Поз.
Артикул
Описание
187
COVER ,019226
188
GASKET , Replaced By: A0002680280
188
GASKET , Replaced By: A0002685780
188
GASKET SHIFT CASE
189
PIN , THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002683974
189
PIN SHIFT CASE,BOTTOM
190
SPRING SHIFT CASE
191
HOUSING SHIFTING DOME
192
BUSHING SHIFTING DOME,TOP
193
SEAL RING SHIFTING DOME,TOP
194
BOOT SHIFTING SHAFT
195
VALVE BREATHER, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
196
SPRING WASHER , Replaced By: N000137008212
196
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
197
SCREW EXHAUST PIPE TO BRACKET M 8X40
198
SPRING ,039558 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0049932601, +001A0002680443, +001A0002681750, +001A0002681574
198
SPRING ,039558 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0049932601, +001A0002680443, +001A0002681750, +001A0002681574
198
SPRING SHIFTING LOCK,039559
199
PIN SHIFTING LOCK,018150
199
PIN ,018151039558 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002681574, +001A0002680443, +001A0049932601
199
PIN ,018151039558 THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE, Replaced By: A0002681574, +001A0002680443, +001A0049932601
199
PIN SHIFTING LOCK,039559
200
EXPANSION PLUG ROD END
200
EXPANSION PLUG ROD END
201
SHAFT SHIFTING LOCK
202
PISTON SHIFTING LOCK
203
LOCK PISTON TO ROD
204
SEAL RING SHIFTING LOCK
205
GASKET , Replaced By: A0002685180
205
GASKET SHIFT CASE,TOP AND BOTTOM
206
COVER SHIFT CASE,BOTTOM
207
SEAL RING CONTROL UNIT BRANCH-OFF
208
SEAL RING SHIFTING SHAFT,BOTTOM
209
BUSHING SHIFTING SHAFT,BOTTOM
210
SEAL RING SHIFTING SHAFT,BOTTOM
211
SPACER WASHER , Replaced By: A6022640852
211
SPACER WASHER AS REQUIRED 0.50 MM
212
SPACER WASHER SHIFTING SHAFT,BOTTOM
213
COVER SHIFTING LOCK,019226
214
SPRING WASHER , Replaced By: N000137008212
214
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
215
SCREW PLUG SOCKET TO BRACKET BEHIND CAB
215
SCREW FLEXIBLE METAL TUBE TO CONNECTOR AND TO COLLAR
216
SCREW , Replaced By: N000933008134
216
SCREW FRONT AXLE REGULATING SOLENOID VALVE
217
BREATHER SHIFTING LOCK
218
SPRING WASHER STEERING COLUMN BRACKET TO CAB
219
SCREW , Replaced By: N304014010004
219
SCREW REAR EXHAUST PIPE TO CLAMP
220
SCREW PLUG
221
SPRING WASHER STEERING COLUMN BRACKET TO CAB
222
SCREW CLUTCH TO FLYWHEEL
223
SCREW PLUG OIL FILLING, UP TO CHASSIS 4 277882 FROM CHASSIS 4 277883 SEE MICROFICHE,MODEL 750.402
224
PLUG , Replaced By: A0009977535
224
PLUG , Replaced By: A3529970032
224
SCREW PLUG BELL HOUSING
225
COVER , Replaced By: A0009977535
225
PLUG , Replaced By: A3529970032
225
SCREW PLUG BELL HOUSING
226
SPRING WASHER STEERING COLUMN BRACKET TO CAB
227
SCREW BRACKET TO BELL HOUSING
228
SCREW CLUTCH TO FLYWHEEL
229
BUSHING , Replaced By: A3241440150
229
BUSHING BRACKET TO TRANSMISSION CASE
230
BRACKET 4/2-WAY VALVE
231
SWITCH , Replaced By: A0005455906, +001A3805402281, +001A0005450149
231
SWITCH , Replaced By: A0015457614
231
SWITCH BACK-UP LIGHT SWITCH
232
GASKET , WITH AK 6-90 UP TO TRANSMISSION 068147,WITH AK 6-80 UP TO TRANSMISSION 279573
233
PLUG BACK-UP LIGHT TO 000 545 28 06, WITH AK 6-90 UP TO TRANSMISSION 068147,WITH AK 6-80 UP TO TRANSMISSION 279573
234
SCREW BRACKET TO TAIL LAMP BRACKET
235
SWITCH , Replaced By: A0015458214
235
SWITCH
236
SLOTTED GATE
237
GASKET , Replaced By: A0002685080
237
GASKET VALVE TO TRANSMISSION
