Поз.
Артикул
Описание
5
INJECTION PUMP
10
FITTING
20
SEAL RING
25
PRESSURE VALVE
34
CLAMPING PIECE THREADED
35
CLAMPING PIECE WITH THRU HOLE
40
LOCK WASHER CONTROL LEVER TO INJECTION PUMP LEVER
45
SCREW
47
SEAL RINGTO 000 429 24 30
47
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
50
SCREW BREATHER TO 001 477 14 01
51
SEAL RING PNEUMATIC VALVE
51
SEAL RING FUEL LINE TO FEED PUMP
51
SEAL RING , Replaced By: N007603010110
52
SCREW PLUG
53
SEAL RING
54
FITTING
55
PRESSURE VALVE PRESSURE RELIEF
56
SPRING ,295837/93
57
SEAL RING LINE CONNECTION
57
SEAL RING INJECTION PUMP
58
SEAL RING LINE CONNECTION
58
SEAL RING PNEUMATIC VALVE
58
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
58
SEAL RING , Replaced By: N007603010110
67
WOODRUFF KEY POWER STEERING PUMP
69
LOCK WASHER DRIVE GEAR TO INJECTION PUMP
70
NUTTO 007 074 03 02
72
SCREW LICENSE PLATE TO BRACKET
72
SCREW , Replaced By: N304017006020
73
WOODRUFF KEY INJECTION PUMP
127
SEAL RING PNEUMATIC VALVE
127
SEAL RING , Replaced By: N007603010110
129
SCREW PLUG 4/2-WAY VALVE
129
SCREW PLUG AIR DEHYDRATOR
138
HEXAGON HEAD BOLT RESONATOR TO TRANSMISSION CASE,K 138633
138
SCREW , Replaced By: N910105010001
138
SCREW
139
STUD BOLT CONTROL BLOCK M 10X35
140
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
141
NUT
142
WASHER RADIATOR TO RUBBER MOUNTING
143
WASHER AIR CLEANER TO SUBSTRUCTURE
143
SEAL RING
143
SEAL RINGTO 388 476 71 69
143
WASHER BEARING BRACKET TO SIDE MEMBER
185
NOZZLE HOLDER
187
SPACER WASHER1.08 MM
187
SPACER WASHER1.68 MM
187
SPACER WASHER1.80 MM
187
SPACER WASHER1.18 MM
187
SHIM, 1.0 MM THICK. SPACER WASHER1.0 MM
187
SPACER WASHER1.88 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
187
SPACER WASHER1.50 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
187
SHIM, 1.45 MM THICK. SPACER WASHER1.45 MM
187
SHIM, 1.95 MM THICK. SPACER WASHER1.95 MM
187
SPACER WASHER1.28 MM
187
SPACER WASHER1.38 MM
187
SHIM, 1.20 MM THICK. SPACER WASHER1.2 MM
187
SHIM, 1.30 MM THICK. SPACER WASHER1.3 MM
187
SHIM, 1.35 MM THICK. SPACER WASHER1.34 MM, Replaced By: A0030177852
187
SHIM, 1.40 MM THICK. SPACER WASHER , Replaced By: A0030178452
187
SHIM, 1.50 MM THICK. SPACER WASHER1.50 MM, Replaced By: A0030179452
187
SHIM, 1.70 MM THICK. SPACER WASHER , Replaced By: A0040171452
187
SHIM, 1.80 MM THICK. SPACER WASHER1.80 MM, Replaced By: A0040172452
187
SHIM, 1.85 MM THICK. SPACER WASHER , Replaced By: A0040172852
187
SPACER WASHER , Replaced By: A0030179252
187
SPACER WASHER , Replaced By: A0040171252
187
SPACER WASHER1.78 MM, Replaced By: A0040172252
187
SPACER WASHER1.88 MM, Replaced By: A0040173252
187
SPACER WASHER1.98 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
187
SPACER WASHER0.88 MM
187
SPACER WASHER1.40 MM
187
SPACER WASHER1.58 MM
187
SHIM, 1.60 MM THICK. SPACER WASHER1.6 MM
187
SPACER WASHER0.80 MM
187
SPACER WASHER1.70 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
187
SHIM, 1.90 MM THICK. SPACER WASHER1.9 MM
187
SPACER WASHER0.98 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
