTING BETWEEN TIRE INFLATOR CYLINDER AND PRESSURE REGULATOR
35
DOUBLE FITTING BETWEEN TIRE INFLATOR CYLINDER AND PRESSURE REGULATOR
36
SEAL RING LINE CONNECTION
36
SEAL RING LINE CONNECTION
40
VALVE DRAIN, Replaced By: A0004322407
40
VALVE DRAIN, Replaced By: A0004322107
40
VALVE DRAIN, Replaced By: A0004322107
40
VALVE , Replaced By: A0004320807
40
VALVE. DRAIN VALVE DRAIN
40
VALVE. DRAIN VALVE DRAIN
43
RING DRAIN VALVE TO 000 432 08 07, NOT USED
43
RING DRAIN VALVE TO 000 432 08 07, NOT USED
44
VALVE (OVERFLOW VALVE)
44
VALVE (OVERFLOW VALVE)
44
VALVE (OVERFLOW VALVE)
44
VALVE (OVERFLOW VALVE)
44
VALVE (OVERFLOW VALVE)
44
VALVE (OVERFLOW VALVE)
44
VALVE (OVERFLOW VALVE)
44
VALVE (OVERFLOW VALVE)
44
VALVE (OVERFLOW VALVE)
44
VALVE (OVERFLOW VALVE)
44
VALVE (OVERFLOW VALVE)
44
VALVE (OVERFLOW VALVE)
46
O-RING CHECK VALVE TO AIR RESERVOIR
47
THRUST RING CHECK VALVE TO AIR RESERVOIR
47
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
48
NUT CHECK VALVE TO AIR RESERVOIR
50
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
52
BRAKE BOOSTER , Replaced By: A0004315414
52
BRAKE BOOSTER TWO-CIRCUIT, PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
53
FILLER RING BRAKE BOOSTER
53
BRAKE BOOSTER , Replaced By: A0004317014
54
SEAL RING154.2X5.7 MM
54
SEAL RING154.2X5.7 MM
55
SEAL RING
58
SEAL RING , ONLY APPLICABLE TO UNIT 000 431 54 14
58
SEAL RING , ONLY APPLICABLE TO UNIT 000 431 54 14
60
SEAL RING
61
SEAL RINGTO 001 431 37 05,4 375193
62
SEAL RING LINE TO OIL PUMP
62
SEAL RING , ONLY APPLICABLE TO UNIT 000 431 54 14
64
PROTECTIVE CAP BRAKE BOOSTER
64
PROTECTIVE CAP , Replaced By: A0004311087
65
FILTER BOTTOM , INCLUDED IN RANGE OF DELIVERY OF 0004313114 TWO-CIRCUIT BRAKE BOOSTER
70
VALVE REAR BRAKE BOOSTER
70
VALVE REAR BRAKE BOOSTER
72
VALVE SEAT REAR BRAKE BOOSTER
72
VALVE SEAT REAR BRAKE BOOSTER
75
VALVE , Replaced By: A0005862043
75
REPAIR KIT REAR BRAKE BOOSTER, ONLY APPLICABLE TO UNITS 000 431 32 14 AND 000431 31 14
75
REPAIR KIT REAR BRAKE BOOSTER, ONLY APPLICABLE TO UNITS 000 431 32 14 AND 000431 31 14
77
FILTER BOTTOM , ONLY APPLICABLE TO UNITS 000 431 32 14 AND 000431 31 14
77
FILTER BOTTOM , ONLY APPLICABLE TO UNITS 000 431 32 14 AND 000431 31 14
80
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
82
BRAKE BOOSTER , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
84
UNION NUT LINE CONNECTION
85
GLAND LINE CONNECTION
86
T-FITTING
86
T-FITTING
86
T-FITTING
87
SCREW PLUGTO 000 553 03 05,000 553 18 05,
87
SCREW PLUG , Replaced By: N000908014009
87
SCREW PLUG , Replaced By: N000908022011
87
SCREW PLUG LOAD/NO-LOAD VALVE,CONNECTION: "21"
89
SEAL RING LINE CONNECTION
90
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
90
FITTING , Replaced By: A0009970171
90
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
91
SEAL RING FUEL LINE TO FEED PUMP
92
FITTING
92
FITTING , Replaced By: A0039979972
93
ELBOW FITTING , Replaced By: A0019907571
93
