Поз.
Артикул
Описание
1
T-FITTING AT HAND BRAKE VALVE, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927 UP TO CHASSIS 872788 EXCEPT FOR, 500033-599999
1
T-FITTING AIR RESERVOIR I
2
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
4
CONTROL COCK
5
ROTARY SLIDE PARKING BRAKE
6
SPRING PARKING BRAKE
7
LEVER PARKING BRAKE
8
TS DOUBLE FITTING SOLENOID VALVE
8
FITTING , Replaced By: A0029906071
8
FITTING , Replaced By: A0039979072
8
DOUBLE FITTING , Replaced By: A0019972872
9
SEAL RING LINE CONNECTION
15
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
17
UNION NUT LINE CONNECTION
18
GLAND LINE CONNECTION
20
LINE FROM VALVE TO CONNECTION FITTING,K 172343 ORDER BY THE METER
22
TWO-WAY VALVE
23
VALVETO 000 429 00 47
24
SPRINGTO 000 429 00 47
25
SPRINGTO 000 429 00 47
26
SEAL RINGTO 000 429 00 47
27
DOUBLE FITTING BETWEEN THE LINES, BUTT CONNECTION
29
SEAL RING LINE CONNECTION
32
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
34
TUBE FROM HIGH PRESSURE HOSE TO STEERING, LENGTH AVAILABLE: 3000 MM
37
UNION NUT BUTT SCREW CONNECTION
38
GLAND LINE CONNECTION
39
THRUST RING BUTT SCREW CONNECTION
40
SEAL RING DOUBLE BRAKE LINE COUPLING, CONNECTIONS: "11,12"
40
SEAL RING , Replaced By: N007603012121
999
VALVE TAPPETTO 000 429 30 44
999
LINE , Replaced By: A0005516256
999
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
999
VALVETO 000 429 30 44
999
SEAL RING
999
AIR CLEANER ,4 390315
999
ADAPTER FITTING , Replaced By: N074313008101
999
ADAPTER FITTING , Replaced By: A0039972072
999
VALVE
999
O-RING CHECK VALVE TO AIR RESERVOIR
999
LEAD SEAL ROCKER SWITCH, Replaced By: A0009883070
999
THRUST RING CHECK VALVE TO AIR RESERVOIR
999
FITTING TWO-WAY VALVE,CONNECTION: "12",4 691316
999
SEAL RINGTO 000 429 30 44
999
VALVE
999
FITTING , Replaced By: A0039978972
999
FITTING (PARTS KIT),LINE RUPTURE
999
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236, Replaced By: N000000006190
999
FITTING , Replaced By: A0029905971
999
WIRE SPRING LOAD ACCUMULATOR UNIT
999
FITTING AIR RESERVOIR,CONNECTION: "52",K 093236
999
SCREW , Replaced By: N304017006012
999
NUT BALL PIVOT TO LEVER
999
CONNECTION FITTING ,880809
999
NUT CHECK VALVE TO AIR RESERVOIR
999
FITTING , Replaced By: A0039972072
999
SCREW 3/2-WAY SOLENOID VALVE TO BRACKET
999
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
999
LOCKING CONE CONNECTOR
999
NUT AIR RESERVOIR,CONNECTION "14"