187
SHIM, 1.75 MM THICK. SPACER WASHER1.75 MM
187
SHIM, 1.55 MM THICK. SPACER WASHER1.55 MM
187
SPACER WASHER1.84 MM
187
SHIM1.78 MM
187
SPACER WASHER0.94 MM
187
SHIM, 1.10 MM THICK. SPACER WASHER1.1 MM
187
SPACER WASHER1.30 MM
187
SHIM, 1.15 MM THICK. SPACER WASHER1.15 MM
187
SPACER WASHER1.98 MM
187
SHIM, 1.05 MM THICK. SPACER WASHER1.04 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
187
SPACER WASHER1.20 MM
187
SHIM, 1.65 MM THICK. SPACER WASHER1.65 MM
187
SPACER WASHER0.84 MM
187
SPACER WASHER1.48 MM
187
SPACER WASHER0.90 MM
187
SHIM1.34 MM,TO 002 017 03 21,002 017 35 21, TO NOZZLE HOLDER OF MAKE: BOSCH
187
SHIM, 1.25 MM THICK. SPACER WASHER1.24 MM
192
PRESSURE SPRING
195
SPACER WASHER , Replaced By: A0020172252
195
SHIM , Replaced By: A0010179452
195
SPACER WASHER AS REQUIRED
195
SPACER WASHER
200
PIN
205
UNION NUT AS REQUIRED M 22X1.5
205
UNION NUT , Replaced By: A0000174616
205
UNION NUT AS REQUIRED M 24X1.5
207
NOZZLE
209
SEAL RING NOZZLE HOLDER TO CYLINDER HEAD 1.0 MM
209
SEAL RING NOZZLE HOLDER TO CYLINDER HEAD 1.5 MM
209
SEAL RING , THE OLD PART MUST NO LONGER BE INSTALLED IN THIS PLACE, Replaced By: A3880170160
211
SCREW
213
LINE UNBENT
215
LINE CYLINDER NO.1
220
LINE CYLINDER NO.2
225
LINE CYLINDER NO.3
230
LINE CYLINDER NO.4
235
LINE CYLINDER NO.5
240
LINE CYLINDER NO.6
245
SEAL RING CONNECTION TO CYLINDER HEAD
245
SEAL RING DELIVERY LINES
250
SHIM DELIVERY LINE IN CLAMPING PIECE, UP TO ENGINE 461718 YEAR OF MANUFACTURE 1998
250
SHIM , Replaced By: A6034280284, +002A0004290540
250
SHIM DELIVERY LINE IN CLAMPING PIECE
255
CLAMP , Replaced By: A0004290540, +002A3660780386
255
CLAMP , Replaced By: A0004290540, +002A3660780386
255
BRACKET
258
CLAMP DELIVERY LINE
258
CLAMP , Replaced By: A0004290540, +002A3660780386
260
CLAMPING PIECE LINE MOUNTING, ON TRUCKS FROM CHASSIS 156442-263695,ON BUSES FROM CHASSIS 020034-263695,FROM CHASSIS 263696 SEE MICRO FICHE 723.0 ONLY FOR USE WITH HYDRAULIC MODULATOR
260
CLAMPING PIECE , Replaced By: A0004290540, +002A6034280284
260
CLAMPING PIECE , Replaced By: A0004290540, +002A6034280284
263
TAPPING SCREW. SHEET METAL SCREW OIL LINE MOUNTING
263
SCREW COVER PLATE TO COVER PLATE M 6 X 12
265
LINE (FUEL LEAK LINE)
270
SEAL
272
HOLLOW SCREW FUEL LINES TO SOLENOID VALVE
274
SCREW PLUG
276
SEAL RING DELIVERY LINES
277
FITTED WASHER
277
WASHER , Replaced By: N000988008024
278
SCREW PLUG
999
BEARING
999
CAMSHAFT
999
SCREW , TO INJECTION PUMP HAVING THE BOSCH DESIGNATION PES-6A-80C,OR PES-6A-90C
999
CLAMPING JAW. CLAMPING PIECE , Replaced By: A0000781335, +001A0000781435
999
CLAMPING JAW WITH THREAD. CLAMPING PIECE , Replaced By: A0000781435, +001A0000781335
999
FITTING , Replaced By: A0000781069, +001A0000780129
999
INJECTION TIMING DEVICE , Replaced By: A3520700645, +001A3229900001, +001A3129941201
999
BEARING BRACKET , FROM ENGINE 054057-054976 SEE SERVICE INFORMATION, Replaced By: A3220760235
999
INJECTION TIMING DEVICE
999
INJECTION TIMING DEVICE , Replaced By: A3520701345
