Поз.
Артикул
Описание
1
PLASTIC PIPE FUEL LINE 12X1,5 MM, ORDER BY THE METER
1
HOSE , Replaced By: A0009872827
3
SLEEVE LINE CONNECTION
3
BUSHING , Replaced By: N915062009000
5
SEAL CONE LINE CONNECTION
5
GLAND , Replaced By: A0019901967
7
UNION NUT LINE CONNECTION
7
UNION NUT LINE CONNECTION, Replaced By: N000000006239
7
UNION NUT , Replaced By: N915017012100
9
PLASTIC PIPE. HOSE AERATION 6X8 MM, ORDER BY THE METER
11
SLEEVE LINE CONNECTION
11
SLEEVE , Replaced By: N915062006000
13
GLAND LINE CONNECTION
15
UNION NUT LINE CONNECTION
15
UNION NUT , Replaced By: N915017008100
17
T-FITTING DIAPHRAGM CYLINDER,CONNECTION: "11",5 272559
19
T-FITTING 3/2-WAY VALVE, CONNECTIONS "P1,R2",4 307219
21
ELBOW FITTING TWO-WAY VALVE,CONNECTION "1.2"
21
ELBOW FITTING , Replaced By: A0019904371
23
O-RING CHECK VALVE TO AIR RESERVOIR
25
THRUST RING CHECK VALVE TO AIR RESERVOIR
25
THRUST RING , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0009940203
27
NUT CHECK VALVE TO AIR RESERVOIR
30
VALVE (OVERFLOW VALVE) BOSCH
32
SEAL RING LINE CONNECTION
34
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20"
34
FITTING FRONT AXLE REGULATING SOLENOID VALVE, CONNECTION: "20", Replaced By: N000000006191
36
NUT BRACKET TO SIDE MEMBER
38
BRACKET LINE CONNECTIONS
40
BRAKE VALVE , THE OLD PART MUST NO LONGER BE INSTALLED PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0034313505
40
BRAKE VALVE , Replaced By: A0014313705
40
BRAKE VALVE TRAILER CONTROL VALVE WABCO,4 375193
40
BRAKE VALVE TRAILER CONTROL VALVE BOSCH,4 375193 PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
42
REPAIR KITTO 001 431 37 05,4 375193
42
REPAIR KIT , Replaced By: A0024306581
44
T-FITTING RELAY VALVE,CONNECTION: "20"
46
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
48
THRUST RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
50
NUT LOAD/NO-LOAD VALVE,CONNECTIONS: "10,20"
52
SEAL RING LOAD/NO-LOAD VALVE,CONNECTION: "20"
54
FITTING DELIVERY LINE TO PUMP
56
FITTING RELAY VALVE,CONNECTION: "40",5 359430
56
FITTING , Replaced By: A0029979572
58
NUT OIL-DIPSTICK GUIDE TUBE TO BRACKET, Replaced By: N910113008003
58
NUT , Replaced By: N913004008001
60
BRACKET TRAILER CONTROL VALVE
65
PLUG FOUR-CIRCUIT PROTECTIVE VALVE, CONNECTION: "24", 620.415 UP TO CHASSIS 5 014668 620.416 UP TO CHASSIS 5 000515 620.417 UP TO CHASSIS 4 972023
70
BRACKET AT FITTING
75
FITTING BRAKE LINE COUPLING TO BRACKET
77
NUT BRACKET TO SIDE MEMBER
79
LOOM TIE LINE MOUNTING 280 MM
81
GROMMET LINE PASSAGE AT SIDE MEMBER
999
VALVE , Replaced By: A0014298744
999
DIAPHRAGM
999
DIAPHRAGM
999
BRAKE VALVE SEAL RING TO 001 431 18 05,4 412020
999
TEST CONNECTION
999
TEST CONNECTION , Replaced By: A0004312931
999
CROSS FITTING
999
T-FITTING SHIFT VALVE,CONNECTION: "11", 415 5 014668 416 5 000515 417 4 972023
999
PLUG
999
REPAIR KITBOSCH
999
REPAIR KITTO 001 431 34 05,4 375193
999
REPAIR KIT , Replaced By: A0004304606
999
ELBOW FITTING 3/2-WAY VALVE,CONNECTION: "20",5 765577
999
ELBOW FITTING DELIVERY LINE TO PUMP
999
ELBOW FITTING TRAILER CONTROL VALVE,CONNECTION: 1.1
999
LOOM TIE , Replaced By: A0019978390
999
LOOM TIE LINE MOUNTING
999
LOOM TIE LINE MOUNTING 150 X 3,6 MM
999
VALVE TRAILER BRAKE
999
VALVE (OVERFLOW VALVE) GRAU
999
REPAIR KIT VALVE KIT TO 001 431 37 05,4 375193
999
REPAIR KITTO 001 431 48 05,4 375193
999
FITTING SHUTTLE VALVE
999
SEAL RING
999
VALVE (OVERFLOW VALVE) KNORR
999
BRACKET COVERING
999
BRACKET , Replaced By: A3853530440
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, FRONT
999
BRACKET DELIVERY AND SUCTION LINES TO ENGINE, TOP
999
WASHER BRACKET TO LEFT SIDE MEMBER
999
BRACKET FUEL LINES TO TRANSMISSION
999
SCREW , Replaced By: N304017008021
999
SCREW END PIECE TO EXHAUST PIPE M 10X25
999
NUT BRACKET TO SUPPORT AND TO END PIECE
999
SCREW REINFORCEMENT TO ROCKER PANEL
999
FITTING ,4 667210
999
SCREW PIPE CLAMP
999
NUT
999
NUT STRAP TO BRACKET
999
LOCK WASHER CLAMP TO BRACKET AND TO PIPE
999
LOCK WASHER BRACKET TO SUPPORT AND TO END PIECE
999
NUT , Replaced By: N910113010000
999
NUT. UNION NUT LINE CONNECTION
