Поз.
Артикул
Описание
30
LINE AIR COMPRESSOR,PRESSURE REGULATOR, DEHYDRATOR 15X1.5 MM, LENGTH AVAILABLE: 3000 MM
30
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
30
HOSE , Replaced By: A0009872827
35
UNION NUT BUTT SCREW CONNECTION
40
GLAND LINE CONNECTION
100
HOSE LEAK LINE 4X6 MM, ORDER BY THE METER
100
PLASTIC PIPE RISING PIPE 4X6 MM
105
FITTING (PARTS KIT),LINE RUPTURE,5 909352K 169122
110
UNION NUT
115
GLAND , Replaced By: A0019901667
120
SLEEVE LEAK LINE
368
VALVE REGULATING SOLENOID VALVE "KNORR", REPAIR IMPOSSIBLE
368
VALVE (SOLENOID VALVE) "BOSCH", REPAIR IMPOSSIBLE
368
VALVE REGULATING SOLENOID VALVE "WABCO", PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
368
VALVE , Replaced By: A0044296044
368
VALVE , Replaced By: A0044295944
368
VALVE , REPAIR IMPOSSIBLE, Replaced By: A0044296144
368
VALVE , REPAIR IMPOSSIBLE, Replaced By: A0044293444
376
VALVE
384
SEAL RING , NOT USED
388
ADAPTER FITTING FLUID RESERVOIR TO BRACKET
392
T-FITTING BETWEEN THE LINES
400
T-FITTING AT HAND BRAKE VALVE, FROM CHASSIS 674068 ALSO INSTALLED ON, 500001-599999,673550,673631,673890,673916-673918,673922,673927 UP TO CHASSIS 872788 EXCEPT FOR, 500033-599999
402
T-FITTING AT CONTROL VALVE
404
ELBOW FITTING FROM PUMP TO CYLINDER, Replaced By: N000000006197
404
FITTING FROM PUMP TO CYLINDER
408
NUT CHECK VALVE TO AIR RESERVOIR
416
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
424
O-RING CHECK VALVE TO AIR RESERVOIR
426
FITTING BETWEEN THE LINES
427
SEAL RING COMPRESSED-AIR-LINE PLUG-CONNECTION
428
LOCK COMPRESSED-AIR-LINE PLUG-CONNECTION
430
SCREW. UNION SCREW LINE CONNECTION
432
BRACKET AT CONTROL VALVE
432
BRACKET RIGHT
448
CLAMP HOSE TO FLANGE AND TO VALVE
456
SCREW REAR AXLE REGULATING SOLENOID VALVE
458
WASHER BRACKET TO LEFT SIDE MEMBER
458
WASHER , Replaced By: N009021008213
460
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
464
NUT , Replaced By: N913004008001
472
SCREW PUMP TO BRACKET
472
SCREW , Replaced By: N304017006016
480
NUT , Replaced By: N913004006001
480
NUT PUMP TO BRACKET
488
BRAKE HOSE , Replaced By: A0004298735
488
BRAKE HOSE BETWEEN THE LINES
496
SEAL RING TO 18-MM-DIA. COMPRESSED AIR LINES
500
FITTING AIR RESERVOIR,CONNECTION: "13"
504
TEST CONNECTION
504
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
504
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
504
TEST CONNECTION SOLENOID VALVE,CONNECTION: "20"
508
PLUG
512
FITTING FROM 3/2-WAY VALVE TO PRESSURE CONTROL VALVE
512
FITTING , Replaced By: A0009977172
520
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
528
SEAL RING TO 18-MM-DIA. COMPRESSED AIR LINES
536
THRUST RING COMPRESSED AIR LINE TO AIR RESERVOIR AND TO T-FITTING
540
ADAPTER FITTING TEST CONNECTION
546
SCREW. UNION SCREW , Replaced By: A0009973734
546
SCREW. UNION SCREW LINE CONNECTION
552
NUT LOAD/NO-LOAD VALVE,CONNECTION: "20",5 727400
999
ELBOW FITTING CHECK VALVE TO AIR RESERVOIR
999
DISTRIBUTOR FRONT AXLE BRAKE CIRCUIT,5 411349