ELBOW FITTING 3/2-WAY VALVE,CONNECTION "1"
95
BRACKET , 352 431 48 40 EXCHANGEABLE FOR 352 431 58 40,352 431 00 74 EXCHANGERABLE FOR 360 431 0274,000471 030000 EXCHANGEABLE FOR 000933 008014 CON TINUED ON FOOTNOTE 12, Replaced By: A3524315840
95
BRACKET , 352 431 48 40 EXCHANGEABLE FOR 352 431 58 40,352 431 00 74 EXCHANGERABLE FOR 360 431 0274,000471 030000 EXCHANGEABLE FOR 000933 008014 CON TINUED ON FOOTNOTE 12, Replaced By: A3524315940
95
BRACKET BRAKE BOOSTER
95
BRACKET BRAKE BOOSTER
96
SHIM
96
SHIM
96
SHIM
97
SCREW BRACKET TO SIDE MEMBER
97
SCREW , Replaced By: N304017010002
98
SCREW BRACKET TO TRANSMISSION CASE
99
BRACKET , Replaced By: A3604300910
99
BRACKET BRAKE MASTER CYLINDER
99
BRACKET BRAKE MASTER CYLINDER
99
BRACKET COMPRESSED AIR LINE MOUNTING
99
BRACKET COMPRESSED AIR LINE MOUNTING
99
BRACKET , Replaced By: A3604300910
99
BRACKET , Replaced By: A3604300910
99
BRACKET BRAKE MASTER CYLINDER
100
SHIM BRACKET TO SIDE MEMBER
100
SHIM BRACKET TO SIDE MEMBER
102
SCREW REAR EXHAUST PIPE TO MUFFLER
102
SCREW REAR EXHAUST PIPE TO MUFFLER
102
SCREW MANUAL PUMP TO BRACKET AND TO PLATE M 10X40
104
SCREW END PIECE TO EXHAUST PIPE M 10X25
104
SCREW END PIECE TO EXHAUST PIPE M 10X25
104
SCREW END PIECE TO EXHAUST PIPE M 10X25
105
LEVER BRAKE BOOSTER TO BRACKET
105
LEVER BRAKE BOOSTER TO BRACKET
105
LEVER BRAKE BOOSTER
105
LEVER BRAKE BOOSTER
108
PIN DOUBLE LEVER TO CONSOLE
109
LOCK RING P.T.O.
110
SCREW , Replaced By: N304017008016
110
SCREW OIL-DIPSTICK GUIDE TUBE TO BRACKET
112
PIN PISTON ROD TO LEVER, 415 5 014668 416 5 000515 417 4 972023
115
CLAMP ,K 147121, Replaced By: N000000000319
115
CLAMP IDLING ADJUSTMENT WIRE CABLE,K 147121
115
CLAMP , Replaced By: N916016008200
118
CLAMP , Replaced By: N916016015202
118
CLAMP LINE MOUNTING
120
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
120
LINE BRAKES 6X0.7 MM, LENGTH AVAILABLE 25000 MM
120
LINE , Replaced By: A0004296201
122
SPACER TUBE BEARING BRACKET TO STEERING COLUMN BRACKET
124
BRACKET OIL LINE MOUNTING
124
BRACKET OIL LINE MOUNTING
124
BRACKET OIL LINE MOUNTING
125
CLAMP , Replaced By: N916016015202
125
CLAMP LINE MOUNTING
999
VALVETO 003 429 04 44,WABCO
999
LINE , Replaced By: A0005516256
999
DIAPHRAGM
999
THRUST RING FROM 3/2-WAY VALVE TO QUICK BREATHER VALVE,5 431227
999
DIAPHRAGM , Replaced By: A0004290745
999
DIAPHRAGM
999
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
999
SEAL RING
999
T-FITTING AIR RESERVOIR I
999
NUT AT BRAKE BOOSTER
999
VALVE
999
REPAIR KITTO 003 429 02 44
999
FILTER BOTTOMTO 001 431 32 14,001 431 68 14
999
VALVE , FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927
999
PROTECTIVE CAP101
999
VALVE , Replaced By: A0004320807
999
GASKETTO 000 429 16 30
999
REPAIR KITTO 000 429 63 44,000 429 59 44
999
REPAIR KIT OVERFLOW VALVE TO 003 429 09 44,WABCO
999
SEALING CORD , Replaced By: A0009870446
999
SEALING CORD BRAKE BOOSTER 34 MM X 2,3 MM, TO 000 431 36 14
999
T-FITTING , Replaced By: N074317000100