238
PIN GEAR INTERLOCK, T0 000 261 06 19
239
SEAL RING NEUTRAL POSITION SWITCH,4 920019
240
SPRING WASHER , Replaced By: N000137008212
240
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
241
SCREW , Replaced By: N304017008034
241
SCREW BRACKET TO CROSS CONNECTION STRUT
241
SCREW CLAMP TO BRACKET AND TO PIPE
241
SCREW TWO-WAY VALVE TO BRACKET
242
SHAFT ,068893, Replaced By: A0002604238, +001A0039940141
242
SHAFT , Replaced By: A0002604238
242
SHAFT (SHIFTING SHAFT)
243
ROLLER SHIFTING SHAFT
244
GUIDE , Replaced By: A0002680990
244
GUIDE SHIFTING SHAFT
245
FOLLOWER TOP
246
SPRING SHIFTING SHAFT
248
FOLLOWER ,039558, Replaced By: A0002680443, +001A0002681750, +001A0002681574, +001A0049932601
248
FOLLOWER ,039559060449, Replaced By: A0002680443, +001A0002681750
248
FOLLOWER SHIFTING SHAFT,060450
249
CLAMPING SLEEVE FOLLOWER TO SHIFTING SHAFT
250
CLAMPING SLEEVE SHIFTING SHAFT
251
SHIFTING SEGMENT , Replaced By: A0002680446
251
SHIFTING SEGMENT SHIFTING SHAFT
252
BUSHING SHIFTING SHAFT,BOTTOM
254
SPACER WASHER , Replaced By: A0002681552
254
SPACER WASHER SHIFTING SHAFT
255
SPRING , Replaced By: A0019939101
255
SPRING SHIFTING SHAFT,BOTTOM
256
PRESSURE SPRING , Replaced By: A0049930701
256
SPRING SHIFTING SHAFT,BOTTOM
257
LOCK SHIFTING SHAFT
258
JOINT , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0002684889
258
JOINT SHIFTING SHAFT,TOP
259
NUT , Replaced By: A0002680472
259
NUT , Replaced By: N913004010010
259
NUT , Replaced By: N910113010002
259
HEXAGON NUT
260
NUT , Replaced By: N308673014001
260
NUT BRACKET TO SIDE MEMBER,K 035196
261
CONNECTOR , Replaced By: A0002601175
261
CONNECTOR , Replaced By: A0002601275
261
CONNECTOR JOINT TO SHIFTING TUBE
262
JOINT TOP
262
JOINT , Replaced By: A0002686189
262
JOINT , Replaced By: A0002684789
263
NUT STRAP TO BRACKET
263
NUT STRAP TO BRACKET
263
NUT , Replaced By: N910113010000
264
NUT SHIFT LEVER HANDLE TO SHIFT LEVER
265
NUT L.H. THREAD
266
PULL ROD , TO BE ADAPTED DURING ASSEMBLY
266
PULL ROD , Replaced By: N900331012340
267
NUT BRACKET TO FRAME
268
JOINT BOTTOM
268
JOINT , Replaced By: A0002686289
269
SPRING WASHER STEERING COLUMN BRACKET TO CAB
270
SCREW CLUTCH TO FLYWHEEL
271
BRACKET BRACING,019225
285
VALVE 4/2-WAY
285
VALVE , Replaced By: A0002601457
287
FITTINGTO 000 553 23 01,000 553 37 01,WEBER,4 294800
288
SPRING WASHER ALTERNATOR CONNECTION D+
289
SCREW TWO-WAY VALVE TO BRACKET
290
SCREW CONNECTION LINE CONNECTION TO SHIFTING CYLINDER
291
LINE LINE CONNECTION TO SHIFTING CYLINDER
292
LINE LINE CONNECTION TO SHIFTING CYLINDER, 031138
293
UNION NUT
294
SEAL CONE
294
GLAND , Replaced By: A0019901667
295
HOSE LINE CONNECTION TO SHIFTING CYLINDER, 031138
295
HOSE LINE CONNECTION TO SHIFTING CYLINDER, 031138
296
CLAMP LINE CONNECTION TO SHIFTING CYLINDER
297
LINE FROM FITTING TO VALVE 6X1 MM, LENGTH AVAILABLE 3000 MM
297
LINE , Replaced By: A0004290001
299
VALVE , PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART, Replaced By: A0012602757
301
SEAL RING LINE CONNECTION
302
SCREW-IN FITTING MOUNTED TO T-FITTING,145736 ALSO INSTALLED ON 145741,145768,145770,145774,145786,145787,145795,145807,145808,145819,145825,145830,145837,145840, 145846,145860,145861,145888,145901,145907,145910,145911,145913-145917,146138. EXCEPT FOR 139841,139842,140553,145397,145406,145409,145426,145445,145462,145592,145660,145697,145701.
