Поз.
Артикул
Описание
5
FUEL FILTER
10
SEAL RING FUEL FILTER COVER
12
NUT
12
TIGHTENING NUT. NUT , Replaced By: A0004770873
14
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
18
SCREW BREATHER TO 001 477 14 01
18
BREATHER SCREW. SCREW , Replaced By: A0000741771
20
SEAL RINGBOSCH
22
SCREW
24
SEAL RING VALVE TO VALVE,K 025179
28
FILTER ELEMENT , Replaced By: A3554700092
28
FILTER ELEMENT , Replaced By: A0000901451
28
TS AIR FILTER ELEMENT WITH SEAL RING
30
SPRING
32
BRACKET
34
SCREW PLUG , Replaced By: N007604014110
34
SCREW PLUG FUEL TANK
36
SEAL RING FUEL LINE TO FEED PUMP
48
PIN
50
NUT
52
VALVE SPRING. SPRING
54
VALVE JACKET
56
GASKET
57
TS AIR FILTER ELEMENT WITH SEAL RING
57
FILTER ELEMENT , Replaced By: A0000901451
58
GASKET , Replaced By: A0004773180
58
SEAL RING FUEL FILTER COVER
60
SEAL RING INJECTION PUMP
62
LOCK NUT FOR COVER. NUT
64
SEAL RING
66
BREATHER SCREW. SCREW
68
SEAL RING VALVE TO VALVE,K 025179
70
SCREW PLUG
72
SEAL RING FUEL LINE TO FEED PUMP
73
SCREW PLUG FUEL TANK
73
SCREW PLUG , Replaced By: N007604014110
75
FUEL FILTER
77
PIN
78
SEAL RING FUEL FILTER COVER
78
GASKET , Replaced By: A0004773180
79
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
81
NUT
81
TIGHTENING NUT. NUT , Replaced By: A0004770873
83
SEAL RING CONTROL VALVE,5 093991
85
SCREW BREATHER TO 001 477 14 01
86
SEAL RING FUEL LINE TO FEED PUMP
86
SEAL RING VALVE TO VALVE,K 025179
87
SCREW PLUG , Replaced By: N007604014110
87
SCREW PLUG
87
SCREW PLUG FUEL TANK
127
SCREW BRACKET TO FRAME
127
SCREW BRACKET TO SIDE MEMBER M 12X40
135
SHIM BRACKET TO FENDER,5 952572
137
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
139
HEXAGON HEAD BOLT RUBBER MOUNTING TO SIDE MEMBER AND TO SUPPORT M10X20
139
SCREW , Replaced By: N304017010028
999
FILTER BOWLTO 001 092 19 01
999
FILTER ELEMENT , Replaced By: A3524700092
999
FILTER ELEMENT , Replaced By: A3524700092
999
GASKET , Replaced By: A0000947180
999
BAFFLE PLATE , FOR USE ON TURBOCHARGERS WITH MODEL NO. 64 155 245 0127, BUILT UNTIL AUGUST 1965
999
COVER , FOR USE ON TURBOCHARGERS WITH MODEL NO. 64 155 245 0127, BUILT UNTIL AUGUST 1965
999
HOUSING
999
GASKET , Replaced By: A0004773180
999
BREATHER SCREW. SCREW , Replaced By: A0000741771
999
FILTER ELEMENT , Replaced By: A3554700092
999
SEAL RING ,D 031246
999
FELT TUBE ELEMENT. FILTER ELEMENT , Replaced By: A0000922705
999
FUEL FILTER , Replaced By: A0014772901
999
FILTER ELEMENT , Replaced By: A0000922705
999
PRESSURE SPRING. SPRING , Replaced By: A0029932801, +001A0004770176
999
LOOM TIE , Replaced By: N916017070000
999
LOOM TIE , Replaced By: N916018080000
999
LOOM TIE , Replaced By: N916018110000
999
NUT CONNECTING PIPE TO EXHAUST MANIFOLD
999
NUT
999
LOOM TIE , Replaced By: N916017070000
999
LOOM TIE , Replaced By: A0009979990
999
LOOM TIE
999
WASHER , Replaced By: A3529901740
999
TURBOCHARGER , Replaced By: A3520960499
999
BRACKET , Replaced By: A3520980139
999
FILTER ELEMENT , Replaced By: A4220900051
999
FILTER ELEMENT , Replaced By: A0000901451
999
SCREW , Replaced By: N304017010053
999
SCREW COVER PLATE TO BRACKET
999
NUT STRAP TO SUPPORT,5 149419
999
SCREW PIPE ELBOW TO BRACKET M 10X50
999
NUT
999
LOCK WASHER FITTING TO BRACKET