303
UNION NUT LINE CONNECTION,5 999999K 040105
304
SPRING WASHER PROTECTIVE PLATE TO EXHAUST MUFFLER
304
SPRING WASHER , Replaced By: N000137008212
305
SCREW PIPE CLAMP
305
SCREW , Replaced By: N304017008021
306
BALL SHIFTING ROD
308
CLAMP LINE MOUNTING
480
REPAIR KIT , Replaced By: A0002600468
999
SPINDLE , Replaced By: A0002680332, +001A0002680221, +NBA0002680173, +NBA0002680273, +NBA0002680373
999
SHIFTING FORK REVERSE SPEED AND CRAWLER GEAR,019225
999
BRACKET , Replaced By: A0002600162, +001N000094004051, +001N000125015013
999
PIPE (OIL SUCTION PIPE),019225
999
COVERING CASE PART I,019225
999
SPINDLE , Replaced By: A0002642418
999
PIPE INSIDE,CONTROL PRESSURE,019225
999
SHIFTING FORK P.T.O. CASE FOR TWO AXLES,019225
999
BREATHER , Replaced By: A3362640089
999
BREATHER , Replaced By: A3432640089
999
COUNTERSHAFT , Replaced By: A0002601924, +001A0002606305
999
SHIFTING ROD , Replaced By: A0002684025
999
GASKET KIT , Replaced By: A0002600568
999
PIPE CASE PART I,019225
999
CONNECTG.PARTS,DELY.RANGE , Replaced By: A0002606305, +001A0002640357
999
TRANSMISSION CASE P.T.O. CASE FOR TWO AXLES,019225
999
GASKET KIT , Replaced By: A0002607400
999
PIPE OIL LINE,019225
999
SHIFTING FORK , Replaced By: A0002601330
999
SHIFTING CYLINDER , Replaced By: A0002603563
999
VALVE , Replaced By: A0012602757, +001A0002670543, +001A0002681574, +001A0049932601
999
COUNTERSHAFT ,019225
999
REPAIR KIT PNEUMATIC SHIFTING CYLINDER TO 000 260 66 63
999
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0002604757
999
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0002604757
999
VALVE , THE OLD PART MUST NO LONGER BE INSTALLED, Replaced By: A0002604757
999
VALVE , Replaced By: A0012602757
999
CONNECTG.PARTS,DELY.RANGE P.T.O.
999
GASKET KIT (GASKET KIT),019226
999
TRANSMISSION CASE ,019225
999
TRANSMISSION CASE COVER ,019225
999
COVER , Replaced By: A0009971120
999
COVERING
999
DISC SUPPORT ANNULUS
999
PIN26 MM,019226-046557
999
PLANET GEAR PARTS KIT
999
GASKET , Replaced By: A0002622380
999
COVERING , Replaced By: A0002622729, +001A0002622380
999
GASKET TRANSMISSION COVER
